Telefunken TF-MID1006 Manuale utente
10.1” TABLET PC/
10.1” ПЛАНШЕТ
TF-MID1006
Instruction manual
Руководство по
эксплуатации
Table of contents
Table of contents
2
Dear customer!
Thank you for purchasing our product. For safety, it
is strongly recommended to read this manual carefully
before connecting, operating and/or adjusting the
product and keep the manual for reference in the
future.
Table of contents
Before you start
Important safeguards
General provisions
Health and safety of the user
Power adapter, ports and connectors
LCD
Cleaning and maintenance
Utilization of the product
Battery
Operation
Control elements
Front panel
Rear panel
General operation
Power on/off
Reboot the device
The main screen
Status bar
Adding/removing objects on the desktop
Taking screenshots
Wallpaper
Upgrade basic software (OS)
Connections
Connecting to Wi-Fi
A-GPS
Connect external USB devices
Connect memory cards
Connecting to PC
2
4
4
4
5
5
6
6
7
7
8
8
8
8
9
9
10
11
11
12
12
13
13
14
14
15
15
16
16
Table of contents
Table of contents
3
HDMI-out
Applications
Installing applications
Deleting applications
List of applications
System setup
The Settings menu
The WIRELESS & NETWORKS menu
The DEVICE menu
The PERSONAL menu
The ACCOUNTS menu
The SYSTEM menu
General information
Troubleshooting guide
Accessories
Warranty
Specifications
17
17
17
18
18
22
23
23
23
24
25
25
26
26
31
31
32
Before you start
Before you start
4
Important safeguards
General provisions
• Carefully read this manual to familiarize yourself with
the device.
• Have this manual available as a reference for
operating procedures and precautions. Do not allow the use
of the device by unauthorized persons who have not read
and understood this instruction manual.
• Usage of the device at temperatures beyond the
operating temperature range significantly reduces the life
of the screen and other components of the device and can
lead to malfunction of the device.
• Do not drop, cause an impact or strong shaking of the
device.
• Do not use the device near magnetic fields. Do not
store the device near credit cards, tickets, etc., otherwise
magnetic stripe cards may be damaged.
• Make sure the power supply is turned off if you are
not going to use the device for a long time or during a
thunderstorm.
• Make sure the power supply is turned off if some
malfunction of the device is detected or the device is
overheated, makes uncharacteristic sounds, smells, emits
smoke, or if liquids have been spilled onto it. In these cases
a qualified technical maintenance is required.
• Do not use the unit while driving. Observe the law and
traffic rules of the country of your residence.
• The device must be turned off during takeoff or
landing when used on an aircraft.
• Do not use the device in areas of electronic
interference or static electricity. This can cause data loss.
• In case of a malfunction, contact a sales
representative or a nearest service center.
Before you start
Before you start
5
Health and safety of the user
• Electrical equipment can be dangerous if used
improperly, so if children use this device they should always
be supervised by adults. Do not allow children to touch the
internal components and cables of this device.
• To ensure complete safety, do not disassemble the
casing and do not try to get inside the unit. Repairs should
be performed by qualified personnel only.
• Do not spill liquids on the device. This can cause
electric shock. Besides, if liquid or dust get inside the unit,
they may cause malfunction, overheating and smoke. Keep
the unit dry.
• Make sure there are no foreign objects inside the
device. They can cause malfunction or fire.
• Using headphones at high volumes can lead to
permanent hearing loss. You can increase the volume to
a level at which sound is perceived normally and does
not lead to irritation and damage to your hearing. Set the
volume at a safe level.
• If you have a regular ringing in your ears, reduce
volume or stop using the device.
Power adapter, ports and connectors
• Do not touch the power adapter with wet hands. This
can lead to electric shock.
• Use only the supplied power adapter. Using other
power adapters with this unit may cause damage and lead
to malfunction.
• The power adapter can be connected only to the type
of electrical network the parameters of which are specified
on the rating label. If you are not sure about the parameters
of power supply and power adapter, please contact one of
the manufacturer’s authorized service centers.
• Make sure the plug of the power adapter is securely
Before you start
Before you start
6
inserted into the power supply socket. Otherwise it may
cause fire.
• Do not step on the AC adapter cord or place heavy
objects on it.
• Do not stretch or tangle the cable.
• After charging, disconnect the adapter from the wall
outlet.
• When unplugging the AC adapter from the wall pull the
plug, do not pull the cable itself.
• Do not connect the adapter to any other devices.
• Keep the power adapter away from children.
• Do not insert connector plugs into ports with force. If
a plug cannot be easily inserted into the port, the connector
and the port may not match. Make sure the connector
matches the port and that they are correctly aligned.
LCD
Liquid-crystal display (LCD) is a delicate device that
requires careful handling.
• Do not touch the screen with sharp objects.
• Do not exert strong pressure on the screen and do
not place any objects on it. This can cause damage to the
display and malfunction of the device.
• Do not expose the display to direct sunlight.
Cleaning and maintenance
• Before cleaning the device, make sure it is switched
off.
• To clean the LCD screen and casing of the device use
a soft cloth, special tissue and special cleaners. Do not use
aerosol sprays, solvents, alcohol or abrasives.
The manufacturer reserves the right to alter
specifications, appearance, contents of SW and equipment
of the product unilaterally, without prior notice.
Before you start
Before you start
7
Utilization of the product
If you want to dispose of this product, do not mix it with
general household waste. There is a separate collection
system for used electronic products in accordance with
legislation that requires proper treatment, recovery and
recycling.
Please contact your local authorities for the correct
method of disposal. By doing so, you will ensure that your
disposed product undergoes the necessary treatment,
recovery and recycling and thus prevent potential negative
effects on the environment and human health.
Battery
Connect the power adapter to the electric supply network
and insert the adapter plug into the power connector of
the device. While charging, the process is displayed as
an additional lightning symbol in the power icon: . We
recommend not to disconnect the device until the battery is
fully charged. When the battery is fully charged, the power
icon on the screen will be completely filled.
In order to maintain efficiency and prolong the
battery life, follow the instructions described below:
• Before the first use, it is recommended to attach the
device to the electric mains for 8-12 hours to fully charge
the battery.
• Do not charge the device at high temperatures.
• Do not charge the device too often: you can do this
when the display shows a low level of charge.
• If you are not using the device for a long time, charge
the battery at least once in two weeks; do not wait for the
moment of a full discharge.
Operation
Operation
8
Control elements
Front panel 12
Rear panel 4
35
6
7
8
9
10
11
12
13
Operation
Operation
9
1. Front (additional) camera
2. Display
3. Main camera
4. Speaker
5. RESET button (hole)
6. POWER button
7. VOL+/- buttons
8. MicroSD slot
9. mini HDMI output
10. microUSB port
11. Microphone
12. DC in
13. Earphone 3.5 mm minijack
General operation
Power on/off
• Power on: Press and hold the power button until the
logo appears, followed by the splash screen and the main
screen. Hold down the icon and drag it to the right onto
the icon representing an open lock to unlock the device.
Operation
Operation
10
• Sleep Mode: Sleep mode is convenient for regular
use of the device. In this mode the device stays active, but
the display is turned off and the main screen is locked. This
allows you to instantly access your operating system while
preventing accidental pressing on the display and saving
battery power. To go into sleep mode and back, briefly
press the power button.
• Turn off: Press and hold the power button until a
prompt appears asking if you want to switch off the device.
Click “OK” to shut down.
In case of low battery the device can be switched
off automatically after notifying the user about the problem.
Moreover, all unsaved data may be lost. To avoid this, save
your open documents, close all applications and connect
the tablet PC to a power source.
