User Manual

BroadR-Reach –Standard Ethernet

MediaGateway

Version 1.0

17. September 2014

You can download the latest firmware and documentation for the MediaGateway here:

http://www.technica-engineering.de/MediaGateway

Page 2of 30

Index

1Feature List ................................................................................................................... 3

2Warranty and Safety Information ................................................................................... 4

3Pinning .......................................................................................................................... 5

3.1 Power connector (top left) ....................................................................................... 5

3.2 Switch connectors................................................................................................... 7

3.3 RJ45 Ethernet connectors....................................................................................... 7

3.4 SFP slot .................................................................................................................. 7

4Status LEDs and Pushbutton......................................................................................... 8

5Configuration Website ................................................................................................... 9

5.1 Website Home........................................................................................................10

5.2 System Information Tab.........................................................................................10

5.3 Control Panel Tab..................................................................................................11

5.4 Switch Status Tab..................................................................................................11

5.4.1 Port Name.......................................................................................................14

5.4.2 Tx/Rx octets....................................................................................................15

5.4.3 VLAN Configuration ........................................................................................15

5.4.4 BroadR-Reach Port.........................................................................................16

5.4.5 Gigabit Port.....................................................................................................16

5.4.6 SFP Port .........................................................................................................17

5.4.7 BroadR-Reach Test Modes.............................................................................18

5.5 Contact Tab ...........................................................................................................19

6Example MediaGateway Configuration “FullBlown” ......................................................20

7Hardware Variants........................................................................................................22

7.1 BroadR-Reach Analog Filter:..................................................................................22

7.2 SFP........................................................................................................................22

7.3 Debug connector....................................................................................................22

7.4 Startup Time ..........................................................................................................23

8Bootloader Update........................................................................................................24

9Application Firmware Update........................................................................................27

10 Frequently Asked Questions –FAQ..............................................................................29

11 Contact.........................................................................................................................30

Page 3of 30

1 Feature List

The Technica Engineering MediaGateway has the following basic features:

12 Ports Broadcom BroadR-Reach

100 MBit/s Fullduplex on a single unshielded twisted pair

3 Ports Gigabit Ethernet

10/100/1000 BaseTX Fullduplex

1 Port Gigabit Ethernet

SFP module socket

Broadcom BroadR-Reach Technology

Tyco MQS Connectors for BroadR-Reach and Power Supply

Webserver for easy configuration:

oMaster / Slave

oPort Mirroring

oVLAN Tagging

oPort Status Display

Import and Export of Configurations

WakeUp functionality

CAN, LIN and FlexRay interfaces (requires customer specific software)

Power output for attached devices: VBAT max. 1,2 Ampere in total (Fused)

19 Status LEDs

Possibility to reset to default settings by pushbutton

Robust steel case

Power requirement: 7 to 16 Volt DC (nominal 12 Volt DC)

Power consumption: 7 to 12 Watt

Size: 195 x 143 x 33 mm

Wight: 0,77 kg

International Protection: IP 2 0

Operating Temperature: -40 to +80 °Celsius

Page 4of 30

2 Warranty and Safety Information

Before operating the device, read this manual thoroughly and retain it for

your reference.

You can download the latest firmware and documentation for the

MediaGateway here:

http://www.technica-engineering.de/MediaGateway

Use the device only as described in this manual.

Use only in dry conditions.

Do not apply power to a damaged device.

Do not open the device. Otherwise warranty will be lost.

This device is designed for engineering purpose only.

Special care has to be taken for operation.

Do not use this device in a series production car.

As this device is likely to be used under rough conditions, warranty is limited

to 1 year.

Manufacturer liability for damage caused by using the device is excluded.

Page 5of 30

3 Pinning

The pinning of the ECU connectors is listed on the label on top of the device.

The Tyco Electronics (TE) Micro Quad Lock System (MQS) is used.

Tyco, MQS Abdeckkappe, 2x9 Pol, black Part Number 1-967416-1

alternatively Part Number 1-1355350-1

Tyco, MQS Abdeckkappe, 2x9 Pol, blue Part Number 3-967416-1

Tyco, MQS Buchsengehäuse, 2x9 Pol Part Number 965778-1

alternatively Part Number 962108-2

Tyco crimp contact Part Number 928999-1

Note: You can use the official Tyco tool for these crimp contacts. A cheap variant is the

crimp tool for “PSK” contacts.

3.1 Power connector (top left)

Connector color: Black

Power supply for the device is supplied by Pin 1 (12Volt) and Pin 2 (Ground).

Requirements for the MediaGateway itself: 12 Volt DC up to 1 Ampere (typical 600mA)

If the 12 Volt camera power output is used, this current is also sourced of Pin 1 and 2.

Warning: If you apply a voltage higher than 16 Volt, the device will be damaged!

Page 6of 30

CAN Bus interface (CAN A) on pins 5 (BP) and 6 (BM). This interface may be used for CAN

based wakeup and data transfer. In the default software there is no data transmission speci-

fied. This interface may only be used in customer specific (Gateway) software.

CAN B to CAN E do not support wakeup functionality. They are for data transfer only.

A wakeup-line may be connected on pin 7or 8. The wakeup-line should have the same volt-

age level as the power supply (12 Volt). A high level on one of these pins wakes up the ECU

from sleep mode and keeps it active. If the voltage on this pin drops below approx. 6 Volt for

more than about 3 seconds the ECU will enter sleep mode. It will wake up on a high level

again.

Alternatively the “Prevent sleep“ checkbox in the control panel of the website can be ena-

bled.

Attention: Ethernet Traffic on any port will prevent sleep mode. Timeout is set to 100 sec-

onds.

The LIN interface on pin 9 can be used to communicate with the Microcontroller by LIN bus.

In the default software there is no data transmission specified. This interface may only be

used in customer specific software.

The FlexRay interface on pin 17 and 18 can be used to communicate with the Microcontroller

by FlexRay bus. In the default software there is no data transmission specified. This interface

may only be used in customer specific software.

Function

Battery +12 Volt Input

Wake Line 3 (Output only)

Ground Input

CAN E Plus

CAN C Plus

CAN E Minus

CAN C Minus

CAN D Plus

CAN A Plus

CAN D Minus

CAN A Minus

CAN B Plus

Wake Line 2

CAN B Minus

Wake Line 1

FlexRay Plus

LIN Bus

FlexRay Minus

Page 7of 30

3.2 Switch connectors

Connector color: blue

The pins marked with (P) or (N) are used for the BroadR-Reach ports. Four ports are availa-

ble per switch.

You have to connect the (P) pin to the (P) pin of the periphery device.

You have to connect the (N) pin to the (N) pin of the periphery device.

Note: If you swap these two pins the link LED may be lit on the BroadR-Reach slave side,

but no data transmission will be possible.

The pins marked with (+) or (-) are 12 Volt power output pins. The actual voltage level of

these pins depends on the supply voltage of the ECU. Be aware that the sum of all 12 power

output pairs will deliver a maximum of 1.2 ampere. If more current is used the output will

temporary switch off.

The power output has to be switched on by website configuration (Control panel).

Function

Camera +12 Volt nominal output

BroadR-Reach Port 3, Positive

Camera Ground Output

BroadR-Reach Port 3, Negative

BroadR-Reach Port 2, Negative

Camera Ground Output

BroadR-Reach Port 2, Positive

Camera +12 Volt nominal output

n.c.

BroadR-Reach Port 1, Positive

Camera +12 Volt nominal output

BroadR-Reach Port 1, Negative

Camera Ground Output

Camera +12 Volt nominal output

BroadR-Reach Port 0, Negative

Camera Ground Output

BroadR-Reach Port 0, Positive

3.3 RJ45 Ethernet connectors

There are three RJ45 Standard Ethernet connectors of the front side.

3.4 SFP slot

There is one SFP cage for a MiniGBIC module.

The following modules have been tested:

Edimax Mini GBIC (SFP) LC, 1 Gigabit/s, 1000 Base-SX Module

SFPEX S1GT-A Mini GBIC (SFP) 10/100/100 MBit RJ45 Module

BEL SFP-1GBT-05 SFP 10/100/100 MBit RJ45 Module

Page 8of 30

4 Status LEDs and Pushbutton

The MediaGateway has several status LEDs at the front side of the case.

The “Host” LED is toggles slowly (approx. 0.5 sec) during normal operation to show that the

microcontroller is running in normal mode. It is toggling fast (approx. 0.1 sec) when the mi-

crocontroller is in bootloader mode. The bootloader mode is used for firmware update only

(see below in this manual). You cannot access the website when the device is in bootloader

mode.

When the device is in Bootloader-Update Mode the LED toggles with moderate frequency

(approx. 0.25 sec).

The port status LEDs Switch 1 to 3 and Port 3 to 0 monitor the link status of the correspondig

port. The LEDs are lit when there is BroadR-Reach link detected. They begin to blink when

there is data traffic on this link.

Note: There is an issue when P/N of the bus are swapped. The LED may be on in this case

on BroadR-Reach slave side, but there will be no data transmission possible.

The LEDs built in the RJ45 connector show the status of the gigabit ports. The left (orange

LED) is lit by a link-up. The right (yellow) will blink on data traffic.

The pushbutton on the left side of the case will reset all settings to factory default.

Press this button down for 10 seconds with a pen during powerup/startup of the device.

The IP Address will be reset to default (192.168.0.49)

All settings will be lost.

Note: The MAC Address will not be changed.

Page 9of 30

5 Configuration Website

You can access the configuration website with a standard web browser (Firefox is recom-

mended, Chrome is not recommended).

Connect your PC to a RJ45 connector.

The default IP address of the device is 192.168.0.49 and subnet mask 255.255.255.0

If someone has changed the IP address you can reset it to default as described in chapter 3

of this manual.

For example set the configuration PC to IP address 192.168.0.100 and subnet mask to

255.255.255.0

Page 10 of 30

5.1 Website Home

Warning: If there is a lot of broadcast traffic on the switch, the host microcontroller may be

jammed. You can not access the website in this case. Please use VLAN configuration to

forward only relevant messages to the host.

With the first access to the website you will get the home screen. Please select one of the

tabs for further configuration.

5.2 System Information Tab

On the tab „System Information“ some status information about the device is displayed. You

can check the version number of the application firmware and the bootloader or the unique

Altri manuali per MediaGateway

Indice

Altri manuali Technica Portale

Technica

Technica MediaGateway Manuale utente

Manuali Portale popolari di altre marche

LST

LST M500RFE-AS Manuale utente

Kinnex

Kinnex Media Gateway Manuale utente

2N Telekomunikace

2N Telekomunikace 2N StarGate Manuale utente

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manuale utente

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manuale utente

Telsey

Telsey CPVA 500 - SIP Manuale utente

RTA

RTA 460A-NNA4 Scheda tecnica

Shaw

Shaw Gateway HDPVR Manuale utente

ABB

ABB VSN900 Guida rapida

Commander

Commander Pulse Manuale utente

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manuale utente

NETGEAR

NETGEAR C6300BD Manuale utente

Amit

Amit CDW531AM Manuale utente

HMS

HMS Netbiter EasyConnect EC150 Manuale utente

Huawei

Huawei EchoLife HG620 Manuale utente

AT&T

AT&T U-verse 3801 Manuale per l'uso e la cura

Logic IO

Logic IO RTCU MX2 turbo Manuale utente

Suttle

Suttle MediaMAX MXM-521 Manuale utente
