Teac MP-470 Manuale utente

Media Player MP-470

User Manual

To ensure the smooth handling of your warranty please write the

serial number of your device into the box. In the case of warranty

you are expected to send it together with a copy of your invoice

to your nearest TEAC sales representative.

Downloaded from ManualMPlayer.com Manuals

English – 2 | MP-470

Disposing of the Product

Your device should not be

placed in municipal waste.

Please check local regula-

tions for disposal of elec-

tronic products.

zChanges in specifications and features may be

made without notice or obligation.

served. Edition: July 2008

zCompany and product names provided herein are

trademarks of their respective companies.

Downloaded from ManualMPlayer.com Manuals

English – 3 | MP-470

Content

Important Notice ........................................................................................................................................ 4

Safety Precautions...................................................................................................................................... 4

Battery.................................................................................................................................................. 5

Earphone ............................................................................................................................................. 5

Conneting to a PC ............................................................................................................................. 6

Important ..................................................................................................................................................... 6

Key Features................................................................................................................................................ 7

System Requirements ................................................................................................................................. 7

Package Content....................................................................................................................................... 7

Before Using................................................................................................................................................. 8

Driver .................................................................................................................................................... 8

Connect to a PC and download audio files .................................................................................. 8

Removing the player safely from the PC ........................................................................................ 9

Charging the battery....................................................................................................................... 10

Keys Description........................................................................................................................................ 11

Switching On/Off ...................................................................................................................................... 12

Key Lock..................................................................................................................................................... 12

Reset........................................................................................................................................................... 12

Hints According to User Interface .......................................................................................................... 12

Using the Touchpad Controls.......................................................................................................... 13

Main Menu ........................................................................................................................................ 13

Explorer Key Functions ..................................................................................................................... 14

Quick Option Menu Key Functions ................................................................................................ 14

Basic Operation ................................................................................................................................ 15

Playing Music............................................................................................................................................. 16

Music Explorer Screen ...................................................................................................................... 16

Music Mode....................................................................................................................................... 16

Quick Option Menü Music .............................................................................................................. 17

Viewing Photos ......................................................................................................................................... 18

Picture Mode .................................................................................................................................... 18

Quick Option Menu Picture (Photo) .............................................................................................. 19

Playing Movies .......................................................................................................................................... 20

Video Mode ...................................................................................................................................... 20

Quick Option Menu Movie.............................................................................................................. 21

Video Conversion............................................................................................................................. 21

Minimum System Requirements ............................................................................................. 21

Installation ................................................................................................................................. 22

Converting Video..................................................................................................................... 22

FM Radio.................................................................................................................................................... 25

Radio Mode ...................................................................................................................................... 25

Quick Option Menu Radio .............................................................................................................. 26

Reading an E-Book................................................................................................................................... 27

E-Book Mode..................................................................................................................................... 27

Manual Mode display .............................................................................................................27

Auto Mode display .................................................................................................................. 27

Adding a bookmark ................................................................................................................ 27

Quick option Menu Ebook .............................................................................................................. 28

Explorer ...................................................................................................................................................... 28

Customized Settings ................................................................................................................................. 29

Firmware Upgrade.................................................................................................................................... 30

Troubleshooting ........................................................................................................................................ 31

Technical Specifications.......................................................................................................................... 33

Warranty .................................................................................................................................................... 34

Downloaded from ManualMPlayer.com Manuals

English – 4 | MP-470

Important Notice

This product is protected by certain intellectual property rights of

Microsoft. Use or distribution of such technology outside of this

product is prohibited without a license from Microsoft.

Content owners use Windows Media digital rights management

technology (WMDRM) to protect their intellectual property, includ-

ing copyrights. This device uses WMDRM software to access

WMDRM-protected content. If the WMDRM software fails to pro-

tect the content, content owners may ask Microsoft to revoke the

software’s ability to use WMDRM to play or copy protected con-

tent. Revocation does not affect unprotected content. When you

download licenses for protected content, you agree that Microsoft

may include a revocation list with the licenses. Content owners

may require you to upgrade WMDRM to access their content. If

you decline an upgrade, you will not be able to access content

that requires the upgrade.

Safety Precautions

zDo not disassemble, repair or modify the player by yourself. Refer

servicing to qualified personnel only.

zKeep the player clean and never store it close to heat sources or

dirty, humid or rainy places and avoid direct sunlight.

zIf the surface is dirty, please clean it with soft cloth wet with clean

water or soft cleaning fluids and never clean the case with alco-

hol or aggressive diluents.

zNever use the player in extremely dry environment to avoid static

discharging.

zNever apply heavy impact on the player like dropping it or plac-

ing it on a magnet.

Downloaded from ManualMPlayer.com Manuals

English – 5 | MP-470

Battery

zThe battery used in this device may cause a fire or chemical

burn if mistreated. Do not disassemble, incinerate, or heat the

battery.

zDo not dispose the player in fire to avoid explosion because the

player has built-in battery.

zDo not touch the player with bare hands if the built-in battery is

leaking. In this case, contact service center for help since the

liquid may remain in the player. If your body or clothes has been

contacted with the battery liquid, wash it off thoroughly with

water. Also, if some of liquid gets into your eyes, do not rub your

eyes but immediately wash them with clean water, and consult

a doctor.

zDo not connect the player to a power source other than that

indicated in this manual or on the label as this may result in the

risk of fire or electric shock.

Earphone

zNever use the player during driving a car or using other vehicles

to avoid traffic accidents. This is also content of the law of some

countries. Even while walking it may be dangerous especially

when crossing the street. Please do not listen in extremely high

volume to avoid any dangers. Wherever potential risks may arise,

please do not use the player to ensure your safety.

zHearing experts advise against the constant use of personal

stereos played at high volume. Constant exposure to high

volumes can lead to hearing loss. If you should experience ring-

ing in the ears or hearing loss, discontinue use and seek medical

advice.

zPlease insert the earphone prior to turn on the player, which can

not only avoid damaging the earphone but keep the player in

good condition also. Turn off the player when it is not used.

Downloaded from ManualMPlayer.com Manuals

English – 6 | MP-470

Conneting to a PC

zNever disconnect the player from PC during downloading,

uploading and formatting to avoid failures and losses of data.

zWhen the player is used as removable disk, please follow strictly

the given file download and upload procedures. Our company

does not resume any responsibility for any data losses due to mis-

use.

Important

zPlease charge the battery immediately when the display indi-

cates low battery, or the device will be powered off automati-

cally. In this case, all settings will be saved.

zPlease disconnect the player from PC properly to avoid data

loss.

zBattery service life may be various from different using conditions,

manufacturer and manufacturing time.

zAvoid losses of data by regularly making backups of your data.

zIn both power on and power off state, the player may be

charged by the connection to PC via the USB line.

Note:

If the product suddenly has no response or powers off, an

electrostatic discharge may be the cause. In this circum-

stance, please follow the procedures below for recovery:

zTurn off the unit by pushing and holding the slide button at

the right (Power off position) for 15 seconds.

zTurn on the unit again

Downloaded from ManualMPlayer.com Manuals

English – 7 | MP-470

Key Features

z2.0 inch TFT color screen, 176x220 pixels resolution

zMP3 and WMA player

zAVI video player

zJPEG picture viewer (jpg)

zFolder navigation

zFM radio

zSeveral equalizer modes

zAppears as removable disk on the PC

zFirmware upgradeable

zRechargeable Lithium Polymer battery integrated

zID3 tag display showing artist / song title / lyrics

zUser specified settings

zTouchpad controls with backlight

System Requirements

zIBM PC & Compatible PC, Notebook, Apple Macintosh with USB

interface

zOperating System:

Windows98SE, Windows ME, Windows2000/XP, Windows Vista

Macintosh OS X

Package Content

Please check the package for the following items. If any one of

them is missing, please contact your vendor.

zMP-470 Player

zStereo earphones

zUSB cable

zBasic Operation Manual

zUser Manual (on CD)

zCD with Software

Downloaded from ManualMPlayer.com Manuals

English – 8 | MP-470

Before Using

Driver

Windows2000/XP/ME/Vista, Macintosh OS X

This player is plug & play for WIN2000/XP/ME/Vista OS and

Macintosh OS X.

Windows98/SE

For Windows98/SE, you are required to install a driver (available

from TEAC by request) before connection.

Connect to a PC and download audio files

To connect the player with the PC for transferring files:

1. Plug the larger end of the USB cable to the USB port of the PC,

and plug the smaller end to the USB port of the player.

2. Windows: It may take Windows several minutes to recognize and

set up the device the first time it is connected depending on

your hardware configuration. When the “ ” icon appears at the

right bottom of the PC screen, double click “My Computer” on

the desktop, you see a removable disk, which indicates the

player. Just use the removable disk as a regular local disk, copy-

ing files from or to it.

If you are using media management software such as iTunes,

Winamp, or Windows Media Player, please refer to their

documentation for support.

3. Macintosh: Open a finder window. Click on the Removable Disk

icon located on the left side of the finder window. Files can be

copied from/to the removable disk as usual.

Downloaded from ManualMPlayer.com Manuals

English – 9 | MP-470

Removing the player safely from the PC

Windows2000/XP

1. Left click the icon at the right hand corner of the taskbar.

2. Click on the pop-up mini-window with message of “Safely

Remove the USB Mass Storage Device – Drive (X:)”.

3. When you are prompted to remove the device, pull out the

player.

Windows98

Please make sure the data transfer is completed before unplug-

ging the MP3 player.

Macintosh

1. On the left side of the Finder Window,

identify the appropriate Removable Disk

icon.

2. Click on the “Eject” arrow on the right of

the Removable Disk icon.

3. Disconnect the USB cable from the player and your computer.

Downloaded from ManualMPlayer.com Manuals

English – 10 | MP-470

Charging the battery

The unit is equipped with a rechargeable Lithium Polymer battery.

If the icon is displayed the battery has to be charged. Please

charge the player with the provided USB cable at the PC. Upon

initial use, the battery should be charged fully (12 hours) to ensure

optimal performance and battery life.

To charge the battery, connect the larger end of the USB cable to

the USB interface of PC, and connect the other smaller end of the

USB cable to the USB interface of this player. The charging starts

immediately after the connection is made.

Important:

1. Do not connect the player to a power source other than

that which is indicated here or on the label as this may

result in the risk of fire or electric shock.

2. If the player gets unusually hot during charging, or you will

note any strange behaviour, disconnect the player imme-

diately from PC or charging unit and contact your local

dealer.

3. When connected to a USB hub, the hub must be self-

powered to charge the player’s battery.

Downloaded from ManualMPlayer.com Manuals

Indice

Manuali Lettore multimediale popolari di altre marche

Visual Land

Visual Land Impulse Manuale utente

limHD

limHD 200i Manuale utente

Transcend

Transcend DMP10 Manuale utente

Philips

Philips GoGear Muse SA2MUS08 Manuale utente

Fantec

Fantec MM-HDRL Manuale utente

Dune HD

Dune HD Duo 4K Manuale utente

IAdea

IAdea HMP-505S Manuale utente

Camos

Camos MMS-1000 Manuale utente

Energy

Energy 75 Series Manuale utente

Z3 Technology

Z3 Technology DME-03 Manuale utente

Sony

Sony SVR-2000 Guida utente

Meicheng

Meicheng HD-1080K12 Manuale utente

DENAFRIPS

DENAFRIPS ARCE Manuale utente

Topaz

Topaz CMS Media Player Istruzioni per l’uso

InFocus

InFocus LightCast Manuale utente

IconBiT

IconBiT XDS1003D Manuale utente

Quanmax

Quanmax QDSP-2090 Series Manuale utente

Samsung

Samsung MP-80S Manuale utente
