TBK vision TBK-MD5531EIR Manuale utente

HD-TVI 1080P

User Manual v2

TBK-MD5531EIR, TBK-MD5731EIR,

TBK-BUL4531EIR, TBK-BUL4731EIR

HD-TVI Cameras

TBK HD TVI Camera Series manual V2

www.tbkvision.com 1

1Product description

1.1 Product Introduction

This manual is applicable to following models:

TBK-MD5531EIR, TBK-MD5731EIR, TBK-BUL4531EIR,

TBK-BUL4731EIR.

This series of cameras use 2MP sensor, to provide HD-TVI

video signal at 1080P resolution. These are TVI cameras,

and therefore require a TVI compatible DVR to be

connected (they are not compatible with traditional PAL

analog devices).

1.2 Product Features

TBK HD TVI Camera Series manual V2

www.tbkvision.com 2

High Definition TVI 1080P real-time video.

HD TVI video output, no delay, lossless, long

distance transmission.

Progressive scan CMOS,capture moving object

perfectly.

Reach 400 meters coaxial cable real-time

transmission.

Support low illumination, auto color to black.

Support ICR switch, realize day&night monitor.

Support 3D noise reduction.

2Product Structure

The followings are the dimensions of some

products. No further notice for the upgraded

version.

TBK HD TVI Camera Series manual V2

www.tbkvision.com 3

Photo 2-1 TBK-MD5531EIR

Photo 2-2 TBK-MD5731EIR

TBK HD TVI Camera Series manual V2

www.tbkvision.com 4

Photo 2-3 TBK-BUL4531EIR

Photo 2-4 TBK-BUL4731EIR

TBK HD TVI Camera Series manual V2

www.tbkvision.com 5

3Technical Parameters

Image Sensor

1/2,7" color CMOS（1080P/2MP）

Signal

HD-TVI

Resolution

1080P 25IPS

Minimum Illumination

0.1 lux F1.2（0 lux with IR LED ON）

Lens

TBK-MD5531EIR: 3,6 mm

TBK-MD5731EIR: 2,8-12 mm

TBK-BUL4531EIR: 3.6mm

TBK-BUL4731EIR: 2,8-12 mm

Video Output

BNC×1

D&N

Support ICR

SNR

>52dB（AGC off）

OSD menu

Yes

TBK HD TVI Camera Series manual V2

www.tbkvision.com 6

BLC /HLC

Yes, adjustable

White balance

Automatic, manual, push

Privacy mask

yes

Other

Shutter, AGC, mirror, flip

LEDS IR

TBK-MD5531EIR: 24 pcs

TBK-MD5731EIR:36 pcs

TBK-BUL4531EIR: 36 pcs

TBK-BUL4731EIR: 42 pcs

Protection level

IP65

Power supply

TBK-MD5531EIR: 12 VDC 400 mA

TBK-MD5731EIR: 12VDC 500 mA

TBK-BUL4531EIR: 12VDC 500 mA

TBK-BUL4731EIR: 12VDC 600 mA

TBK HD TVI Camera Series manual V2

www.tbkvision.com 7

4Product Installation

1. Avoid installing the camera directly towards the

sun.

2. Do not install it in the place where temperature is

above 50℃or below -20℃.

3. No installation in the areas with frequent

vibration.

4. Avoid operating and storing in the water.

5. Video cable connector and DC tie-in must be

avoided touching water.

6. Please ensure that power input is right.

TBK HD TVI Camera Series manual V2

www.tbkvision.com 8

5Troubleshooting

No.

Problem

Reason

How to solve

Image normal

in the day

while vague or

being

interfered by

horizontal

stripes at night.

Power is not

enough or

power cable is

too long.

Change power

supply or

shorten power

cable.

No image

Wrong

connection to

the video

cable.

Reconnect

Power gets

problem.

Change power

supply.

Having not

connected to

power supply.

Plug in.

www.tbkvision.com
