TCL Alcatel SHINE PLUS Manuale tecnico
L2E Repair Document TCLCommunication Ltd.
Rev.
ONE TOUCH 5095Y/K/I Level 2 Enhance Repair Document
Page
1.0
1/82
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
SHINE PLUS
ONE TOUCH 5095Y/K/I
Note: this manual is non-contractual and TCL Communication Ltd. can modify it without prior
notice on the characteristics of described equipments.
L2E Repair Document TCLCommunication Ltd.
Rev.
ONE TOUCH 5095Y/K/I Level 2 Enhance Repair Document
Page
1.0
2/82
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
1.0
2016/3/23
Draft creation
Xiaolong Yang
Rev.
Date
Modification description
Prepared By
Checked By
Approved By
L2E Repair Document TCLCommunication Ltd.
Rev.
ONE TOUCH 5095Y/K/I Level 2 Enhance Repair Document
Page
1.0
3/82
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
Content
1Level 2 repair process ..............................................................................................5
2Warranty Check and Visual Inspection ...................................................................6
2.1 Warranty confirmation of L1.....................................................................................6
2.2 Visual mechanical check..........................................................................................7
2.3 Pretest........................................................................................................................8
3Battery......................................................................................................................17
3.1 Battery information.................................................................................................17
3.2 Battery test ..............................................................................................................19
3.4 Note of Battery ........................................................................................................21
4. Software download .................................................................................................21
4.1 Equipments requested when download：.............................................................21
4.2 Install driver..............................................................................................................21
4.3 SW download process.............................................................................................22
5 Disassembly and assembly ONE TOUCH 5095 ........................................................27
5.1 ESD Safety................................................................................................................27
5.2 Disassembly tool......................................................................................................27
5.3 Disassembly process...............................................................................................28
Disassembly Notice:......................................................................................................35
5.4 Reassembly Process ..............................................................................................36
5.5 Disassembly process evaluation...........................................................................37
6Disassembly Complete...........................................................................................38
7Level 2 repair...........................................................................................................44
7.1 power on issue.........................................................................................................45
7.2 Charge issue.............................................................................................................46
7.3 Display issue ............................................................................................................47
7.4 Vibrator issue ..........................................................................................................48
7.5 Touch panel issue...................................................................................................49
7.6 SIM recognize issue................................................................................................50
7.7 TF card recognized issue.......................................................................................51
7.8 Main camera issue ..................................................................................................52
7.9 Sub camera issue....................................................................................................53
7.10MIC issue .................................................................................................................54
7.11Speaker issue..........................................................................................................55
L2E Repair Document TCLCommunication Ltd.
Rev.
ONE TOUCH 5095Y/K/I Level 2 Enhance Repair Document
Page
1.0
4/82
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
8L2E Enhance Repair................................................................................................55
8.1 Position of L2 enhance components on main PCBA...........................................55
8.2 Trouble shooting for common failures..................................................................58
8.3 L2 enhance spare part list......................................................................................74
9PCBA exchange.......................................................................................................75
10 Other component exchange...................................................................................75
Function Test..................................................................................................................76
APPENDIX 1 Packaging Requirements ........................................................................77
L2E Repair Document TCLCommunication Ltd.
Rev.
ONE TOUCH 5095Y/K/I Level 2 Enhance Repair Document
Page
1.0
5/82
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
1 Level 2 repair process
Reassembly
Record in BIG
End
OK
Retest
OK
OK
Start
Visual Inspection
Warranty Check
Pretest & Failure confirm
SW Upgrade
Disassembly
L2 Repair
Retest
Function test
PCBA Replace
NG
NG
NG
Restore User Information
Back up user data
L2E Repair
Retest
OK
NG
L2E Repair Document TCLCommunication Ltd.
Rev.
ONE TOUCH 5095Y/K/I Level 2 Enhance Repair Document
Page
1.0
6/82
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
2 Warranty Check and Visual Inspection
2.1 Warranty confirmation of L1
IMEI sticker check:
1) Power on the handset, enter *#06#
2) If the IMEI sticker in the back casing is not lost:
We should make sure that the IMEI number MUST be the same with the one on the IMEI sticker; if
not, it‟s out of warranty policy.
Humidity sensitive label
If humidity sensitive label is not good, the cell phone will be considered as out of guarantee.
1). Liquid was detected by humidity sensitive label.
2). Position of humidity sensitive sticker.
L2E Repair Document TCLCommunication Ltd.
Rev.
ONE TOUCH 5095Y/K/I Level 2 Enhance Repair Document
Page
1.0
7/82
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
2.2 Visual mechanical check
Mechanical warranties check items:
1) Corrosion
Corrosion on the USB connector, SIM connector, and other metal surfaces。
2) Hole (diameter > 1mm)
Holes on any surface, including the front casing, furnished frame, battery cover, touch Lens,
keypad…
3) Bump
Bumps (diameter > 1mm) on any surface, including front casing, decorate frame, battery
cover, touch Lens, keypad, etc.
4) Scratch
Scratches (length > 3mm) on any surface, including the front casing, decorate frame, battery
cover, touch Lens, keypad, etc.
5) Distortion
Bend, twisted or crushed on the h/s, cover/casing or connectors, etc.
6) Broken
Touch broken, casing/cover broken, etc.
7) Dropped
Keypad tear off, touch lens, connectors dropped, etc.
L2E Repair Document TCLCommunication Ltd.
Rev.
ONE TOUCH 5095Y/K/I Level 2 Enhance Repair Document
Page
1.0
8/82
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
8) Gap
External physical damage relating to abnormal use, like front case and frame opened
9) Others
Damage caused by disassembly ,wrong part assembly, loss of components
Use in abnormal environment like high temperature causing plastic melts
2.3 Pretest
1) Check that the SIM card is set correctly.
2) Insert the battery.
3) Power on the cell phone.
4) If the cell phone cannot power on, visually check the condition of the battery connector. Replace
it if necessary.
5) If the cell phone asks to input NCK code, this means it is SIM locked and can only be worked
with dedicated SIM card. Use the correct SIM card.
6) Enter the phone code if necessary.
7) Press *#2886# in dial screen and then you will see the interface displaying the SW version.
Select “Auto” to start the auto test, or select “MANU” to do the MMI test manually.
If one of the test failed during “Auto” test mode, it will ask you “Restart?”, press “YES” to restart the
auto test from the first one and “NO” to exit the auto test, while “NEXT” to continue the auto test.
Traceability
L2E Repair Document TCLCommunication Ltd.
Rev.
ONE TOUCH 5095Y/K/I Level 2 Enhance Repair Document
Page
1.0
9/82
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
I. You can get some information such as IMEI, CU-REF, PTH, Date Code, etc.
II. Press “Pass” to continue.
Touch Panel1
I. “Please draw on the yellow area”according to instructions;
II. Press “Pass” to continue.
Touch Panel2
I. “Please draw on the yellow area”according to instructions;
II. Press “Pass” to continue.
LCD MIRE
I. You will see the LCD display three colors: RED, GREEN and BLUE if it
functions well;
II. Press “Pass” to continue;
LCD BLACK
I. You will see the LCD displays black if it functions well;
II. Press “Pass” to continue;
LCD GRAY
I. You will see the LCD displays grey if it functions well;
II. Press “Pass” to continue;
LCD GRAYLEVEL
L2E Repair Document TCLCommunication Ltd.
Rev.
ONE TOUCH 5095Y/K/I Level 2 Enhance Repair Document
Page
1.0
10/82
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
I. You will see the LCD displays grey level if it functions well;
II. Press “Pass” to continue;
LCD WHITE
I. You will see the LCD displays white if it functions well;
II. Press “Pass” to continue;
KEYPAD
I. Press the key displayed on the screen. The key on the screen will turn grey
when you press it if it functions well;
II. Press “Pass” to continue.
LCD BACKLIGHT
I. The screen backlight will be flashing if it functions well;
II. Press “Pass” to continue.
KEYBOARD BACKLIGHT
I. The keyboard backlight will be flashing if it functions well;
II. Press “Pass” to continue.
MAIN CAMERA
Press “Pass”to continue if the front camera functions well.
FRONT CAMERA
Press “Pass”to continue if the main camera functions well.
