Product Application and Solution Guide
S5 Sweeper
©2013 The Tennant Company CONFINDENTIAL - For Internal Use Only S5 Rev 9/12 1
Model Names: S5
Positioning: Compact maneuverability and outstanding performance over a wider variety of debris
(compared to single broom systems)
Value Proposition: “Sweep smarter, not harder” – more versatility/benefits for the same price point
Key Support Points:
PRODUCTIVITY and consistent performance
• TwinMax™ technology improves capture of a wide variety of debris
•Compact size is easy to maneuver in tight spaces while side brush captures
debris in corners and under shelves
•Consistent optimum sweeping performance due to constant broom
drive with motor
VERSATILITY to clean multiple surface and environments
•Dust control with active fan and large filter
•Suitable for both inside and outside sweeping
QUALITY CONSTRUCTION that extends product life
•Robust roto-molded construction and reliable technology
LOW COST OF OWNERSHIP in acquiring and operating
•Balancing the performance, durability and compact size make this sweeper a great value at an affordable price!
Product Positioning/Highlights
©2013 The Tennant Company CONFINDENTIAL - For Internal Use Only S5 Rev 6/13 2
Product Markets and Applications
©2013 The Tennant Company CONFINDENTIAL - For Internal Use Only S5 Rev 6/13 3
MARKET APPLICATION FLOOR TYPES
Retail
Show floors, entry ways, narrow
aisles, storage
rooms
Natural stone, concrete, tiles, vinyl,
carpet
Small
Warehouses
Production
areas, storage areas,
aisles, dock areas
Concrete, vinyl,
hard floor
Schools and
Universities
Classrooms, locker
rooms, common
dormitories spaces
Tiles, vinyl, carpet
Hospitality
Patient rooms, hallways
Natural stone, tiles, vinyl, carpet
Small
Manufacturing
Production areas, entrances, material
storage areas
Coated concrete, vinyl,
hard floor
Building
Services
Small offices, hallways, route
cleaning
trucks
Coated concrete, vinyl,
hard floor, carpet
Product Markets and Applications
©2013 The Tennant Company CONFINDENTIAL - For Internal Use Only S5 Rev 6/13 4
Product Specifications
©2013 The Tennant Company CONFINDENTIAL - For Internal Use Only S5 Rev 6/13 5
FEATURES
SPECIFICATION*
Product Name S5
Sweeping System TwinMaxTM Technology
Path Width 24 in / 620 mm
Main Broom
Length
Diameter
Speed - rpms
16 in / 400 mm
6.7 in / 170 mm
390 rpm
Side Broom
Diameter
# of side brooms
12 in / 300 mm
1
Productivity
Practical (per ISSA
540 cleaning times)
13,850 ft²/hr / 1,290 m²/hr
Hopper Capacity 1.3 ft3 / 37 L
Drive Type Gear Motor
Automatic Main Broom
Drive Yes
Power Transmission Maintenance Free, High
Performance Belt Drive
Sound Level
(operator’s ear) 62 dBA
FEATURES
SPECIFICATION*
Batteries 12 V AGM
Charger On-Board
AirFlow 141 cfm / 240 m³/hr
Filtration
Type
Filter Area
99.97 @ .3 microns
13 ft² / 1.2 m²
Adjustable Handle Yes
Dimensions
Length
Width
Height
36.3 in / 923 mm
25.5 in / 650 mm
22 in / 557 mm
Weight:
w/battery
w/o battery
121 lb / 55 kg
88 lb / 40kg
Construction:
Main Body
Chassis
Roto-Molded
Corrosion Resistant
Warranty: See your sales representative or authorized
distributor for complete warranty details
*Specifications subject to change without notice
Crucial Design Concept
TwinMax™ Technology
•Performance Improvement with dual counter-rotating brushes
•Combines over-throw and direct sweeping principles
•Performs better than single broom systems on a wider variety of debris
•Performs well inside and outside, including on carpet
•Fully adjustable main and side brushes for optimal pick-up
•Optimal hopper utilization with top fill design
©2013 The Tennant Company CONFINDENTIAL - For Internal Use Only S5 Rev 6/13 6
Strengths of Our Sweeper Solution
©2013 The Tennant Company CONFINDENTIAL - For Internal Use Only S5 Rev 6/13 7
CUSTOMER
Results & Benefits
Versatile operation
–well suited for small indoor
and outdoor
environments
Optimal adaptation
–allowing you to clean a wide array of
floors & c
aptures many types of dirt
Outstanding performance
–with consistent broom drive
Decreased
labor –with easy replacement & cleaning of the
brush and bristles
Increased operator comfort
–due to no manual pushing
force needed to operate
Simplified training
–shortened learning curve allows for less
training and more time cleaning
Reduced fatigue
–with less strain on the operator while
cleaning
TENNANT
Advantages & Features
Compact size
Pressure adjustment
main brushes
Motor
operation
Split
-half design main brushes
Battery operation
Intuitive design
Fully adjustable handle
Productivity –helping workers to drive a better time/clean ratio
Versatility –allowing you to re-purpose one machine for multiple uses
Quality Construction –ensuring strong performance and a long asset life
Low Cost of Ownership –delivering operating value at a reasonable investment
Top Line S5 Customer Benefits
©2013 The Tennant Company CONFINDENTIAL - For Internal Use Only S5 Rev 6/13 8
Productivity
©2013 The Tennant Company CONFINDENTIAL - For Internal Use Only S5 Rev 6/13 9
Effective cleaning
•Easier pick-up into the hopper with both
brushes working together
•Chevron pattern directs debris toward center
of machine
Fully adjustable brushes can be set at optimal
height for whatever surface needs cleaning
Compact size
•Easy to maneuver around racks and shelves
•Able to clean narrow aisles quickly
•Low profile side brooms for reach under capabilities
Productivity
©2013 The Tennant Company CONFINDENTIAL - For Internal Use Only S5 Rev 6/13 10
More time spent sweeping and fewer
dumps with a large 1.3 ft3/ 37L capacity
hopper
Easy hopper removal makes dumping
debris quicker and less fatiguing on
the operator HOPPER
BATTERY
OPERATED Consistent optimum sweeping performance
with constant broom drive.
No manual pushing force required to operate
