Data Sheet
VCMS-Series Video Camera Stands
Product Overview
The TDK RF Solutions VCMS-Series Video
Camera Monopod Stands are designed specifi-
cally for mounting a shielded video camera in
EMC test environments.
The monopod stands are constructed of
durable, non-conductive, commercial grade
fiberglass and plastic that will not interfere with
RF test measurements.
Each VCMS rests on a solid Delrin base that
provides stability and balance for heavier
equipment but is lightweight enough to allow for
ease of movement within the test facility. The
VCMS is available in three models:
VCMS-150R The VCMS-150R telescoping
monopod stand easily adjusts from 100 cm to
150 cm in height, and supports equipment up to
10 kg. It is designed for use in anechoic cham-
bers, shielded rooms, and OATS.
VCMS-100RSB The VCMS-100RSB telescop-
ing monopod stand adjusts from 50 cm to 100
cm in height, supports equipment up to 10 kg,
and features a support bracket to stabilize the
stand against an object. It is designed for use
on car seats to monitor the dashboard and
instrument panel during automotive testing.
VCMS-30 The VCMS-30 monopod stand is fixed
at 30 cm high and supports equipment up to
1.5 kg. It is designed for use in small test
environments such as a TEM cell.
The TDK RF Solutions VCMS Video Camera
Monopod Stands are built for use in EMC
test environments. Camera stands are
available in several models to meet your
specific requirements.
Applications
Portable mounting for video cameras
Features
Three models available to fit your test
requirements
P
PRODUCTS
To learn more about TDK RF Solutions’ wide range of innovative products and services visit www.tdkrfsolutions.com
©Copyright 2004 TDK RF Solutions Inc. All rights reserved. Specifications subject to change without notice. DSVCMS072604
Ordering Information
Product: Camera Stand
Model Number: VCMS-150R, 100RSB,
30
Warranty: 1 year
To place an order or to learn more about the
TDK RF Solutions products that best meet your
needs, contact your TDK sales representative:
TDK RF Solutions Inc.
1101 Cypress Creek Rd.
Cedar Park, Texas 78613 USA
Phone: 1-512-258-9478
Fax: 1-512-258-0740
E-mail: [email protected]
World Wide Web: www.tdkrfsolutions.com
TDK Electronics Europe
TDK House, Queensway 5 - 7
RH1 1YB, Redhill, Surrey
United Kingdom
Phone: +44/1737-781-372
Fax: +44/1737-781-360
VCMS-Series Video Camera Stands
Mechanical Specifications
Construction: Fiberglass and plastic
Finish: Preventive water
absorption seal
Dimensions–VCMS-150R
Extended Height: 1.5 m (59”)
Collapsed Height: 1 m (39.4”)
Base Diameter: 0.38 m (15”)
Weight: 7.7 kg (17 lbs.)
Dimensions–VCMS-100RSB
Extended Height: 1 m (39.4”)
Collapsed Height: 0.5 m (19.7”)
Support Bracket Length: 0.36 m (14”)
Base Diameter: 0.38 m (15”)
Weight: 7.7 kg (17 lbs.)
Dimensions–VCMS-30
Fixed Height: 30 cm (12”)
Base Diameter: 15 cm (6”)
Weight: 3 kg (7 lbs.)
www.tdkrfsolutions.com
TOTALIRF EXPERTISETM
STS
SYSTEMS TEST SERVICES
P
PRODUCTS
SW
SOFTWARE
C
CHAMBERS
