Technoline WIRELESS 433 MHz WEATHER CLOCK Manuale utente

WIRELESS 433 MHz WEATHER CLOCK

Instruction Manual

INTRODUCTION:

Congratulations on purchasing this fancy Weather clock with wireless 433MHz

transmission of outdoor temperature and display of indoor temperature and humidity. It is

further acting as a DCF-77 radio controlled clock with calendar display and alarm clock

function. In addition, sunrise/ sunset/ sun duration time as well as the moon phase are

shown. With the totally 15 different weather forecast icons featured by "weather man",

users can easily observe the forecast weather condition and will no longer worry the

sudden weather change. This innovative product is ideal for use in the home or office.

FEATURES:

The Weather clock

Foldout

Stand

Battery

compartment cover

Function

Keys

LCD Display

Function

Keys

DCF-77 Radio controlled time with manual setting options

DCF Time reception ON/OFF

12/24 hour display

Hour, minute and second time display

Calendar (weekday, date, month and year)

Time zone option ±12 hours

Alarm with snooze function

Snooze setting

Weather forecasting with 15 easy-to-read weather forecast signs featured by

weather man

Weather forecasting icon sensitivity setting

Temperature display in degrees Celsius (°C) or Fahrenheit (°F) selectable

Indoor and outdoor temperature display with MIN/MAX recording

Indoor humidity reading displayed as RH% with MIN/MAX recordings

All MIN/MAX temperature recordings show date and time received

All MIN/MAX recordings can be reset

Display of sunrise time, sunset time and sun duration in 28 cities

12 Moon phases display throughout the year

Can take up to three outdoor transmitters

LCD contrast setting

LED backlight

Table standing/ Wall mounting

The Outdoor Temperature Transmitter

Remote transmission of outdoor temperature

to Temperature Station by 433 MHz

Holder Shower proof casing

Wall mounting case

Mounting at a sheltered place. Avoid direct

rain and sunshine

HOW TO INSTALL AND REPLACE BATTERIES IN THE WEATHER CLOCK

The Weather clock uses 2 x AA, IEC LR6, 1.5V batteries. To install and replace the

batteries, please follow the steps below: 1. Remove the cover at the back of the

Weather clock.

2. Insert batteries observing the correct

polarity (see marking).

3. Replace compartment cover.

HOW TO INSTALL AND REPLACE BATTERIES IN THE TEMPERATURE

TRANSMITTER

The Temperature transmitter uses 2 x AA, IEC LR6, 1.5V batteries. To install and replace

the batteries, please follow the steps below:

1. Remove the battery cover.

2. Insert the batteries, observing the correct polarity (see

marking).

3. Replace the battery cover on the unit.

Note:

In the event of changing batteries in any of the units, all units need to be reset by

following the setting up procedures. This is because a random security code is assigned

by the transmitter at start-up and this code must be received and stored by the Weather

clock in the first 3 minutes of power being supplied to it

SETTING UP:

1. First, insert the batteries into the Weather clock (see “How to install and replace

batteries in the Weather clock”). Once the batteries are in place, all segments of

the LCD will light up briefly and a short signal tone will sound. Following some test

data display, the indoor temperature and humidity, the time as 0:00 the date as 1.1.

05 and the "weather man" icon will be displayed. If the indoor temperature and

humidity are not displayed after 30 seconds, remove the batteries and wait for at

least 10 seconds before reinserting them. Once the indoor data is displayed

proceed to step 2.

2. Immediately after and within 3 minutes of activating the Weather clock, place the

batteries into the transmitter (see “How to install and replace batteries in the

Temperature transmitter“).

3. After inserting the batteries into the transmitter, the Weather clock will start

receiving data from the transmitter. The outdoor temperature should then be

displayed on the Weather clock. If this does not happen after 15 minutes, the

batteries will need to be removed from both units and reset from step 1.

4. The Weather clock can take up to 3 remote transmitters. If you have purchased

additional transmitters, follow step 2 for all extra transmitters. However, ensure that

you leave 10 seconds in between the reception of the last transmitter and the set-

up of the following transmitter. The Weather clock will number the transmitters in

the order of set-up, i.e. the first transmitter will have the temperature displayed with

the number 1 against it and so on.

5. Before all the transmitters are set up, there is a testing period, during which the

display switches quickly between all the received transmitters at random, according

to which random transmission it receives. Pressing any key will stop this process.

The process also stops automatically if up to 3 transmitters are received or no keys

are pressed for a few minutes.

6. Once the remote temperature has been received and displayed on the Weather

clock, the DCF-77 time code reception is automatically started. This takes typically

between 3-5 minutes in good conditions. This time period is an excellent

opportunity to locate the transmitter(s) in suitable location(s) outdoors. In order to

ensure sufficient 433 MHz transmission however, this should under good

conditions be no more than 100 meters from where the Weather clock will be finally

positioned (see notes on “Positioning the temperature transmitter” and “433

MHz Reception”).

7. If after 10 minutes, the DCF time has not been received, use the SET key to

manually enter a time initially The clock will automatically attempt to receive the

DCF time at each full hour. When this is successful, the received time will override

the manually set time. The date is also updated with the received time. (Please

refer also to notes on “DCF-77 Radio controlled Time” and “Manual Time

Setting”).

BATTERY CHANGE:

It is recommended to replace the batteries in all units on an annual basis to ensure

optimum accuracy of these units.

Please participate in the preservation of the environment.

Return used batteries to an authorized depot.

FUNCTION KEYS:

Weather clock:

The Weather clock has five easy to use function keys.

SNOOZE/ SUN key

SET key

MIN/

MAX key

ALM key

CH/ + key

SET key (Setting):

To enter the set mode for the following functions: LCD contrast, Time zone, Time

Reception ON/OFF, 12/24 hour display, Manual time, Year, Date, Sunrise/ sunset

city location, Snooze time duration, °C/°F, and Weather forecast sensitivity settings.

To toggle between the display of "Weekday + date + month", "Second", "Alarm

time", and "Date + month + year"

To press and hold for 3 seconds to reset at the same time the maximum/ minimum

temperature and humidity records of indoor and the currently selected outdoor

channel (will reset all records to current level)

To stop the alarm

To switch on the backlight

MIN/ MAX

To toggle between the maximum/ minimum outdoor temperature and maximum/

minimum indoor temperature and humidity data

Note: The Time/date shown is corresponding to MIN/MAX temperature data.

To stop the alarm

To switch on the backlight

ALM key (alarm)

Press for about 3 seconds to enter the Alarm setting mode

To activate/ deactivate the alarm

To stop the alarm

To switch on the backlight

CH/ + key

To toggle between the Outdoor transmitters 1, 2 and 3 (if more than 1 transmitter is

used)

To adjust LCD contrast, time zone, Time Reception ON/OFF, 12/24 hour display,

hour, minute, year, month, day, snooze time duration, °C/ °F and weather

forecasting icon sensitivity in setting modes

To adjust the alarm time in alarm setting mode

To stop the alarm

To switch on the backlight

SNOOZE/ SUN key

To activate the snooze function for the alarm

To toggle between the sunrise time, sunset time, sun duration in the Sun display

To exit manual setting mode and alarm setting mode

To switch on the backlight
