BRSS10

Owner’s

Handbook

Blu-ray disc player

Read these instructions.

Keep these instructions.

Heed all warnings.

Follow all instructions.

Do not use this apparatus near water.

Clean only with a slightly damp cloth.

Do not block any ventilation openings.

Install in accordance with the manufacturer’s instructions.

Do not install or operate near any heat sources such as

radiators, stoves, or other apparatus that produce heat.

Unplug this apparatus during lightning storms or when

unused for long periods of time.

Refer all servicing to qualied service personnel. Servicing

is required when the apparatus has been damaged

in any way, such as the power-supply cord or plug is

damaged, liquid has been spilled or objects have fallen

into the apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally, or has been

dropped.

Warning: To reduce the risk of re or electrical shock, do

not expose this product to rain or moisture. The product

must not be exposed to dripping and splashing and no

object lled with liquids such as a vase of owers should

be placed on the product.

No naked ame sources such as candles should be placed

on the product.

Caution: Changes or modications not expressly approved

by the manufacturer could void the user’s authority to

operate this device.

Caution: Usage of controls or adjustments or performance

of procedures other than those specied herein may result

in hazardous exposure.

IMPORTANT

This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communication. However, this is no

guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful

interference to radio or television reception, which can be

determined by turning the equipment o and on, the user

is encouraged to try to correct the interference by one of

the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and

receiver.

- Connect the equipment into an outlet on a circuit

dierent from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV

technician for help.

This symbol indicates that there are

important operating and maintenance

instructions in the literature accompanying

this unit.

This symbol indicates that dangerous

voltage constituting a risk of electric shock

is present within this unit.

CAUTION!

RISK OF ELECTRIC SHOCK

DO NOT OPEN

TO REDUCE THE RISK OF ELECTRIC SHOCK

DO NOT REMOVE COVER (OR BACK)

IMPORTANT SAFETY INFORMATION

WARNING: DANGER OF RADIATION

These labels tell you that the unit contains a laser

component. Opening the CD compartment lid and

defeating the safety interlocks will expose the user to

radiation from the laser beam. Do not stare into the laser

while it is operating.

ELECTRICAL INFORMATION

Mains Supply: The mains operating voltage of this unit is

marked on a rating plate on the underside of the unit.

The means of disconnecting this appliance from the mains

supply is the mains plug. This should be unobstructed and

readily operable at all times.

INDEX INTRODUCTION

Read this manual before using your player.

The Player is set to play Region B Blu ray or Region 2 DVD

Video discs.

The player will accept the following disc types (among

others): Blu-Ray, DVD Video, DVD-RAM, DVD-R, DVD+R,

DVD-RW, DVD+RW, CD, CD-R, CD-RW, WMA, JPEG,

MPEG4.

The following formats are not acceptable:

Discs with other region codes.

Improperly formatted recordable discs, including

recordable discs which are not nalised.

IMPORTANT NOTE

Blu-ray and DVD Video discs contain various features.

Many features are determined by the program or software

content on the disc itself. Some procedures in this manual

cannot be performed if the disc does not support the

feature. Also, some discs may need special settings which

are unsupported by the player.

CAUTION: during playback, the disc spins at high speed,

do not lift or move the player, doing so may damage the

disc.

Full, high-denition video playback at up to 1080p•

resolution.

Up-conversion of standard DVD Video discs for•

enhanced picture quality at up to 1080p resolution.

HDMI AV Connection.•

Stereo analogue and digital audio outputs.•

PIP (picture in picture) functionality.*•

Pop-up menu display during playback.*•

Wired ethernet connection to enable access to BD-•

Live features.*

*Where available on Blu-ray discs.

Menu navigation assistance:

Your Blu-ray player includes menus to enable you to

navigate the content of your discs and to change settings.

To help you navigate the menus, a selection box is placed

over the currently selected menu item.

In the two menu examples below, the pointers on the

box indicate which directions you can navigate with the

cursor buttons on the remote control.

PLAYER FEATURES

Important safety information ..................................................1

Introduction ...................................................................................2

Player features ...............................................................................2

Disc region codes.........................................................................3

Film ratings .....................................................................................3

Controls and connections.........................................................4

Remote control .............................................................................5

HDMI connection .........................................................................6

Composite video (CVBS) and SCART connection .............7

Digital audio connection...........................................................8

Network connection ...................................................................9

Connecting power, loading a disc....................................... 10

Playing Blu-ray or DVD-Video discs .................................... 11

Blu-ray disc special features ..................................................14

BD-Live .......................................................................................... 15

Playing CD audio discs ............................................................ 16

Viewing JPEG digital photos ................................................. 17

Playing WMA music les......................................................... 19

Playing MPEG video les.........................................................21

System settings - overview.................................................... 23

System settings - System category ..................................... 24

System settings - Network category .................................. 25

System settings - Display category..................................... 27

System settings - Audio category........................................ 28

System settings - Language category................................ 29

System settings - Parental category ................................... 30

Troubleshooting ........................................................................ 31

Care and cleaning ..................................................................... 32

Specications.............................................................................. 32

Warranty ....................................................................................... 32

Blu-ray and DVD discs and players are covered by a

worldwide agreement which limits playback of discs

to specic regions as determined by the software

manufacturer. Most discs come marked with a region

coding. A disc specied as playable in one region may not

play on a player designed for a dierent region. A disc

specied as universal or with no region coding may be

played in any region.

The regions are:

Blu Ray discs:

Region A: The Americas and their dependancies, East Asia

(except China and Mongolia) and Southeast Asia.

Region B: Africa, Southwest Asia, Europe (except

Belarus, Russia and the Ukraine), Oceania and their

dependancies.

RegionC:CentralAsia,EastAsia(ChinaandMongoliaonly),

South Asia, Eastern Europe and their dependancies.

DVD Video discs:

Region 1: Canada, USA

Region 2: Europe, Japan, Mid-East, South Africa.

Region 3: South-East Asia.

Region 4: Australia, Caribbean, Central & South America,

New Zealand.

Region 5: Africa, Former Soviet Union, India, North Korea,

Pakistan.

Region 6: China.

THIS PLAYER PLAYS REGION B BLU-RAY AND REGION

2 DVD VIDEO DISCS, ALSO REGION FREE, UNIVERSAL

DISCS.

An international agreement limits playback of discs to

certain age groups as below:

I KID SAFE•

2 G•

3 PG•

4 PG 13•

5 PGR•

6 R•

7 NC17•

8 ADULT•

From the factory, this player is set to play all disc ratings.

Each disc and packaging has information about the

classication of the disc.

If there are children in your house you can restrict viewing

to particular age groups by following the instructions in

the Parental settings Menu on page 30. Once restrictions

are set, access to higher rated content will require a

password.

This player incorporates copyright protection technology

that is protected by method claims of certain U.S.

patents and other intellectual property rights owned by

Macrovision Corporation and other rights owners. Use of

this copyright protection technology must be authorized

by Macrovision Corporation. and is intended for home

and other limited viewing uses only unless otherwise

authorized by Macrovision Corporation. Reverse

engineering or disassembly is prohibited.

The HDMI output of the player has High Denition

HDMIoutputoftheplayertoavideoscreennotsupporting

HDCP technology will downgrade the picture.

Manufactured under license from Dolby Laboratories.

Dolby and the double-D symbol are trade marks of Dolby

Laboratories.

Manufactured under license under U.S. Patent #’s:

5,451,942; 5,956,674;5,974,380; 5,978,762; 6,487,535 &

other U.S. and worldwide patents issued & pending. DTS

is a registered trademark and the DTS logos, symbol and

DTS-HD Advanced Digital Out are trademarks of DTS, Inc.

FILM RATINGSDISC REGION CODES NOTICES

CONTROLS AND CONNECTIONS

FRONT VIEW

Disc loading tray1.

Open/close button2.

Play/pause button3.

Stop button4.

Standby/On button5.

USB dock (under cover)6.

BACK VIEW

Power cord1.

Analogue stereo audio out2.

Analogue composite video out3.

Digital audio out4.

HDMI Digital A/V out5.

RJ45 ethernet connector6.

REMOTE CONTROL

Open/close button1.

Numeric keypad2.

Return button3.

Previous button4.

Next button5.

Play/pause button6.

Step button7.

Repeat A-B button8.

Subtitle button9.

Angle button10.

Popup/Title menu button11.

Up cursor button12.

Right cursor button13.

Down cursor button14.

Volume down button15.

Volume up button16.

Yellow (C) button17.

Blue (D) button18.

Mute button19.

Secondary audio button20.

Picture in picture button21.

Resolution button22.

Red (A) button23.

Green (B) button24.

Setup menu button25.

Audio select button26.

Left cursor button27.

Enter button28.

Disc menu button29.

OSD button30.

Repeat button31.

Zoom button32.

Stop button33.

Fast reverse button34.

Fast forward button35.

Search button36.

Standby/On button37.

When replacing the batteries in the remote control, refer

to the diagram above.

FITTING BATTERIES

1. Press the catch on the battery cover.

2. Lift o the battery cover.

4. Re-t the battery door and clip it in place.

DISPOSAL OF BATTERIES

Dispose of used batteries with regard to the recycling

regulations in your area. Do NOT short circuit batteries or

throw them into water, the general rubbish or in a re.

Weak batteries can leak and damage the remote control.

Replace them in good time!

3. Fit two AAA batteries observing polarity as shown.

When replacing the batteries, use only the same AAA

type specied.

CONNECTING HDMI DIGITAL VIDEO AND AUDIO TO A TV AND (OPTIONAL) SURROUND-SOUND DECODER

HDMI CONNECTION TO A TV

Your Blu-ray player includes dierent connection options.

Digital HDMI connection is recommended for the highest

quality video and audio performance.

If your TV includes HDMI digital connections, connect

an HDMI cable (not supplied) as shown for the highest

quality of picture and sound from your TV.

HDMI CONNECTION TO A SURROUND-

SOUND DECODER

If your audio-visual system includes a separate surround-

sound decoder with HDMI connections, you can use two

HDMI cables (not supplied) to connect your player to the

decoder and then to the TV.

NOTE: It is advisable to check that the settings for HDMI

digital audio are correct for your AV surround decoder.

These can be found in the section‘System settings - audio

category’. Connect to an HDMI input

of the decoder.

ConnectfromtheHDMIoutput

of the decoder to the TV

SURROUND-SOUND

DECODER

CAUTION: Always

disconnect the player,

TV, and any other AV

system components

from the mains before

making or changing

any connections.

CONNECTING ANALOGUE VIDEO, AUDIO AND SCART

SCART CONNECTION TO A TV

If your TV doesn’t have separate audio and video

connections, it may have a SCART audio/visual connector.

To connect to a SCART input you will need a 3-way AV

phono cable and a SCART adaptor (not supplied).

Connect the AV phono cable to the player as shown, then

connect the cable to the adaptor as shown. If the SCART

adaptor includes a switch, set this to ‘IN’. Connect the

SCART adaptor to a free SCART input of the TV.

ANALOGUE AUDIO AND VIDEO

If your TV doesn’t include a digital HDMI connection, it

may have separate composite video (CVBS) and stereo

audio connection.

The input jacks for these connections are normally

coloured yellow (composite video), white (left audio)

and red (right audio). To connect to composite video and

stereo audio you will need a 3-way AV phono cable (not

supplied).

Connect the AV phono cable to the player as shown, then

connect the other end to the TV, matching the coloured

plugs to the coloured sockets on the TV.

White plug

Red plug

Yellow plug

SCART adaptor

3-way AV cable

Connect to a free

SCART input

White plug

Red plug

Yellow plug

3-way AV cable

CAUTION: Always

disconnect the player,

TV, and any other AV

system components

from the mains before

making or changing

any connections.

DIGITAL AUDIO OUTPUT

USING THE DIGITAL AUDIO OUTPUT

Your player also includes a co-axial digital audio

output. You can use this jack to connect digital audio

to a surround-sound decoder that doesn’t have HDMI

connections.

Connect a single digital audio phono interconnect

between the digital audio output of the player and a free

digital audio input of the decoder.

NOTE: Video may be connected to the TV via HDMI or

CVBS (Composite) analogue video out. In the system

illustrated, video and audio are connected to the TV via

the HDMI connection.

NOTE: It is advisable to check that the settings for the

digital audio output are correct for your AV surround

decoder. These can be found in the section ‘System

settings - audio category’.

To a digital

audio input

CAUTION: Always

disconnect the player,

TV, and any other AV

system components

from the mains before

making or changing

any connections.

Indice

Altri manuali Technika Lettore Blu-ray

Technika

Technika BD2CHAW08 Manuale di istruzioni

Manuali Lettore Blu-ray popolari di altre marche

Samsung

Samsung BD-F5900 Manuale utente

Philips

Philips BDP3380K Manuale utente

Samsung

Samsung BD-P4600 Manuale utente

Sharp

Sharp BD-HP17U - AQUOS 1080p Blu-ray DiscTM Player Manuale utente

Pioneer

Pioneer BDP-140 Manuale di installazione e funzionamento

Samsung

Samsung BD-D8200A Manuale utente

LG HLX50W Manuale utente

Sony

Sony BDP-S300 - Blu-Ray Disc Player Manuale utente

Marantz

Marantz UD9004 Manuale utente

Panasonic

Panasonic DMR-HCT230 Manuale utente

LG BD611 Manuale utente

Panasonic

Panasonic Diga DMR-PWT420 Manuale utente

LG BD611 Manuale utente

Marantz

Marantz BD7004 Guida rapida

Kogan

Kogan KABRP3DWFIA Manuale utente

Toshiba

Toshiba BDX2700 Manuale utente

Samsung

Samsung BD-E5400 Manuale utente

Samsung

Samsung BD-F5100 Manuale utente
