Technika LCD19ID-107 Manuale utente
19 LCD TV
LCD19ID-107/207
LCD19ID-107/207
TECHNIKA
19 LCD TV
For Assistance Please Call Our Tesco Electrical
Helpline On 0845 456 6767
Contents
1 Safety and warnings.......................................................................2-5
2 Introduction.................................................................................6-7
3 Installation...................................................................................8-13
4 Remote controler.........................................................................14-16
5 Operation...................................................................................17-19
7 Trouble Shooting.............................................................................25
6 DVB MENU................................................................................20- 24
-1-
IMPORTANT SAFETY INSTRUCTIONS
-2-
1.Read these safety instructions.
2.Keep these safety instructions.
3.Heed all warnings.
4.Follow all safety instructions.
5.Do not use this apparatus near water.
6.Clean only with a dry cloth.
7.Do not block any ventilation openings. Install in accordance with the manufacturers
instructions.
8.Do not install near any heat sources such as radiators,,stoves, or other apparatus
(including
9.Protect the power cord from being walked on or pinched particularly at power outlets,
and the point where they exit from the apparatus.
10.Only use attachments/accessories specified by the manufacturer.
11.Unplug this apparatus during lightning storms or when unused for long periods of time.
12.Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into apparatus, the apparatus has been
exposed to rain or moisture , does not operate n
13.Apparatus must not be exposed to dripping or splashing and no objects filled with
liquids, such as vases, should
amplifiers)that produce heat.
ormally, or has been dropped.
be placed on the apparatus.
IMPORTANT SAFETY INSTRUCTION
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK).NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN!
CAUTION
CAUTION
The symbol indicates that dangerous voltage
constituting a risk of electric shock is present within
this unit.
The symbol indicates that there are important
operating and maintenance instructions in the
literature accompanying this unit.
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
WARNING:
-3-
IMPORTANT SAFETY INSTRUCTION
-4-
WARNINGS AND CAUTIONS
Warning
High voltages are used in the operation of this television
receiver.
Do not remove the cabinet back from your set Refer
servicing to qualified service personnel.
Warning
To prevent fire or electrical shock hazard, do not expose
the television receiver to rain or moisture.
Warning
Do not drop or push objects into the television cabinet
slots or openings. Never spill any kind of liquid on the
television receiver.
Caution
Do not block the ventilation holes in the back cover.
Adequate ventilation is essential to prevent failure of
electrical components.
Caution
Do not power supply cord under the television
receiver.
trap
-5-
WARNINGS AND CAUTIONS
Caution
Never stand on, lean on, or suddenly push the television or its
stand. You should pay special attention to children. Serious
injury may result if it should fall.
Caution
Do not place your television on an unstable cart, stand, shelf or
table.
Serious injury to an individual , and damage to the television,
may result if it should fall.
Caution
When the television receiver is not used for an extended
period of time, it is advisable to disconnect the AC power cord
from the AC outlet.
Avoid exposing the television receiver to direct sunlight and
other sources of heat. Do not stand the television receiver
directly on other product which give off heat. e.g. video
cassette players and audio amplifiers. Do not place naked
flame sources, such as lighted candles on the television.
Caution
If the television is to be built into a compartment or similar
enclosed, the minimum distances must be maintained. Heat
build-up can reduce the service life of your television, and can
also be dangerous.
Caution
Dim:515*320mm(
INTRODUCTION
-6-
Thank you very much for purchasing this TV. To enjoy from the very beginning, read
this manual carefully and keep it handy for easy reference.
INSTALLATION
CAUTION
Locate the TV in the room where light does not strike the screen .
Total darkness or a reflection on the picture screen can cause eyestrain. Soft and
indirect lighting is recommended for comfortable viewing.
Allow enough space between the TV and the wall to permit ventilation.
Avoid excessively warm locations to prevent possible damage to the cabinet or
premature component failure.
This TV can be connected to AC 100-240 Volts. 50/60 Hz. Never connect to a DC
supply or any other power supply.
Do not cover the ventilation openings when using theTV.
directly
Never tamper with any components inside the TV, or any other adjustment controls not
mentioned in this manual. All LCD-TVs are high voltage instruments. When you clean
up dust or water drops on the LCD PANEL or CABINET, the power cord should be
pulled out from the receptacle, then wipe the TV with a dry soft cloth. During thunder
and lighting, unplug the power cord and antenna cord to prevent damage to your TV.
All repairs to this TV should only be performed by the TV service personnel.
-7-
INTRODUCTION
Main features
Used as a Television display terminal or PC display
High luminance,wide viewing angle
Can store 180 TV programs
Translucent OSD
Auto-search
Full function Remote Control
850:1
6
2x1.5V AAA Battery
DVB-T DVB-T
AC Power Cord.........................1
Infrared Remote Controller...... 1
User s Manual ........................ 1
INSTALLATION
Accessories
Front panel
-8-
1
ENTER
2 3
4 5 6
7 8 9 0
+
CH
_
+
_
VOL
POWER MUTE
SWAP
RECALL
TVMENU INPUT
DVBMENU SOUND EXIT
PIC
SLEEP ASPECT
TEXTDISPLAYSOURCE
INFO FAV EPG
REVEAL HOLD LIST INDEX
SUBPAGE SIZE AUDIO SUBTITLE
ON: OFF:
1
1: STANDBY BUTTON: Turn ON/OFF the TV set.
2: Remote control sensor.
3: Indicator LED: GREEN POWER ON.
RED STAND BY.
4: Key board(see next page).
5: AC power switch.
3
2
4
5
30 30
Battery(AAA)............................2
SOURCE
MENU
CH+
CH-
VOL+
VOL-
1 SOURCE
Display the input source menu.
CH+ or CH- to select items in MENU.
2 MENU
3 CH+/CH-
4 VOL+/VOL-
5USB
To display TV MENU.
In TV mode press CH+ or CH- to change the channel up and down.
In DTV mode,it can not change the channel.
In AV,S-VIDEO,YPbPr and SCART mode,it can switch to TV directly.
In MENU,press
Press CH+ or CH- to return the previous mode under Standby status.
Adjust sound level.
In MENU,adjust the item that you selected.
All the terminals are(from left to right):
AC POWER SOCKET,VGA ,PC AUDIO,AV,S-VIDEO,YPbPr,SCART,ANTENNA
Note: AV,S-VIDEO and YPbPr share one audio channel.
INSTALLATION
-9-
KEYBOARD
REAR PANEL CONNECTIONS
SCART
ANTENNA
AV
S-VIDEO
L
R
AUDIO
INPUT YPbPr
INPUT
Y
Pb
Pr
AUDIO
VGA INPUT
VGA INPUT
100-240V~ 50/60Hz
AC-INPUT
SCART
ANTENNA
AV
S-VIDEO
L
R
AUDIO
INPUT YPbPr
INPUT
Y
Pb
Pr
AUDIO
VGA INPUT
VGA INPUT
100-240V~ 50/60Hz
AC-INPUT
USB
USB
USB
