1-1

General Information

General

Information

This chapter details the Texas Instruments (TI) DM38500 PFC/PWM

Combination Controller 100W Power Factor Correction Preregulator

Evaluation Module (EVM) SLUU068. It includes a list of EVM features, a brief

description of the module illustrated with a pictorial, schematic diagrams, and

EVM specifications.

Topic Page

1.1 Features 1−2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 Description 1−2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 Operating Guidelines 1−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.4 DM38500 EVM Performance 1−5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 1

Features

1-2

1.1 Features

UCC38500 PFC/PWM Combination Controller 100W Power Factor Correc-

tion Preregulator include:

JCombines PFC and 2nd Stage Down Converter Controls

JControls Boost Preregulator to Near-unity Power Factor

JAccurate Power Limiting

JImproved Feedforward Line Regulation

JPeak Current Mode Control in Second Stage

JProgrammable Oscillator

JLeading Edge/Trailing Edge Modulation for Reduced Output Ripple

JLow Startup Supply Current

JSynchronized Second Stage with Programmable Soft-start

JProgrammable Second Stage Shut-down

1.2 Description

The UCC38500 provides all the functions necessary for active power factor

correction and a second stage dc-to-dc converter all in one integrated circuit.

The control IC uses leading edge modulation for the boost stage and trailing

edge modulation for the step down converter to reduce the RMS current in the

boost capacitor. The dc-to-dc controller uses peak current mode control for

easy loop compensation.

The UCC38500 evaluation board is designed to illustrate the performance of

the IC in a complete off-line 100W two-stage power converter using power fac-

tor correction. The demonstration board was designed to operate with a uni-

versal input voltage range (i.e. 85−265 Vac) with a regulated 12V dc output.

Caution

High-voltage levels are present on the evaluation module whenever it is

energized. Proper precautions must be taken when working with the

EVM. The output capacitor has high levels of energy storage and it must

be discharged before the load is removed. Serious injury can occur if

proper safety precautions are not followed.

Description

1-3

General Information

1.3 Operating Guidelines

The operating guidelines for the evaluation board are provided with reference

to the schematic in Figure 1−1 and the component layout in Figure 2−1.

1.3.1 Step 1. Load Connections

A resistive or electronic load can be applied to the output terminals labeled

OUT− and OUT+.

Note: For safety reasons the load should be connected before power is sup-

plied to the demonstration board.

1.3.2 Step 2. Applying Input Power

A 60 Hz AC power source not exceeding 265 VRMS needs be applied across

terminals AC−N and AC−L for proper operation.

1.3.3 Step 3. Evaluating the Demonstration’s Boards Performance.

With the AC source set between 85−265 VRMS the output voltage should be

regulated and the input current should track the input voltage shape with near

unity power factor. The operation of the circuit is verified over the line and load

range and shows efficiency as high as 85%. At lighter loads, there may be

some distortion in the line current due to Discontinuous Conduction Mode

(DCM) operation. Please refer to Figures 1−2, 1−3 and 1−4 for typical EVM

performance.

1.3.4 Additional Information

For more information, pin description and specifications for the UCC38500

PFC/PWM Combination Controller, please refer to the datasheet or contact

the Texas Instruments Semiconductor Product Information Center at

1-800-336-5236 or 1-972-644-5580. Product Information can also be found

on the World Wide Web at www.ti.com.

Description

1-4

Figure 1−1.DM38500 Evaluation Module Application Schematic

UDG−00094

OVP/ENBL

VSENSE

VAOUT

ISENSE

MOUT

CAOUT

IAC

VFF

PKLIMIT

VREF

GT1

GT2

VCC

GND

PWRGND

SS2

VERR

ISENSE2

UCC38500

VREF

R25

VCC

R6 GT1

GT2

D10

C27

PKLIMIT

C28

R17

C19

C22

R28

C25

R23

R34

R21

R22

R33

R20

R15

L1 D3

GT1

R14

R29

PKLIMIT

R19

C26

VREF

R18

R24

C29 C30

ISENSE2

GT2

R13

PWR

GND

GT2

12 V

100 W

−

D11

VAC

85−265VRMS

U4 C7

SGND

PGND2

PGND

PGNDPGND

SGND

PGND

C12

C20

VCC

BIAS

CIRCUIT

VCC

VCCBIAS

CIRCUIT

PGND

C23

PGND2

R26

D14

R36

R16

C14 R35 R32

R27

D13

R31 C8

R30

R10

R12 R11

C21

C16

PGND

C24

R1C4

C18

D15

D12

D16

AC−N

AC−L

OUT +

OUT −

VREF

R3 R39

C13

ISENSE2

C17

H11AV1

SGND

C38

HIGH VOLTAGE −

SEE EVM WARNINGS

AND RESTRICTIONS

HIGH

TEMPERATURE−

SEE EVM WARNINGS

AND RESTRICTIONS

HIGH VOLTAGE −

SEE EVM WARNINGS

AND RESTRICTIONS

HIGH

TEMPERATURE−

SEE EVM WARNINGS

AND RESTRICTIONS

Note: High-Voltage component. See EVM Warnings and Restrictions at the back of this document.

Note: High-Temperature component. See EVM Warnings and Restrictions at the back of this document.

Indice

Altri manuali Texas Instruments Controllori

Texas Instruments

Texas Instruments DRV8833 Manuale utente

Texas Instruments

Texas Instruments DLP LightCrafter Dual DLPC900 Foglio di istruzioni

Texas Instruments

Texas Instruments TUSB3200EVM2 Manuale utente

Texas Instruments

Texas Instruments bq78350-R1 Manuale per l'uso e la cura

Texas Instruments

Texas Instruments DLPC3430 Manuale

Texas Instruments

Texas Instruments TMS320C6000 DSP Manuale utente

Texas Instruments

Texas Instruments TUSB422 EVM Manuale utente

Texas Instruments

Texas Instruments TCAN4550-Q1 Manuale utente

Texas Instruments

Texas Instruments TPS92512EVM-001 Manuale utente

Texas Instruments

Texas Instruments TPS59640EVM-751 Manuale utente

Texas Instruments

Texas Instruments TPS40100 Manuale utente

Texas Instruments

Texas Instruments Stellaris MDL-BDC24 Manuale utente

Texas Instruments

Texas Instruments DRV2511Q1EVM Manuale utente

Texas Instruments

Texas Instruments TPS51100 Manuale utente

Texas Instruments

Texas Instruments TMS320C6747 DSP Manuale utente

Texas Instruments

Texas Instruments UCD90320 Manuale utente

Texas Instruments

Texas Instruments Sitara AM335x Manuale utente

Texas Instruments

Texas Instruments TMS320C6000 DSP Manuale utente

Texas Instruments

Texas Instruments TPS53647 Manuale utente

Texas Instruments

Texas Instruments LM5020 Manuale utente

Texas Instruments

Texas Instruments TUSB2136 Manuale utente

Texas Instruments

Texas Instruments TMS320C6452 DSP Manuale utente

Texas Instruments

Texas Instruments TMS320x281 series Manuale utente

Texas Instruments

Texas Instruments PCI7621 Manuale di installazione e d'uso

Manuali Controllori popolari di altre marche

Digiplex

Digiplex DGP-848 Istruzioni operative

YASKAWA

YASKAWA SGM series Manuale utente

Sinope

Sinope Calypso RM3500ZB Manuale utente

Isimet

Isimet DLA Series Style 2 Manuale di installazione

LSIS

LSIS sv-ip5a Manuale utente

Rockwell Automation

Rockwell Automation 1769-L31 Manuale utente

Airflow

Airflow Uno hab Manuale utente

ABB

ABB ACS580-01 drives Manuale utente

Panasonic

Panasonic GM1 Series Manuale utente

Emerson

Emerson SW93 Manuale utente

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuale utente

Panasonic

Panasonic FP? Positioning Unit RTEX Manuale utente

Samson

Samson Type 5824 Manuale di servizio

Alpha IP

Alpha IP MIOB 21001 Manuale utente

Siemens

Siemens OpenAir GMA 1 Series Manuale utente

Surecom

Surecom SR-629 Manuale utente

Fishman

Fishman TriplePlay Manuale utente

Regulus

Regulus SRS1 T Manuale utente
