TeleEye RV432 Manuale utente

c 2005-2006

Mobile Digital Video Recorder with

Advertisement/ Multimedia

Playback

Instruction Manual

TABLE OF CONTENTS

Section Page

I. Product Components and Features 3

II. Installation Guidelines 4

II.1 Installation Environment Requirements 4

II-2 Mounting / Enclosing the MDR 4

II-3 Installation Parts and Materials Required 5

II-4 MDR Product Views 5

II-5 MDR Dimension 6

II-6 MDR Package Contents 7

II-7 MDR Installation Location Guidelines 8

II-8 MDR Installation Instructions 9

II-9 MDR Installation Layout 10

II-10 MDR Bridal Connection Guideline 11

II-11 MDR Visual Orientation 14

II-12 Handheld IR Remote Controller Functions 16

III. System Start-up/ Shut down 19

IV. MDR system layout 21

IV-1 Multimedia Management 21

A) Advertisement 21

B) Music 22

C)Movie 23

IV-2 Playback Management 24

A) Search – Normal Recorded Playback 24

B) Search – Event Recorded Playback 26

V. System Setup Management 27

V-1 System Setup 27

A) Date/Time 28

B) General 29

C) Video Type 31

D) Audible Alarm 32

E) Priority Record 33

F) HDD O/W 34

G) HDD Format 35

H) Network 37

I) Security 38

J) Default Setup 40

K) USB Operation 42

L) Driver Info 43

V-2 Camera Setup 44

V-3 Recording Schedule 46

V-4 Event Setup 47

V-4-1 Sensor Menu 47

V-4-2 Motion Detect Menu 49

V-5 PTZ Setup 50

V-6 System Information: 51

VI. System Firmware Upgrade Procedure 53

VII. Compact Flash Card management 54

VIII. Hard Disk File Structure 57

IX. GPS Operation (Optional) 58

Appendix A 59

MDR Manual

I. Product Components and Features

System Recording Module and Mounting Assembly

zUltra compact case, extremely low weight, high temperature resistance, and vibration resistant

zLow-Voltage, low-current architecture suitable for mobile mounting or fixed locations

zQuick-Release removable Recording Module with tamperproof lock and secure controls

zFlexible Mounting Assembly for permanent connection to vehicle or permanent installation

zIndividual wire connections for audio, video, power, inputs/outputs, and accessory assemblies

z12v, 3Amp regulated power for use with cameras, inputs/outputs, and accessory assemblies

zFull support for NTSC or PAL video inputs and outputs, audio channels, VGA display

zCommunications supported through TCP/IP network interface and USB connection to PCs

zHand-held, IR controller with On-Screen Display (OSD) for all operations of the MDR

z2.5-in. mobile anti-vibration and shock resistance HDD

Video and Audio DVR Features and Capabilities

z4 channels for video input, full-motion (30FPS/camera) continuous or priority video recording and live

display

z4 channels for high-fidelity, digitally recorded, synchronized audio matched to 4 video channels

zContinuous recording while in the playback mode

zUser friendly criteria to playback the events associated video only

zAutomatic timer to resume the live display if the unit is idle for user defined timings

zMPEG-4 video compression for high quality, low storage recording and playback

zUser-selectable settings for quality and audio record enable/disable for each video channel

z12v power supply for multiple devices such as cameras, sensors, relays and any other accessories

zSelectable frame rate with event-triggered burst recording speeds up to 30FPS/camera

zMultiple alarm inputs with selectable pre-alarm and post-alarm record timings

zTV output channel for live video and recorded video viewing

Streaming Video Output for Multimedia Contents

zDVD-quality steaming audio/video with NTSC or PAL composite or VGA output

zFlash card, USB media update

zIndependent operation of DVR and streaming advertising simultaneously

Remote Connection Capabilities

zHandheld Infra-Red controller with OSD for quick access to recorded video and settings menus

zUSB connection for file transfer, PC-based file transfer and settings management

zPC-Based Client software for live viewing, playback video, playback events associated video, and

downloading capabilities

zSupport CMS (Central Management System), Auto download program, Analysis program;

Accessory Modules for MDR

zVideo Interface Module including GPS location and speed

zVehicle Motion Manager includes 3-axis inertia sensor to determine video-matched motion events

zVideo event search allows intelligent searching of recorded video based on event logs

MDR Manual

II. Installation Guidelines

II-1 Installation Environment Requirements

In order to ensure the reliable operation of your Mobile Digital Recorder (MDR) within the terms of the product

warranty, follow these instructions for installing your MDR

a) Follow all electrical codes, adhere to all requirements for your vehicle and for other connected

equipment while installing and operating the MDR.

b) Use only a regulated 12-volt DC or 24-volt DC (2 ~ 3 Amps) certified power supply for installation in

vehicles. The MDR can handle power ranges from 7v ~ 28v DC. Follow the installation and

operating instructions provided to ensure a steady and reliable source of installation. Handle all

electric equipment and connections properly to avoid injuries.

c) Even though the recording unit may not be turned on, live power exists in the mounting assembly

and precautions should be taken to avoid shock. Disconnect the power supply from its source

before connecting or disconnecting the MDR mounting assembly from the power supply.

d) Do not attach any device specified or approved by Vendor.

e) Do not attach powered input leads that exceed 12-volt DC at 1.5 Amps OR 5-volt DC at 1.5 Amps

supply on any one connection.

f) Attach the MDR ground cable to the vehicle correctly to complete the power circuit.

g) Install the MDR in a dry location shielded from direct contact with excessive humidity and moisture,

rain or other sources of liquid spills. Do not install on a recessed surface where liquids may

accumulate or under surfaces where liquids may drip.

h) Do not handle the MDR with wet hands, while standing in water, or while in contact with other

sources of water or moisture that could create a shock hazard.

i) Install the MDR out of direct sunlight and away from direct sources of heat.

j) Do not mount the unit to a surface subject to excessive vibration.

II-2 Mounting / Enclosing the MDR

a) MDR may be operated in a totally sealed enclosure with no cooling airflow, ensure that the operating

temperature of the MDR does not exceed 140°F (60°C) or that the standing temperature does not

exceed 175°F (80°C). The minimum operating temperature for the MDR is -20°F (-28°C). If the

minimum temperature is expected to exceed connect an auxiliary heat source.

b) MDR assembly may be mounted on a flat surface, provide at least 6 inches (15cm) clearance for

cooling airflow around the remaining sides to provide adequate heat dissipation.

c) To clean any surface of the MDR, use only cleaners approved for electronic equipment or

components. Avoid chemical or household cleaners.

d) Disconnect MDR mounting assembly from the power supply when not in use for extended period of

time.

MDR Manual

II-3 Installation Parts and Materials Required

The following common tools and parts are required to install MDR

•Drill and bids for mounting in vehicle

•Screws/bolts and vibration dampening washers as appropriate for mounting

•Wire cutters and wire connectors

•Voltmeter

II-4 MDR Product Views

Front View Rear View (without connections)

Assembled Chassis Details

Height 4.9 cm (1.93 inch)

Width 17.9 cm (7.04 inch)

Depth 24.5 cm (9.64 inch)

Weight 3.25 lb

Recording Module (Removable Component)

Height 4.6 cm (1.81 inch)

Width 17.9 cm (7.04 inch)

Depth 17.6 cm (6.92 inch)

Module Removal Clearance 16.5 cm (6.49 inch)

Installation Clearance (except base ) 10 cm (6 in)

Mounting Assembly / Recording Module Removed

MDR Manual

II-5 MDR Dimension

17.9 cm

7.5

24.5 cm

4.9 cm

MDR Manual

II-6 MDR Package Contents

The following materials are shipped with the MDR. Ensure that you unpack all contents of your

shipment and confirm receipt of the following items for each unit:

a) MDR Recording Module and Mounting Assembly

b) DB37 bridal (AV input/ Sensor connectors/ Inertia sensor connector)

c) DB25 bridal (AV output / VGA connector/ RS232/ RS485/ Control panel connector)

d) USB Cable

e) 20 PCs screws

f) GPS Antenna (with GPS equipped models only)

g) Warranty card

h) User Manual CD

i) Hand held IR remote controller (batteries not included)

a b c

d e f

g h i

MDR Manual

II-7 MDR Installation Location Guidelines

Following are the general guidelines for the installation purposes. Choose a location in the vehicle

that meets the following items:

Power: It is recommended that the MDR be connected to the vehicle ignition. Battery power is

used only when the vehicle is running. MDR could drain any vehicle battery over time if

the ignition is not turned off.

Connection: Connect only to appropriate power supply and ensure proper grounding of the circuit.

Moisture: Protect unit and connections from environmental sources of moisture and liquid spills.

Temp: Do not install where unit temperature will exceed F140°F (60°C), fall below -20°F (-28°C)

or store the unit where temperatures rise above 175°F (80°C). Avoid direct exposure to

sunlight.

Ventilation: Provide sufficient ventilation with a minimum of 6 inches cooling clearance to ensure

proper operating temperature for the unit.

Vibration: If necessary, provide additional shock mounting to prevent damage and wear by

excessive vibration.

Clearance: Front clearance of 16.5 cm or 6.49 inch is required to slide the recording module from

the mounting assembly.

Wiring: Install where mounting assembly wires have sufficient clearance and will not be crimped

or subject to wire insulation damages due to vibration.

Access: Secure the MDR so that passengers or drivers cannot tamper or damage the unit,

cameras, wires or other accessories. Do not mount where access to any other vehicle

component will be restricted.

Injury: Install the unit, cameras, accessories and wires so that no injuries can be caused

through impact with equipment during vehicle operation. Ensure that all transportation

regulations are followed to avoid passenger injury should they come in contact with the

installed equipment.

MDR Manual

II-8 MDR Installation Instructions

Follow these guidelines when installing the MDR:

•Remove all components provided in the package.

•Disconnect any power supply or device.

•Slide the recording module from the mounting assembly.

•Locate a proper spot to install the mounting assembly and provide any additional shock

absorption if necessary.

•Locate a reliable electrical ground point in the vehicle.

•Make all connections to the rear of the mounting assembly.

•Place the mounting assembly and permanently attach to the supporting structure using

screws.

•Slide the recording module on to the mounting assembly to ensure proper clearance.

•Connect the provided bridals to MDR.

•Connect power source and turn the vehicle ignition (make sure this connect with “Signal”) to

test the unit.

•Observe completion of the unit power-up procedures as described in section labeled as

“System Startup and Shutdown”.

•Apply any information labeling required by local statute for video surveillance.
