Technisonic Industries Limited TiL-91-DE Manuale utente

VHF/AM MOBILE TRANSCEIVER

Model TiL-91-DE

MOBILE SYSTEM P/N 910200

(TMS-150)

Installation and

Operating Instructions

TiL Document No. 94RE146

Rev. E

JULY 2012

Technisonic Industries Limited

240 Traders Boulevard, Mississauga, Ontario L4Z 1W7

Tel: (905) 890-2113 Fax: (905) 890-5338

www.til.ca

REVISION HISTORY

[ 94RE146 ]

REV SECTION

- PAGE - DESCRIPTION DATE

Edited

n/c Original Document

B Global New Document Template (new file format)

Title page changed, Headers/Footers added

Added Revision page, Added Warranty page FEB 2012 FM

C The 10 channel (memories) will no longer be available

on all 91-DE based radios, ONLY 25.

3-5 Updated sect 3.3 for 10 & 25 channels MAR 2012 FM

D Title Pg Simplify System description

iii Updated FCC information including antenna and

Simplify description under “Warning”

Warranty Information changed "Base Stations" to

"Mobile System".

1-7 Revise Transmitter Characteristics for FCC and

ICAN information JUL 2012 FM

E Clarified 10/25 channel information JUL 2012 SM

iiii

iii

WARNING

Do not make physical contact with antenna when transmitter is on.

CAUTION ! STATIC SENSITIVE !

This unit contains static sensitive devices. Wear a grounded wrist strap and/or conductive gloves

when handling printed circuit boards.

FCC COMPLIANCE INFORMATION

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference and (2) this device must accept any interference

received, including interference that may cause undesired operation.

WARNING: For compliance with FCC RF Exposure Requirements the mobile transmitter

antenna installation shall comply with the following two conditions:

1.The transmitter antenna gain shall not exceed 3 dBi.

2. The transmitter antenna is required to be located outside of a vehicle and kept at a separation distance of 90 cm

or more between the transmitter antenna of this device and person(s) during operation.

NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference, in which case the user will be

required to correct the interference at his/her own expense.

FCC LABELING INFORMATION: When this device is permanently mounted in an enclosure where the

FCC ID label can not be seen, another label must be placed on the outside of the enclosure stating

‘contains FCC ID: IMA90-6R’.

WARRANTY INFORMATION

The Model 91-DE Mobile Transceiver is under warranty for one year from date of purchase. Failed

units caused by defective parts, or workmanship should be returned to:

Technisonic Industries Limited

240 Traders Boulevard

Mississauga, Ontario L4Z 1W7

Tel: (905) 890-2113

Fax: (905) 890-5338

TECHNISONIC INDUSTRIES LIMITED

www.til.ca

TMS-150 91-DE Installation & Operating Instructions TiL 94RE146 Rev E

TABLE OF CONTENTS

SECTION TITLE PAGE

SECTION 1 GENERAL DESCRIPTION

1.1 INTRODUCTION ............................................................................................................... 1-1

1.1.1 Purpose of the System ...................................................................................................... 1-1

1.1.2 Modes Of Operation .......................................................................................................... 1-2

1.2 TECHNICAL SUMMARY .................................................................................................. 1-7

SECTION 2 PREPARATION FOR USE AND STORAGE

2.1 INTRODUCTION ............................................................................................................... 2-1

2.2 TRANSCEIVER LOCATION ............................................................................................. 2-1

2.3 VEHICLE POWER SUPPLY ............................................................................................. 2-1

2.4 POWER INPUT CABLE ASSEMBLY ............................................................................... 2-1

2.5 ANTENNA ASSEMBLY ..................................................................................................... 2-2

2.5.1 Antenna Location .............................................................................................................. 2-2

2.5.2 Antenna Installation ........................................................................................................... 2-2

2.6 MOUNTING BRACKET INSTALLATION .......................................................................... 2-2

2.7 TRANSCEIVER INSTALLATION ...................................................................................... 2-2

2.8 MICROPHONE INSTALLATION ....................................................................................... 2-2

2.9 OPTIONAL EXTERNAL LOUDSPEAKER OR HEADPHONE ......................................... 2-3

2.9.1 External Loudspeaker ....................................................................................................... 2-3

2.9.2 Headset ............................................................................................................................. 2-3

2.10 OPERATIONAL CHECK ................................................................................................... 2-3

SECTION 3 OPERATING INSTRUCTIONS

3.1 INTRODUCTION ............................................................................................................... 3-1

3.1.1 Transceiver Model TiL-91-DE P/N 901006-2 .................................................................... 3-1

3.1.2 Scan Search and Toggle Modes ....................................................................................... 3-1

3.1.3 Technical Summary .......................................................................................................... 3-1

3.2 OPERATOR'S SWITCHES, CONTROLS AND INDICATORS ......................................... 3-1

3.3 FRONT PANEL KEYPAD OPERATION (10 or 25 channel memories) ............................ 3-5

3.3.1 Keypad "Beeps" ................................................................................................................ 3-6

3.3.2 Keypad and LCD Display Lighting .................................................................................... 3-6

3.3.3 Transmitter Time-out ......................................................................................................... 3-6

3.3.4 Selecting a Frequency ...................................................................................................... 3-7

3.3.5 Storing a Frequency to a Channel .................................................................................... 3-8

3.3.6 Recalling a Stored Channel .............................................................................................. 3-8

3.3.7 Transmit Inhibit .................................................................................................................. 3-9

3.3.8 Toggling Between Two Channels ..................................................................................... 3-9

3.3.9 Search Mode ..................................................................................................................... 3-10

3.3.10 Scan Mode ........................................................................................................................ 3-10

3.4 FIXED CHANNEL FREQUENCY SET UP ........................................................................ 3-12

3.4.1 System Configuration ........................................................................................................ 3-12

3.4.2 Transceiver Disassembly/Assembly ................................................................................. 3-12

3.4.3 Operational Check ............................................................................................................ 3-12

WARRANTY ..........................................................................................................................................

TECHNISONIC INDUSTRIES LIMITED

www.til.ca

TMS-150 91-DE Installation & Operating Instructions TiL 94RE146 Rev E

LIST OF FIGURES

FIGURE TITLE PAGE

1.1 Transceiver - General View ...................................................................................................... 1-3

1.2 Transceiver with Mounting Bracket - General View ................................................................. 1-4

1.3 Power Input Cable Assembly - General View .......................................................................... 1-4

1.4 Microphone Assembly - General View ..................................................................................... 1-5

1.5 Antenna Assembly - General View ........................................................................................... 1-6

3.1 Transceiver Front Panel Layout ............................................................................................... 3-2

3.2 Fixed Channel Jumper Locations ............................................................................................. 3-11

LIST OF TABLES

TABLE TITLE PAGE

1.1 Leading Particulars ................................................................................................................... 1-7

3.1 Operator's Switches, Controls and Indicators .......................................................................... 3-3

3.2 Channel/Function Selector Keypad .......................................................................................... 3-5

TECHNISONIC INDUSTRIES LIMITED

www.til.ca

TMS-150 91-DE Installation & Operating Instructions TiL 94RE146 Rev E

1-1

SECTION 1 - GENERAL DESCRIPTION

1.1 INTRODUCTION

VHF/AM Mobile Transceiver System 910200 (Item No. TMS-150), manufactured by Technisonic

Industries Limited, is VHF/AM Transceiver, complete with Mounting Bracket, Power Input Cable,

Microphone and Antenna.

1.1.1 Purpose of the System

(1) Intended Purpose and Use - The transceiver is intended for installation in airport service

vehicles, such as cars, snowplows, and grass cutters, to allow ground control over such

vehicles while they are negotiating aircraft manoeuvring areas.

(2) Brief Description of System Units - VHF/AM Mobile Transceiver System 910200 consists

of the following items:

(a) Transceiver Model 91-DE, Part Number 901006-2, Series 1, is a VHF/AM transceiver

which operates in simplex and allows quick keypad access and LCD display of the

frequency range 117.975 MHz to 138.000 MHz with 25 kHz channel spacing. The

transceiver operates from a 12 volts dc nominal vehicle power supply (negative

ground only). An optional extra cost dc to dc converter P/N 863118-1 can be installed

in the transceiver to allow operation from an input supply from 10.8 to 30.0 VDC. A

general view of the transceiver is given in Figure 1.1. The transceiver is normally

located under the dashboard of a vehicle using a mounting bracket and mounting

hardware.

(b) Mounting Bracket, Part Number 913053-1, is a U-shaped aluminium alloy bracket

which, together with items of hardware included in the Mounting Hardware Kit P/N

869024-1, is used to mount the transceiver under the dashboard of a vehicle.

A view of the transceiver with mounting bracket is given in Figure 1.2.

core cable terminated at one end by a two-pin, female contacts, connector, which

mates with the two-pin, male contacts, connector located at the left-rear of the

transceiver. The unterminated end of the cable is connected to the 12 VDC vehicle

power supply negative-ground during installation.

A view of the cable assembly is given in Figure 1.3.

(d) Microphone Assembly, Part Number 961070-1, consists of a Microphone and a

mounting bracket, P/N RK6MB.

A general view of the microphone assembly is given in Figure 1.4.

The microphone is a rugged hand-held microphone housed in a high impact plastic case

which includes a rear case hang-up button for storage on the mounting bracket. The

dynamic microphone is a noise cancelling type with a pre-amplifier, press-to-talk switch,

and a retractable three-cord cable terminated by a three-pin male contacts, connector

which mates with the MIC/PTT connector located on the front panel of the transceiver.

The microphone dc supply for the microphone is supplied by the transceiver. The

mounting bracket, provided with the microphone, should be mounted in a convenient

location near the transceiver. A small screwdriver which can be used for releasing the

modular plug located in the microphone head is supplied with the microphone.

TECHNISONIC INDUSTRIES LIMITED

www.til.ca

TMS-150 91-DE Installation & Operating Instructions TiL 94RE146 Rev E

1-2

A replacement plug-in microphone cord, P/N 963299-1 is available for this microphone.

This cord is supplied with a modular microphone plug on one end and a three pin DIN

connector on the other to mate with the Model 91-DE Transceiver.

(e) Antenna Assembly, Part Number 861910-1, is supplied complete as a kit which

includes the following items: Antenna Base, which includes a mounting pad, together

with a pad, braid nut, sleeve and clamp for termination of the antenna RF cable. The

Antenna Rod is supplied with an Allen Wrench for adjustment of its set screws. The

Antenna RF Cable is a ten metre length RG58/U coaxial cable terminated at one end

by an UHF, male contact, connector which mates with the UHF, female contact,

antenna connector located at the right-rear of the transceiver. The antenna may be

mounted on any flat surface, roof, cowl, fender or rear deck of a vehicle, however,

rooftop mounting is recommended for best performance. A general view of the

antenna assembly is given in Figure 1.5.

1.1.2 Modes of Operation

The transceiver may be operated in either of two modes; transmit or receive, as selected by the

Press-to-Talk (PTT) switch on the microphone.

(1) TRANSMIT MODE - When the PTT switch on the microphone is pressed, the transceiver

operates in the transmit mode. The PTT signal line is grounded by the microphone PTT switch via

the microphone lead and the MIC/PTT connector to the transceiver. The Tx ON amber LED will

go ON, indicating that the transmitter is activated.

Transmission will occur on the channel frequency indicated on the front panel. Refer to Section 3

for transceiver details

(2) RECEIVE MODE - When the PTT switch on the microphone is released, the transceiver

operates in the receive mode. The Tx ON amber LED will go OFF, indicating that the transmitter

is inhibited. Reception of the frequency displayed on the transceiver will occur.

The setting of the SQUELCH CONTROL determines the squelch threshold level. When the

SQUELCH CONTROL is rotated in the counter-clockwise direction, the SQUELCH INDICATOR

green LED will go ON, indicating that the squelch circuit is connecting the demodulated audio to

the VOLUME CONTROL. The setting of the VOLUME CONTROL determines the audio level

produced from the internal speaker. When the VOLUME CONTROL is adjusted in the clockwise

direction, the audio level will increase.

NOTE

When the connector of the external loudspeaker or head

phone is connected to the SPEAKER/PHONE jack, the

internal loudspeaker is disconnected and the VOLUME

CONTROL will control the audio level of the external

loudspeaker or headphone.

Altri manuali per TiL-91-DE

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Technisonic Industries Limited Ricetrasmettitore

Technisonic Industries Limited

Technisonic Industries Limited TiL-90-6R/8.33 Manuale utente

Technisonic Industries Limited

Technisonic Industries Limited TFM-556 Manuale utente

Technisonic Industries Limited

Technisonic Industries Limited TiL-90-6R Manuale utente

Technisonic Industries Limited

Technisonic Industries Limited TFM-550 Manuale

Technisonic Industries Limited

Technisonic Industries Limited TFM-138 Manuale utente

Technisonic Industries Limited

Technisonic Industries Limited TDFM-9300 Manuale utente

Technisonic Industries Limited

Technisonic Industries Limited TFM-138 Manuale

Technisonic Industries Limited

Technisonic Industries Limited TDFM-136 Manuale utente

Technisonic Industries Limited

Technisonic Industries Limited TFM-403 Manuale

Technisonic Industries Limited

Technisonic Industries Limited TFM-138A Manuale utente

Technisonic Industries Limited

Technisonic Industries Limited TFM-30 Manuale

Technisonic Industries Limited

Technisonic Industries Limited TFM-550 Manuale utente

Technisonic Industries Limited

Technisonic Industries Limited TFM-30 Manuale utente

Technisonic Industries Limited

Technisonic Industries Limited AS-350 Manuale utente

Technisonic Industries Limited

Technisonic Industries Limited TDFM-9100 Manuale utente

Technisonic Industries Limited

Technisonic Industries Limited TDFM-136B Manuale utente

Technisonic Industries Limited

Technisonic Industries Limited TDFM-6000 Manuale utente

Technisonic Industries Limited

Technisonic Industries Limited TFM-566 Manuale utente

Technisonic Industries Limited

Technisonic Industries Limited TDFM-136 Manuale utente

Technisonic Industries Limited

Technisonic Industries Limited TiL-91-DE/8.33 Manuale utente

Technisonic Industries Limited

Technisonic Industries Limited TFM-500 Manuale

Technisonic Industries Limited

Technisonic Industries Limited TDFM-136 Manuale

Technisonic Industries Limited

Technisonic Industries Limited TFM-530 Manuale utente

Technisonic Industries Limited

Technisonic Industries Limited T3018 Manuale utente

Manuali Ricetrasmettitore popolari di altre marche

Yaesu

Yaesu FT-7B Manuale utente

Kenwood

Kenwood ProTalk TK-3201 Manuale utente

Texas Instruments

Texas Instruments TLK10232 Manuale utente

Mizuho

Mizuho MX-2 Guida del prodotto

Kenwood

Kenwood TK-3180 Manuale operativo e di manutenzione

Blitz

Blitz MJ-398U Manuale utente

Utilicom

Utilicom LongRanger 2050 Manuale utente

Standart

Standart HX290UKA Manuale utente

Altronix

Altronix Pace1PTM Manuale utente

Kirisun

Kirisun PT2208 Manuale utente

ELECRAFT

ELECRAFT KX2 Manuale utente

Zodiac

Zodiac K3 Manuale utente

Assa Abloy

Assa Abloy SecureComm HKC GSM-WIFI U Manuale utente

Kenwood

Kenwood TK-2217 Manuale utente

Siemens

Siemens PSO 4000 Manuale utente

Kenwood

Kenwood TS-590SG Manuale utente

Midland

Midland G8E-BT Manuale

ComNav

ComNav Mariner X2 Manuale utente
