EQ5 AC Drive Operations Manual

Document: TWMC-EQ5OM

Revision: 001P0

EQ5 AC Drive Operations Manual

_______________________________________________________________________

TECO – Westinghouse Motor Company Compliance with UL

Preface

Thank you for purchasing our EQ5 series inverter. This product is used to drive a 3-phase electric motor at

variable speed. As incorrect use of this product may result in personal injury and/or property damage,

please read all safety and operating instructions before using.

Safety Instructions

Please read this manual carefully before installing, connecting (wiring), operating, servicing, or inspecting the

inverter. Also please familiarize yourself with all safety features before using the inverter.

In this manual, safety messages are classified as follows:

Danger Improper operation may result in serious personal injury or death.

Caution Improper operation may result in slight to medium personal injury or property

damage.

Situations more serious than those covered by CAUTION will depend on prevailing circumstances.

Always follow instructions.

Instructions on use:

Danger

•This inverter is designed to drive a 3-phase induction motor and is not suitable for a single-phase motor or

any other types, as fire may result.

•This inverter may not be used (as is) as a component of a life-support system or other medical device

directly affecting the personal welfare of the user.

•This inverter is manufactured under strict quality control standards. However, safety equipment must be

installed if the failure of this device may result in personal injury and/or property damage.

•There is a risk of accident.

Instructions on installation:

Danger

•Mount this inverter on an incombustible material such as metal. There is a risk of fire.

•Do not place combustible or flammable material near this inverter, as fire may result.

Caution

•Do not hold or carry this inverter by the surface cover. Inverter may be dropped causing injury.

•Ensure that the inverter and heat sink surfaces are kept free of foreign matter (lint, paper dust, small chips

of wood or metal, and dust), as fire or accident may result.

•Do not install or operate a damaged inverter or an inverter with missing parts, as injury may result.

EQ5 AC Drive Operations Manual

_______________________________________________________________________

TECO – Westinghouse Motor Company Compliance with UL

Instructions on wiring:

Danger

•Connect the inverter to power via a line-protection molded-case circuit breaker or fuse, otherwise fire may

result.

•Always connect a ground wire, otherwise electric shock or fire may result.

•A licensed specialist must perform the wiring, otherwise electric shock may result.

•Turn off the power before starting the wiring, otherwise electric shock may result.

•Wire the inverter after installation is complete, otherwise electric shock or injury may occur.

Caution

•Confirm that the phases and rated voltage of this product match those of the AC power supply, otherwise

injury may result.

•Do not connect the AC power supply to the output terminals (U,V,and W), otherwise injury may result.

•Do not connect a braking resistor directly to the DC terminals (P(+)and N(-)),otherwise fire may result.

•Ensure that the noise generated by the inverter, motor, or wiring does not adversely affect peripheral

sensors and equipment, otherwise accident may result.

Instructions on operation:

Danger

•Be sure to install the surface cover before turning on power (closed). Do not remove the cover while

power to the inverter is on. Otherwise electric shock may occur.

•Do not operate switches with wet hands, otherwise electric shock may result.

•When the retry function is selected, the inverter may restart automatically after tripping. Design the machine

to ensure personal safety in the event of restart. Accident may result.

•When the torque limiting function is selected, operating conditions may differ from preset conditions

(acceleration/deceleration time or speed). In this case, personal safety must be assured. Otherwise

accident may result.

•As the STOP key is effective only when a function setting has been established, install an emergency

switch independently, and when an operation via the external signal terminal is selected, the STOP key on

the keypad panel will be disabled. Otherwise accident may result.

•As operations start suddenly if an alarm is reset with a running signal input, confirm that no running signal

is input before resetting alarm. Otherwise accident may result.

•Do not touch inverter terminals when energized even if inverter has stopped. Otherwise electric shock

may result.

Caution

•Do not start or stop the inverter using the main circuit power. Failure may result.

•Do not touch the heat sink or braking resistor because they can be extremely hot. Burns may result.

•Carefully check the performance of motor or machine before operating at high speed. Injury may result.

•Do not use the inverter braking function for mechanical holding. Otherwise injury may result.

EQ5 AC Drive Operations Manual

_______________________________________________________________________

TECO – Westinghouse Motor Company Compliance with UL

Instructions on maintenance, inspection, and replacement:

Danger

•Wait a minimum of five minutes (30HP/CT, 40HP/VT or less) or ten minutes (40HP/CT, 50HP/VT or more)

after power has been turned off (open) before starting an inspection. (Also confirm that the charge lamp is

off and that DC voltage between terminals P (+) and N (-) does not exceed 25V.) Otherwise electrical

shock may result.

•Only authorized personnel should perform maintenance, inspection, and replacement operations.(Take off

metal jewelry such as watches and rings and use insulated tools.) Otherwise electric shock or injury

may result.

Instructions on disposal:

Caution

•Treat as industrial waste when disposing it. Otherwise injury may result.

Other instructions:

Danger

•Never modify the product. Otherwise electric shock or injury may result.

EQ5 AC Drive Operations Manual

_______________________________________________________________________

TECO – Westinghouse Motor Company Compliance with UL

Compliance with UL/cUL standards [Applicable to products with UL/cUL mark]

Caution

Tightening torque and wire range: Refer to Table 2-3-5 in Section 2

Apply the following power supply specifications to the inverter:

Inverter Model Maximum input voltage Input source current

EQ5 - 20P2 - N1 to EQ5 - 2032 - N1 AC240V Not more than 100,000A

EQ5 - 2040 - C to EQ5 - 2150 - C

EQ5 - 40P5 - N1 to EQ5 - 4032 - N1 AC480V

EQ5 - 4040 - C to EQ5 - 4800 - C

Caution

* [CAUTION] Hazard of electrical shock. Disconnect incoming power before working on this control.

* [CAUTION] Dangerous voltage exists until charge light is off.

* [WARNING]

* More than one live parts inside the inverter.

* Type1 “INDOOR USE ONLY”

The inverter is approved as a part used inside a panel. Install it inside a panel.

* Suitable for use on a circuit capable of delivering not more than 100,000rms symmetrical amperes.

* Use 60/75C copper wire only.

* A Class2 circuit wired with class1 wire.

* Field wiring connections must be made by a UL Listed and CSA Certified closed-loop terminal connector

sized for the wire gauge involved. Connector must be fixed using the crimp tool specified by the

connector manufacturer.

* Connect the power supply to main power supply terminals via the Molded-case circuit breaker (MCCB) or

a ground fault circuit interrupter (GFCI) to conform to the UL Listing Mark.

(See Instruction Manual basic connection diagram Fig.2-3-1).

* When using auxiliary control-power input (R0, T0), connect as per Basic connection diagram Fig.2-3-1.

* Solid state motor overload protection is provided in each model.

EQ5 AC Drive Operations Manual

_______________________________________________________________________

TECO – Westinghouse Motor Company Index

Contents

Pg.

Before Using This Product ···························· 1

1-1 Receiving Instructions ·························· 1

1-2 Appearance ······································· 1

1-3 Handling the Product ·························2-3

1-4 Carrying and Moving the Product ··········· 3

1-5 Storage ··········································3-4

2. Installation and Electrical Connections ·········· 5

2-1 Operating Environment ························ 5

2-2 Installation Method ····························5-7

2-3 Electrical Connections ························· 8

2-3-1 Basic Power Electrical Connections ·· 8

Fig. 2-3-1 Basic Wiring Diagram.................9

2-3-2 Connecting Input power, Motor and

Ground Terminals ···················10-16

2-3-3 Connecting the Control Terminals 17-21

2-3-4 Input Protection Device Ratings·······22

2-3-5 Terminal Tightening Torque and

Cable Size ·································23

2-3-6 DC Link Choke Wattage Loss…….....24

3. Initial Operation ······································25

3-1 Inspection and Preparation Before

Operation··········································25

3-2 Operation Method ······························25

3-3 Trial Run ······································25-26

4. Digital Operator ······································27

4-1 Appearance of Digital Operator ·········27-28

4-2 Digital Operator LCD screen,

Level Structure ···································28

4-2-1 Normal Operation ························28

4-2-2 Alarm Modes ··························28-29

4-3 Digital Operator Keypad Navigation ·······30

4-3-1 Operation Mode ··························30

4-3-2 Setting the Output Frequency ·········30

4-3-3 Switching to the LED Monitor ·········31

4-3-4 Program Menu Screen ··················31

4-3-5 Setting the Parameter Values ·····32-33

4-3-6 Checking Parameter Data ·············33

4-3-7 Monitoring Operating Status ···········33

4-3-8 I/O Check ··································34

4-3-9 Maintenance Information ···············35

4-3-10 Load Rate Measurement ·············36

4-3-11 Alarm Information ·······················37

4-3-12 Alarm History and Possible

Reasons ···································38

4-3-13 Data Copy, Verify and Error

Processing ···························39-40

4-3-14 Alarm Mode ······························41

Pg.

5. Parameters F,E,C,P,H, A and U·················· 42

5-1 Parameter Summary List ·················42-45

5-2 Parameter Explanation ···················46-86

6. Alarms Codes, Causes and Troubleshooting · 87

6-1 List of Alarm Codes and Causes ·······87-88

6-2 Alarm Reset ····································· 89

6-3 Troubleshooting Alarm Codes and

Causes (Flowcharts)………….….……...90-96

7. Maintenance and Inspection ······················ 97

7-1 Daily Inspection ································· 97

7-2 Periodic Inspection ························97-99

Inspection Notes and Records..................100

7-3 Main Circuit Voltage, Current and Power

Measurements…………………………......101

7-4 Insulation Test ·································102

7-5 Parts Replacement ···························102

7-6 Inquiries about Damaged Products ·······103

7-7 Warranty…………………………………….

8. Specifications ········································104

8-1 Standard Specifications ···············104-106

8-2 Common Specifications ·····················107

8-3 Outline Dimensions and Weights ···108-111

8-4 RS-485 Modbus RTU Serial

Communications ·······························112

8-4-1 Transmission Specification············112

8-4-2 Connection································112

8-4-3 Serial Interface Configuration·········112

8-4-4 Modbus RTU Functions················112

8-4-5 Inverter Function Code Access ······113

8-4-6 Command and Monitor

Data Registers······················113-115

8-4-7 Data Format Specification·······115-119

8-4-8 Communication Errors··················119

9. Options ················································120

10. Electromagnetic Compatibility (EMC) ········121

10-1 General ········································121

10-2 Recommended Installation

Instructions ····························121-124

EQ5 AC Drive Operations Manual

_________________________________________________________________________

TECO – Westinghouse Motor Company Receiving and Handling 1

1. Before Using This Product

1-1 Receiving Instructions

Unpack and check the product as explained below.

If you have any questions about the product,

contact the nearest TWMC sales office or your

local distributor where you purchased the unit.

1. Check the ratings on the nameplate to confirm

that the delivered product is the one that was

ordered.

TYPE : Inverter type

SOURCE : Power rating

OUTPUT : Output rating

MASS : Mass (not indicated for products with 30HP/CT, 40HP/VT or less)

SER.No. : Serial number

8 5 XXXXXXXXXXXXX

Productionlotserialnumber

Production month:1 to 9: January to September,

X: October, Y: November, Z: December

Production year: Last digit of year (7 --> 2007)

2. Check for damaged and/or missing parts.

3. In addition to the drive unit and this manual, the package contains rubber bushings (for products of

30HP/CT, 40HP/VT or less) and a terminating resistor (1/2 W, 120) which is packed separately. The

terminating resistor for products rated 40HP/CT, 50HP/VT or more, is installed internally. The

terminating resistor is required for RS485 communication and can remain installed regardless of RS-

485 communication status.

1-2 Appearance

Mounting screws of surface cover

Digital Operator Digital Operator

Mounting screws of

surface cover

(6 screws total)

Ratings nameplate

Surface cover

Intermediate cover

Surface cover

30HP/CT, 40HP/VT or Less 40HP

CT, 50HP/VT or More

EQ5 AC Drive Operations Manual

_________________________________________________________________________

TECO – Westinghouse Motor Company Receiving and Handling 2

1-3 Handling the Product

1. Removing the cover

For drives rated 30HP/CT, 40HP/VT or less, loosen the mounting screws of the cover, then remove by

pulling the top (see Fig. 1.3.1).

Fig. 1-3-1 Removing the Surface Cover (for inverters rated 30HP/CT, 40HP/VT or less)

For drives of 40HP/CT, 50HP/VT or more, first remove the six mounting screws, then remove the cover

(see Fig. 1-3-2).

Fig. 1-3-2 Removing the Surface Cover (for inverters rated 40HP/CT, 50HP/VT or more)

2. Removing the digital operator

After removing the cover as explained in (1.), loosen the mounting screws of the digital operator and

remove as shown in Fig.1.3.3.

Fig. 1-3-3 Removing the Digital Operator (30HP/CT, 40HP/VT or less)

EQ5 AC Drive Operations Manual

_________________________________________________________________________

TECO – Westinghouse Motor Company Receiving, Handling, and Storage 3

Temporary Storage

For drives 40HP/CT, 50HP/VT or more, loosen the mounting screws of the digital operator and remove

using the finger holds on the digital operator case (see Fig. 1-3-4).

Fig. 1-3-4 Removing the Digital Operator (40HP/CT, 50HP/VT or more)

1-4 Carrying and Moving the Product

1. Carry the product by the main body.

Do not carry the product while holding the cover or parts other than the main body.

2. Use a crane or hoist to carry a product equipped with handling hooks.

1-5 Storage

Temporary storage of this product must meet those conditions listed in Table 1-5-1.

Table 1-5-1 Storage Environment

Item Specifications

Ambient

temperature -10 (14°F) to +50 (122°F)

Condensation or freezing must not occur as

a result of sudden temperature changes.

Storage

temperature -25 (-13°F) to +65 (149°F)Note1

Relative

humidity 5 to 95% Note2

Atmosphere

The product must not be exposed to dust, direct sunlight, corrosive gas, oil

mist, vapor, or water. There must be a minimum salt content in the

atmosphere. Do not store where condensation may occur as a result of

sudden changes in temperature.

Note1: The storage temperature applies only to short periods of time such as when transporting

the equipment .

Note2: As a large change in temperature within this humidity range may result in condensation or freezing,

do not store where such temperature changes may occur.

1. Do not place this product directly on a floor.

2. To store the product in an extreme environment, pack in vinyl sheeting, etc.

3. If the product is stored in a high-humidity environment, insert a drying agent (e.g., silica gel)

and pack the product in vinyl sheeting.

EQ5 AC Drive Operations Manual

_________________________________________________________________________

TECO – Westinghouse Motor Company Receiving, Handling, and Storage 4

Long-term Storage

If the product is to be stored for an extended period of time after purchase, the method of storage depends

primarily on storage location.

The general long-term storage method is as follows:

1. The above conditions for temporary storage must be satisfied.

When the storage period exceeds three months, the upper limit of ambient temperature must

be reduced to 30º (86ºF) to prevent the deterioration of the electrolytic capacitors.

2. Pack the product thoroughly to eliminate exposure to moisture and include a drying agent to

ensure a relative humidity of about 70% or less.

3. If the product is mounted on equipment or a control panel and is not being unused and is exposed to

the elements such as like moisture or dust (particularly on a construction site), remove the product and

store in a suitable environment.

4. Electrolytic capacitors not provided with voltage for extended periods of time will deteriorate. Do not

store electrolytic capacitors longer than one year without providing voltage to them.

NOTES

Questo manuale è adatto per i seguenti modelli

Indice

Manuali Controllori popolari di altre marche

Digiplex

Digiplex DGP-848 Istruzioni operative

YASKAWA

YASKAWA SGM series Manuale utente

Sinope

Sinope Calypso RM3500ZB Manuale utente

Isimet

Isimet DLA Series Style 2 Manuale di installazione

LSIS

LSIS sv-ip5a Manuale utente

Rockwell Automation

Rockwell Automation 1769-L31 Manuale utente

Airflow

Airflow Uno hab Manuale utente

ABB

ABB ACS580-01 drives Manuale utente

Panasonic

Panasonic GM1 Series Manuale utente

Emerson

Emerson SW93 Manuale utente

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuale utente

Panasonic

Panasonic FP? Positioning Unit RTEX Manuale utente

Samson

Samson Type 5824 Manuale di servizio

Alpha IP

Alpha IP MIOB 21001 Manuale utente

Siemens

Siemens OpenAir GMA 1 Series Manuale utente

Surecom

Surecom SR-629 Manuale utente

Fishman

Fishman TriplePlay Manuale utente

Regulus

Regulus SRS1 T Manuale utente
