TI-5630

Guidebook

Manuel d’instructions

Manual de instrucciones

Manual de instruções

English, Français, Español, Português

Antes de usar (o ensamblar) el producto lea cuidadosamente este instructivo

Getting Started

Installing the Paper Roll

1. Remove the printer compartment cover.

2. Lift the paper holder so that it extends behind the printer

compartment.

3. Remove any packing materials from the printer compartment.

4. Replace the printer compartment cover.

5. Plug the calculator into an electrical outlet.

6. Set the

power

switch on the right side of the calculator to on

(

)

7. Place the paper roll on the paper holder as shown below.

8. Insert the end of the paper into the paper slot on the back of the

calculator above the black “bar”. To avoid paper jams, use quality

bond paper.

9. Feed the paper into the slot; then press and hold

Note

To prevent damaging the printer (which may void the warranty),

when operating the calculator without paper, move the

PRINTER

switch to

OFF

ENG5630.DOC TI-5630 Guidebook, UK English Texas

Instruments Inc Revised: 06/23/00 1:04 PM Printed: 06/23/00

1:05 PM Page 2 of 8

Replacing the Ink Roller

1. Set the power switch on the right side of the calculator to off (

2. Remove the printer compartment cover.

3. Lift the removal tab on the old ink roller and remove the roller, as

shown in the following illustration.

4. Lower the new ink roller into the compartment and press down

gently until it snaps into place.

5. Replace the printer compartment cover.

Note

Do not refill old ink rollers. New rollers are available from local

retailers.

Key Descriptions

Advances the paper.

Clears the entire pending operation except the memory or

the grand total.

Changes the sign (

–

) of the displayed number.

Interprets the number in the display as a percentage.

Clears an entry or an error or overflow.

Computes the percentage of change between two values.

(The price increase from 9.75 to 11.25 is 1.50 and the

percentage increase is 15.38%.)

Calculates the selling price and profit or loss amount on

an item.

(

Removes the last digit entered in the display.

Prints a reference number or date without affecting

calculations.

ENG5630.DOC TI-5630 Guidebook, UK English Texas

Instruments Inc Revised: 06/23/00 1:04 PM Printed: 06/23/00

1:05 PM Page 3 of 8

Adds the stored tax rate to the value in the display.

Subtracts the stored tax rate from the value in the display.

Pressed once, displays and prints the grand total of all

totals. Pressed twice, clears the grand total. This is active

only if PRINTER = GT.

Displays and prints the total, but does not clear the total.

Displays and prints the total and clears the total. If

PRINTER = IC, also resets the item counter (

) to zero.

Displays and prints the value in memory and clears the

memory. Also clears

from the display and resets the

memory item count to zero.

;

Displays and prints the subtotal in memory but does not

clear the memory.

Subtracts the displayed value from memory. If a

multiplication or division operation is pending,

completes it and subtracts the result from memory.

Adds the displayed value to memory. If a multiplication or

division operation is pending,

completes it and adds

the result to memory.

Using Decimals (DECIMAL Switch)

Lets you add and subtract numbers without entering the

decimal point (key in 5321 to enter 53.21).

The number of decimal places varies based on the result.

0,2,3,4,6

Sets the number of decimal places to 0, 2, 3, 4, or 6.

Rounding (ROUND Switch)

Results are rounded down (if

DECIMAL = 1

, 2.33 rounds to 2.3).

5/4

Results are rounded up or down, depending on the value

and decimal setting (if

DECIMAL

, 2.349 rounds to 2.35).

Results are rounded up (if

DECIMAL = 1

, 2.33 rounds to 2.4).

Entering a Tax Rate (TAX Switch)

SET

Lets you enter a tax rate to perform tax calculations.

CALC

Stores the tax rate.

ENG5630.DOC TI-5630 Guidebook, UK English Texas

Instruments Inc Revised: 06/23/00 1:04 PM Printed: 06/23/00

1:05 PM Page 4 of 8

Printing (PRINTER Switch)

OFF

Calculations are displayed but not printed.

Calculations are displayed and printed.

Both the printer and item counter are active. To clear the

item counter, press

Accumulates a running grand total of all calculations you

perform until you clear the grand total. To print a grand

total, press

. To clear the grand total, press

again.

Clearing Errors and Overflows

Correcting Entry Errors

If you have not pressed an operation key:

•

To clear an incorrect entry, press

•

To clear the last digit, press

(

If you have pressed an operation key:

•

To cancel an incorrect entry, press the opposite operation key.

This applies only to calculations involving

, or

Error and Overflow Conditions and Indicators

If you divide by zero or calculate a selling price using a margin of

100%, an error occurs. The calculator prints

ERROR

0 .*

and displays

and

An overflow occurs if you calculate a result with too many digits for

the calculator to display or print. When this occurs, the calculator:

•

Displays

and the first 12 digits of the result with a decimal point

11 places to the left of its correct position.

•

Prints

ERROR

and the first 12 digits of the result with the decimal

shifted 11 places to the left of its correct position.

To clear an error or overflow,

press

. The memory is not cleared

unless the error or overflow occurred in a memory calculation.

ENG5630.DOC TI-5630 Guidebook, UK English Texas

Instruments Inc Revised: 06/23/00 1:04 PM Printed: 06/23/00

1:05 PM Page 5 of 8

Performing Basic Calculations

Addition and Subtraction

12.41 – 3.95 + 5.40 = 13.86

DECIMAL = +, ROUND = 5/4, TAX = CALC, PRINTER = IC,

Press Display Print

1241

12.41 12.41 +

395

8.46 3.95 –

002

8.46 8.46

540

13.86 5.40 +

003

13.86 13.86

∗

Multiplication and Division

11.32

(–6)

2 = –33.96

DECIMAL = F, ROUND = 5/4, TAX = CALC, PRINTER = ON

Press Display Print

11.32

11.32 11.32

–67.92 –6.

2. =

–33.96 –33.96

∗

Squares

2.5

= 6.25

Press Display Print

2.5

6.25

2.5

6.25

∗

Reciprocals

1/25 = 0.04

Press Display Print

0.04

25.

0.04

∗

ENG5630.DOC TI-5630 Guidebook, UK English Texas

Instruments Inc Revised: 06/23/00 1:04 PM Printed: 06/23/00

1:05 PM Page 6 of 8

Using Memory Operations

DECIMAL = 2, ROUND = 5/4, TAX = CALC, PRINTER = ON

Multiplication with Memory Keys

You need the total of three items at

10.50 and five items at 4.95. By using the memory keys, you will not

disturb a current calculation.

Press Display Print

0†

10.5

10.5 x

3. =

M 31.50 31.50 M+

4.95

4.95 x

5. =

M 24.75 24.75 M+

;

††

M 56.25 56.25 M

4.95

†††

4.95 x

5. =

M 24.75 24.75 M–

31.50 31.50 M

∗

†0

prints the current memory total and clears the memory.

††

You calculate a memory subtotal to see the current total

amount of your order.

†††

You decide not to order the last item.

Calculating Gross Profit Margin

DECIMAL = 2, ROUND = 5/4, TAX = CALC, PRINTER = ON

Calculating a Profit Amount

An item cost you 65.00. You want to

earn a 40% profit. Calculate the selling price.

Press Display Print

65. 65. M

40.

43.333333333 %

@∗

108.33 108.33

∗

ENG5630.DOC TI-5630 Guidebook, UK English Texas

Instruments Inc Revised: 06/23/00 1:04 PM Printed: 06/23/00

1:05 PM Page 7 of 8

Calculating a Loss Amount

An item cost you 35,000. You must sell

it, but can only afford to lose 33.3%. Calculate the selling price.

Press Display Print

35000

35,000. 35,000. M

33.3

–33.3 %

–8,743.435859

@∗

26,256.56 26,256.56

∗

Calculating Percentages

DECIMAL = F, ROUND = 5/4, TAX = CALC, PRINTER = ON

Percent

49 x 15%

Press Display Print

49. 49. x

7.35 15.

7.35 %

∗

Percent Ratio

29.5 is what percent of 25?

Press Display Print

29.5

29.5 29.5

25. %

118. 118.

∗

Calculating Tax

DECIMAL = F, ROUND = 5/4, TAX = SET, PRINTER = ON

Add-On

1,450 + 15% tax

Press Display Print

15 and move TAX

switch to CALC 0. 15. %

1450

1,450.

217.5

1,667.5 1,667.5

∗

ENG5630.DOC TI-5630 Guidebook, UK English Texas

Instruments Inc Revised: 06/23/00 1:04 PM Printed: 06/23/00

1:05 PM Page 8 of 8

Discount

235

17.5%

(Remember to move the TAX switch to SET before you begin.)

Press Display Print

5 and move

TAX switch to CALC 0. 17.5 %

235

235.

–35.

200. 200.

∗

Using Constants

DECIMAL = F, ROUND = 5/4,TAX = CALC, PRINTER = ON

Multiplying by a Constant

5 x 3 = 15 5 x 4 = 20

The first number in a multiplication problem is the constant multiplier.

Press Display Print

5. 5. x

3. =

15. 15.

∗

4. =

20. 20.

∗

Dividing by a Constant

66 ÷ 3 = 22 90 ÷ 3 = 30

The second number in a division problem is the constant divisor.

Press Display Print

66. 66. ÷

3. =

22. 22.

∗

90. =

30. 30.

∗

Prise en main

Installation du rouleau de papier

1. Retirez le couvercle du compartiment de l'imprimante.

2. Soulevez le porte-rouleau de manière à le faire passer derrière le

compartiment de l'imprimante.

3. Veillez à ce que le compartiment de l'imprimante soit libre de tout

élément ou résidu d'emballage.

4. Replacez le couvercle du compartiment de l'imprimante.

5. Branchez la calculatrice sur une prise secteur.

6. Positionnez sur ON

le commutateur

de marche/arrêt situé à droite

de la calculatrice

(

)

7. Placez le rouleau de papier sur le porte-rouleau comme illustré ci-dessus.

8. Insérez l'extrémité de papier dans la fente située à l'arrière de la

calculatrice au-dessus de la "barre" noire. Pour éviter tout

bourrage de papier, utilisez exclusivement du papier de qualité.

9. Insérez le papier dans la fente ; puis appuyez sur cette touche

et maintenez-la enfoncée.

Remarque

Pour éviter d'endommager l'imprimante (ce qui peut

rendre la garantie caduque), lorsque vous utilisez la calculatrice sans

papier, veuillez placer le commutateur

PRINTER

sur

OFF

Indice

Lingue:

Altri manuali Texas Instruments Calcolatrice

Texas Instruments

Texas Instruments TI-30XS Multiview Manuale utente

Texas Instruments

Texas Instruments TI-84 PLUS series Istruzioni operative

Texas Instruments

Texas Instruments TI-85 Manuale utente

Texas Instruments

Texas Instruments TI-55 Manuale utente

Texas Instruments

Texas Instruments TI-73 Explorer Manuale

Texas Instruments

Texas Instruments TI-40 College II Manuale utente

Texas Instruments

Texas Instruments TI-5032SVC Manuale utente

Texas Instruments

Texas Instruments E-5032 Manuale utente

Texas Instruments

Texas Instruments TI-82 STATS Manuale utente

Texas Instruments

Texas Instruments BA II Plus Manuale utente

Texas Instruments

Texas Instruments Tl-84 Plus CE Manuale utente

Texas Instruments

Texas Instruments TI-84 - Plus - Edition Graphing Calculator Manuale utente

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuale utente

Texas Instruments

Texas Instruments TI-84 - Plus - Edition Graphing Calculator Manuale utente

Texas Instruments

Texas Instruments TI-92 Manuale di istruzioni

Texas Instruments

Texas Instruments Voyage 200 Manuale

Texas Instruments

Texas Instruments TI-86 - ViewScreen Calculator Manuale

Texas Instruments

Texas Instruments TI-10 Manuale utente

Texas Instruments

Texas Instruments 30XA Manuale utente

Texas Instruments

Texas Instruments TI-83 - Plus Graphing Calculator Manuale

Texas Instruments

Texas Instruments TI30XA - Scientific Calculator Manuale utente

Texas Instruments

Texas Instruments TI-84 Plus Series Manuale utente

Texas Instruments

Texas Instruments Titanium TI-89 Guida rapida

Texas Instruments

Texas Instruments Titanium TI-89 Manuale utente

Manuali Calcolatrice popolari di altre marche

HP 35s Manuale

Casio

Casio CFX-9970G Manuale utente

LEXIBOOK

LEXIBOOK EL350 Manuale utente

HP HP-97 Manuale utente

Citizen

Citizen SDC-414N Manuale utente

Casio

Casio fx-3800P Manuale utente

Canon

Canon P26-DHIII Manuale utente

Citizen

Citizen 520DPA Manuale utente

Sharp

Sharp EL-9900 Manuale utente

Casio

Casio FX-9860GII - SOFTWARE VERSION 2-00 Manuale utente

Casio

Casio MS-7UC Manuale utente

Sharp

Sharp WriteView EL-W506 Manuale tecnico

Casio

Casio FC-200 Manuale utente

Casio

Casio fx-CG50 Manuale utente

HP HP-67 Guida utente

Royal

Royal CBC2000 Manuale utente

Heathkit

Heathkit IC-2009 Manuale utente

Universal

Universal UNV-15907 Manuale utente
