Tetra LightWave Timer Manuale utente
2LightWaveTimer
12
LWE0005
A
LWE0008
B
LightWave Splitter
LightWave Single Light
LWE0006
C
3
UK
WARNING
• This device is suitable for use by children aged 8
and over as well as people with reduced physical,
sensory or mental capacities or a lack of expe-
rience and knowledge if they are supervised or
have been instructed how to safely use the device
and understand the resultant risks.
• Children must not play with the device.
• Children must not conduct cleaning or user main-
tenance activities without supervision.
• Always switch o and unplug all devices in the
aquarium before carrying out any tasks which
require reaching into the water.
• Do not use the device if the electrical cables or
housing are damaged.
• Damaged connection cables cannot be replaced.
Dispose of the device.
4LightWaveTimer
UK
CONTENTS
FOREWORD......................................................................................................................5
ABOUT THIS MANUAL...................................................................................................5
SAFETY INSTRUCTIONS................................................................................................5
SCOPE OF DELIVERY.......................................................................................................6
PRODUCT BASICS ..........................................................................................................6
ASSEMBLY AND ATTACHMENT...................................................................................7
INITIAL USE .....................................................................................................................7
OPERATION......................................................................................................................8
SET-UP ..............................................................................................................................9
MAINTENANCE.............................................................................................................11
TROUBLESHOOTING ....................................................................................................11
DISPOSAL.......................................................................................................................12
TECHNICAL SPECIFICATIONS ....................................................................................13
WARRANTY....................................................................................................................13
5
UK
FOREWORD
Thank you for choosing a quality product from Tetra. For further useful informa-
tion and services in relation to your product and Tetra’s fascinating underwater
worlds, please visit our website: www.tetra.net.
ABOUT THIS MANUAL
The manual goes with the LightWave Timer and must be stored for future ref-
erence.
Explanation of the manual structure
NOTE
Indicates a possibly dangerous situation which could lead to damage of prop-
erty or the environment if it is not avoided.
Fig. A: Reference to a figure at the beginning of this manual.
1. Instruction
• List
6, section name: Reference to a page and the section concerned in this
manual.
SAFETY INSTRUCTIONS
Preventing hazardous situations
• Protect the plug-in connectors from moisture.
• Never open the housing of the LightWave Timer.
• Do not allow children to play with the packaging materials. There is a risk of
choking.
Preventing material damage
• Only use original spare parts and accessories.
6LightWaveTimer
UK
Note the symbols on the device
Do not dispose of the device with household waste; send for
recycling.
Protection class III: protection by low voltage.
IP54 Protected against water splashes from any direction.
Intended for indoor use only.
SCOPE OF DELIVERY
Fig. A
1LightWave Timer
2 Support with suction cups
PRODUCT BASICS
Product description
The LightWave Timer can be used to control the brightness of the connected
LED light and various time-dependent eects.
Intended use
Only use the LightWave Timer:
• to control LightWave LED lights,
• in indoor areas,
• for private use,
• in line with the technical data.
7
UK
ASSEMBLY AND ATTACHMENT
The device can be hung on the loop or placed in the holder and attached to the
outside of the clean aquarium wall using the suction cups.
Procedure:
Fig. B
• Attaching the device using the holder: to ensure that the suction cups hold
securely, moisten and use on smooth, grease-free and clean surfaces.
NOTICE: Do not attach the device to the inside of the aquarium in order to
avoid contact with water.
INITIAL USE
An (optional) LightWave Splitter is required to operate two LED lights.
Procedure:
Fig. C
1. Connect all components and connect the power supply to the mains.
NOTICE: Do not attach electric accessories, such as the power supply, to
the aquarium in order to avoid contact with water.
2. When you first switch on the LightWave Timer it will be in set-up mode. Set
the time and functions (9, Set-up).
– The set-up menu is exited automatically after 30 seconds of inactivity.
Interrupted power supply
If the power supply is interrupted (e.g. due to a power cut or if the switch on
the power supply is turned o), the current time settings will be lost. Once the
power supply is restored, the LED light will indicate with full brightness that the
power supply has been interrupted.
• In this case, the current time and brightness will need to be reset (9,
Set-up).
8LightWaveTimer
UK
OPERATION
Function during operation
Function in set-up mode
Description
12:00 •Current time display.
•Set values display.
•Sunrise/sunset eect.
LED on = eect enabled.
•Cloud eect.
LED on = eect enabled.
•Thunderstorm eect.
LED on = eect enabled.
MINUTE
/ RESET •Switch the LED light on/o manually.
At the next daytime/night phase change, the manual switch
status of the LED light will be reset.
•Reset the LightWave Timer to factory settings.
Press and hold the button for 3 seconds.
•Change the minutes.
HOUR
F1-F3 ·DEMO •Demonstration of the sunrise/sunset, cloud and thunder-
storm eects.
Press and hold the button for 3 seconds.
•Change the hours.
•Increase the brightness of the LED light.
Not possible if an eect is enabled.
•Enable/disable eect mode.
9
UK
Function during operation
Function in set-up mode
Description
•Reduce the brightness of the LED light.
Not possible if an eect is enabled.
SET •Start set-up mode.
Press and hold the button for 3 seconds.
•Save settings and navigate to the next menu.
SET-UP
Procedure:
Press and hold SET for 3 seconds to open the set-up menu.
• The set-up order is pre-determined: A|Current time B|Switch-on/switch-
o time of the LED light C|Sunrise/sunset D|Cloudy sky E|Thun-
derstorm.
• The menu is exited automatically after 30seconds of inactivity.
Set-up menu
A Current time.
• The figures flash on the display.
1. Set the current time using the HOUR and MINUTE buttons.
2. Press SET to save the setting.
3. Press SET again to switch to menu item B.
B Switch-on/switch-o time of the LED light (daytime phase).
• “ON” (switch-on time) is briefly shown on the display, followed by the
time.
1. Set the switch-on time using the HOUR and MINUTE buttons.
2. Press SET to save the setting.
– “OFF” (switch-o time) is briefly shown on the display, followed by
the time.
3. Set the switch-o time using the HOUR and MINUTE buttons.
4. Press SET to save the setting and switch to menu item C.
10 LightWaveTimer
UK
Set-up menu
C Sunrise/sunset eect. The sunrise starts with the switch-on time and
lasts for 20 minutes. The sunset starts with the switch-o time and lasts
for 20 minutes.
• “F1” is displayed.
1. Press + to enable/disable the eect.
– lights up when the eect is enabled.
2. Press SET to save the setting and switch to menu item D.
D Cloud eect. The LED light is dimmed for 11 minutes. The start time must
be within the daytime phase, otherwise the error message “Err” will be
displayed.
• “CL ON” (start time) is briefly shown on the display, followed by the
time.
1. Set the start time time using the HOUR and MINUTE buttons.
2. Press SET to save the setting.
– “F2” is displayed.
3. Press + to enable/disable the eect.
– lights up when the eect is enabled.
4. Press SET to save the setting and switch to the next menu item.
E Thunderstorm eect. The LED light simulates flashes of lightening for
14 minutes. Any start time can be programmed. The eect can start
during the daytime or night phase.
• “FL ON” (start time) is briefly shown on the display, followed by the
time.
1. Set the start time time using the HOUR and MINUTE buttons. Press
SET to save the setting.
– “F3” is displayed.
2. Press + to enable/disable the eect.
– lights up when the eect is enabled.
3. Press SET to save the setting and exit the set-up menu.
