Telstra S60
Telephone User Guide
If you have any
problems with your
phone, refer to the Help
section of this User
Guide or call TecHelp
on 1300 369 193.
3
In this guide
Key features 3
Telstra S60 parts checklist 4
Setting up your Telstra S60 5
Safety instructions 6
Wall mounting your Telstra S60 7
Getting to know your Telstra S60 8
Using your Telstra S60 9
Adjusting the ringer volume 9
Answering a call 10
Making a call 10
Mute 10
Storing numbers for one-touch memory 10
One-touch memory dialling 11
Storing numbers for two-touch memory dialling 1
Two-touch memory dialling 1
Help 13
Customer service & Product warranty 14
Wall mounting template 15
© COPYRIGHT 006 Telstra Corporation Limited
This work is copyright. All rights reserved. Other than for purposes and subject to
conditions prescribed under the Copyright Act, no part of it may in any form or by any
means (electronic, mechanical, photo copying, microcopying, scanning, recording or
otherwise) be reproduced, stored in a retrieval system or transmitted without prior
permission from Telstra Corporation Limited ABN 33 051 775 556.
™ Trade Mark of Telstra Corporation Limited
® Registered Trade Mark of Telstra Corporation Limited
3
Key features
One-touch memory button
The one-touch memory button allows you to call your most
frequently used number by pressing a single key.
10 two-touch memory buttons
You can program 10 of your most commonly used telephone
numbers into the telephone. This allows you to dial any of
these numbers simply by pressing two buttons.
Last number redial
Lets you redial the last number you dialled with the one key
press.
Volume buttons
Lets you increase or decrease the earpiece volume while on a
call.
5
Telstra S60 parts checklist
Your Telstra S60 has been designed for ease of use and made to
the high standards set by Telstra. Please read the instructions
carefully and keep this User Guide for future reference. If
anything is missing, please contact TecHelp on 1300 369 193
immediately.
Telephone Base Unit
Telephone Handset
Handset Cord
(Shown here assembled)
Wall Mount Bracket &
Screws
Telephone Line Cord &
Adaptor Plug
5
Setting up your Telstra S60
Before plugging your Telstra S60 into the telephone line you
need to assemble the unit.
Step 1
Wrap the telephone line cord into the cable storage of the
telephone base.
Step 2
Plug the line cord into the telephone wall socket
Your S60 is
now ready
to use.
6SXOMY\N
:RYXO]YMUO^
6 7
Safety instructions
Read and follow all instructions and warnings.
• Do not use this product during an electrical storm, as it is
possible to get a shock.
• Do not use the product near water, or when wet.
• Keep the product away from heaters and direct sunlight.
• Slots and openings in the cabinet are provide for ventilation.
Ensure these are not blocked or covered.
• Do not open the unit. There are no user serviceable parts
inside. Warranty conditions will not apply if the unit has been
opened.
• Unplug the unit before cleaning. Do not use detergents or
sprays. To clean the outside plastic parts use only a damp
cloth.
• Do not push objects into ventilation openings. This could
cause an electrical shock.
• Do not use this telephone near flammable gases or liquids.
6 7
Wall mounting your Telstra S60
Your Telstra S60 can be wall-mounted by using the wall
mounting bracket supplied.
Using the wall mounting template (on page 15), drill holes for
the screws and insert the wall plugs (if required).
Follow the illustrations below to complete wall mounting your
S60.
9
Getting to know your Telstra S60
Keypad
Memory
Use to store
numbers in
the Two-Touch
memory
Store/Mute
Press to mute
the microphone
during a call.
Also used when
storing numbers in
memory.
Recall
Used when
connected to
certain PABX’s and
with some Telstra
features such as
Call Waiting
M1
Press for One-
Touch memory
dialling
+ Vol & - Vol
Press to increase
or decrease
volume while on
a call
Hang Up
Press to end a
call and return to
dial tone. Replace
handset in base
to hang up.
Redial/Pause
Press to redial
the last number
dialled.
9
Using your Telstra S60
Adjusting the ringer volume
Your phone is built with 3 preset ringer melodies and loudness
levels. To change the melodies and loudness level, follow the
instructions listed below:-
1. Pick up the handset.
. Press and release button.
3. Press and release the button.
. Use the numbered button (keypad) to make your selection of
ringer melodies and loudness level combination.
Numbered button Ringer melody Loudness level
1 A Low
A Normal
3 A High
B Low
5 B Normal
6 B High
7 C Low
C Normal
9 C High
0 Off Off
5. Hang up to store the new setting.
10
1110
Answering a call
Lift the handset to answer the call.
Making a call
1. Lift the handset.
. Listen for a dial tone then enter the number you wish to call.
Ending a call
Replace the handset in the base to hang up. To end a call and
return to dial tone press
Mute
To prevent the other party from hearing you while on a call
press the button. To resume speaking press the button
again.
