Raptor 1000 Features

•Resolution up to 1920 X 1080

•8/16/24 -Bits Per Pixel

•Hardware Double Buffering

•12 MB Viewable Frame Buffer

•24 Independent Overlays

•1024 Dynamic Colors

•Single Slot PCI Long Card

•Hardware Support for MOX

(Multiple Overlay Extension)

Markets

•Air Traffic Management

•Vessel Traffic Control

•Command & Control

Platforms

•Sun UltraSPARC Workstations

•Digital Alpha Workstations

Product Brief

Raptor 1000

1920 x 1080 Color Video Graphics Adapter

The Tech-Source Raptor 1000 high reso-

lution graphics accelerator combines in a

single slot PCI card a comprehensive

array of high-end display subsystem fea-

tures that formerly required a box level

solution. The Raptor 1000 is designed

for use in high resolution, high perform-

ance, color graphics applications such as

Air Traffic Management and Vessel Con-

trol. It's high level of integration achieves

extreme flexibility over a wide range of

functions.

An advanced Application Specific Inte-

grated Circuit designed by Tech-Source

engineers provides the ability to display

1024 independent dynamic colors at the

same time. That’s four times the number

of colors available in traditional graphics

systems. Specialized frame buffer layering

hardware allows for complete control of

24 independently addressable overlays

with dynamic priority adjustment. That’s

12 times more than most advanced un-

derlay/overlay systems.

The Raptor 1000 offers two-dimensional

drawing acceleration for polygons, text

and windowing operations. The graph-

ics-processor can generate an excess of

900,000 X Window System characters per

second providing the ability to manage

over 2,000 targets/tracks in real time.

Multiple configuration modes are avail-

able for double buffering and multiple

overlay buffering support. True hard-

ware double buffering is supported using

standard software interfaces such as

MBX (Multi-buffering extension for X)

and DBE (Double buffering extension).

Specialized flash fill hardware performs

back buffer screen erases in under 100

microseconds.

442 S. North Lake Boulevard

Altamonte Springs, FL 32701

407.262.7100

www.techsource.com

Tech Source, the Tech Source logo, and Raptor 1000 are trademarks of Tech Source, Inc. All other trademarks are the property of

notice. Tech Source, Inc. assumes no responsibility for errors or omissions that may appear in this document.

Raptor 1000 Technical Specifications

Raptor 1000 PCI video graphics adapter, software configurable resolutions up to 1920 x 1080, 12 MB frame

buffer, includes DB-13-W3 to 4BNC video cable, operating system specific device driver software

and manuals.

Raptor OpenWindows for Solaris Loadable drivers for Sun PCI systems running Solaris 2.6, 7 or 8.

Raptor X Servers for Digital UNIX Loadable drivers for the Digital/Compaq Alpha workstations running Tru64

UNIX, 4.0f, 5.0, 5.1.

Specifications

Frame Buffer Size 12 MB

Color Lookup Table 1024 entries

Bits Per Pixel 8, 16 or 24 (software configurable)

Dynamic Color Plane Groups 24

Drawing Processor Number Nine PCI graphics accelerator

PCI Interface 33 MHz, 32-bit, Revision 2.1

Video Interface Red, green and blue at RS-343 levels (50 ohm)

Video Sync Separate sync at TTL levels (75 ohm)

Video Connector DB-13-W3

Temperature Rating 10 degrees to 50 degrees C (operating)

-10 degrees to 70 degrees C (non-operating)

Humidity Rating 10% to 90% (non-condensing)

Power Rating Less than 15 watts

Physical 12.283 inches x 4.2 inches (PCI long format)

Software Available
