English Operating Manual
Presence detector
PlanoCentro 000-A-230V
PlanoCentro 000-E . .
PlanoCentro 000-U . .
Table of contents
1. Safety.........................59
2. Function and performance .........60
3. Installation .....................62
4. Connection / Operation mode .......66
5. Start-up .......................69
6. Parameters .....................71
7. Read-out data ..................72
8. Test-Mode .....................73
9. Control commands ...............75
10. Diagnostics.....................76
11. Troubleshooting .................77
12. Technical data ..................78
13. Dimension drawings ..............81
14. Warranty declaration..............82
59
GB
Thank you for purchasing a Theben HTS presence detector and putting your trust in us.
1. Safety
!
CAUTION!
Danger of death through electric shock or re!
Installation should only be carried out by a qualied electrician!
Work done on electrical installations may only be conducted by an authorised electrician or
trained persons under the supervision and charge of an authorised electrician according to
electrotechnical regulations!
Observe country-specic safety guidelines for working on electric installations! The voltage
supply must be disconnected before installation!
!CAUTION!
The device is maintenance-free.The warranty terminates if the device is opened or entered with
any kind of object.
1.1 Designated use
The presence detector is intended for indoor installation.
The presence detector is solely intended for the purpose contractually specied between the
manufacturer and the user.Any other or extended use has to be regarded as not complying with
the designated use.The manufacturer is not liable for any resulting damage. Radio frequency has
to be followed.
60
2. Function and performance
The presence detector series PlanoCentro is intended for ceiling mounting.
●Installation in suspended ceilings (false ceilings)
●Installation in ush-mounted junction box (set into concrete ceiling)
Devices are available in the delivery unit with matching assembly sets for ceiling installation and
ush-mount ceiling installation.
The presence detector PlanoCentro 000 (Slave) serves to extend the detection area in combination
with a master device such as PlanoCentro 101. By relaying the presence signal the PlanoCentro
000 helps with the comfortable and energy-efcient control of lighting, HVAC and shading. The
area of preferred use includes large spaces such as ofces and classrooms.
●Detection range up to 100m2moving and 64m2seated persons at 3.5 m installation height
●Adjustable sensitivity
The PlanoCentro 000 has an output for parallel connection.
Helpful functions are available for start up and subsequent maintenance support.
●Data read-out (parameters, diagnostic and statistical data)
●Diagnostic functions
The presence detector can send conguration and diagnostic information to the SendoPro Man-
agement remote control via radio transmission (868MHz). Commands from the SendoClic remote
control cannot be processed.
61
GB
2.1 Scope of delivery
Ceiling installation
1 Presence detector with installation
protection cover (removable)
2 PlanoCap (terminal cover)
3 PlanoFix E (installation frame)
4 Strap, 6 pieces
5 PlanoCover (frame)
6 Template for ceiling cut out
7 Assembly instruction
Flush-mounted installation
1 Presence detector with installation
protection cover (removable)
2 PlanoFix U (installation plate)
3 PlanoCover (frame)
4 4 screws
5 Assembly instruction
1
1
2
2
3
3
4
4
75
5
6
62
o
7 x 7 m
9 x 9 m
o
7 x 7 m
9 x 9 m
seated persons
moving persons
3. Installation
3.1 Presence detection
The ideal installation height is between 2.0 - 3.5 m.The sensitivity of the detector reduces with higher
installation heights. The presence detector requires a clear view of people in order to clearly detect
people. Ofces, mobile partition walls, plants, hanging lighting etc. can hinder (shadowing) the pres-
ence detector.
Detection range (installation height 3.0m)
install. height seated persons moving persons
2.0 m 20 m24,5m x 4,5m 36 m26,0m x 6,0m ± 0.5m
2.5 m 36 m26,0m x 6,0m 64 m28,0m x 8,0m ± 0.5m
3.0 m 49 m27,0m x 7,0m 81 m29,0m x 9,0m ± 1.0m
3.5 m 64 m28,0m x 8,0m 100 m210,0m x 10,0m ± 1.0m
63
GB
3.2 Ceiling installation
Ceiling installation of the presence detector takes place via the PlanoFix E installation frame and
straps in the cut out ceiling element.
PlanoFix E installation frame
1. Draw ceiling cut out
(A hinge is integrated into the top of the packaging)
2. Cut out the drawn form according to the materials with suitable
tools, 100 x 100 mm ± 1mm
3. Insert 4 straps into the PlanoFix E
4. Insert the PlanoFix E into the ceiling cut out with the straps
5. By pulling on the straps and pushing against the PlanoFix E, the
PlanoFix E is snapped securely into the ceiling element.
6. Cut the ends of the 4 straps
64
Monitoring the presence detector
1. Connect wires, see technical data page 76.
2. Fasten cable to the strain relief clamps and remove the excess
3. Fasten the PlanoCap
4. Make sure the locks on the PlanoFix E are open
5. Insert the presence detector into the PlanoFix E
6. Close the locks on the PlanoFix E
7. Remove installation protection
8. Attach the PlanoCover
The technical data is to be followed during assembly and installation.
See page 78 and following.
65
GB
3.3 Flush-mounted ceiling installation
Flush-mounted ceiling installation of the presence detector takes place via PlanoFix U in a ush
mounted socket. Details about the ush mounted socket can be found in the technical data page
78, section ush mount installation. The screws included are intended for installation in the ush-
mounted socked. Suitable pan head screws are to be used for the installation of other materials.
Install presence detector with PlanoFix U
1. Connect wires, see technical data page 78.
2. Insert the presence detector into the ush-mounted junction
box (check the wire progression)
3. Screw the PlanoFix U metal plate tightly to the ush-mounted
junction box
4. Remove installation protection
5. Attach the PlanoCover
66
4. Connection / Operation mode
The presence detector PlanoCentro 000 can be used in combination with a master device such as
PlanoCentro 101 to implement parallel connections.
●Master - slave parallel switching
4.1 General parallel connecting
The parallel signal is sent via P-terminal and also received. Every detector, regardless of whether
it is master or slave, sends the presence signal via P-terminal. This enables a Master and Slaves
to be connected together with a parallel signal. See following chapter with parallel connecting
variations.
-The parallel signal is compatible with the compact range.
Parallel signal response
Room monitoring Information about room monitoring is also transmitted with the parallel signal.
!CAUTION!
Power supply:
Detectors linked to one another via the parallel signal have to be connected
to the same phase.
