Thermo Pride OH6FX072DV4R Manuale utente

2-Stage OH6 Oil Furnace

Dependable Craftsmanship

with Maximum Comfort

Your home is your castle – that’s how the saying goes. So,

when you’re looking for a new oil furnace look no further

than the ermo Pride 2-Stage OH6 oil furnace. is state-

of-the-art furnace will provide your family with luxurious

comfort and energy savings for many years to come.

e 2-Stage OH6 combines the beneﬁts of the time-tested

and proven low-proﬁle highboy OH6 oil furnace coupled

with a 2-Stage Riello oil burner and an electronically com-

mutated blower motor (ECM.) e 2-Stage burner operates

at a standard low ﬁre rate most days comfortably heating

your home and saving energy. On those bitter cold days

when your home needs the extra heat, the burner automati-

cally switches to high ﬁre providing additional warmth. e

ECM motor gives you even more comfort by operating with

inﬁnite blower speeds that automatically adjust for varying

heating and cooling modes. When heat is needed the blower

smoothly ramps up to speed gently circulating the warm

air around your home and eliminating that annoying blast

of cold air from your registers. All you feel is comfort. e

ECM motor’s inﬁnite speeds also increase your furnace eﬃ-

ciency while the motor pays for itself with dramatic electrical

savings in both the heating and cooling modes.

e 2-Stage OH6 combines all the features you would

expect from ermo Pride’s tradition of handcrafted quality

with new high-tech design.

It is backed by ermo Pride’s

Peace of Mind lifetime

limited warranty - virtually

eliminating the worry of ever having to replace your furnace

again. Should you sell your home, the warranty will auto-

matically transfer to the new homeowners.

is is the furnace you deserve – the 2-stage OH6. Today’s

state-of-the-art technology combined with ermo Pride’s

traditional hand crafted quality.

2-Stage OH6 Oil Furnace

e Ultimate in Eﬃcient

Oil Heating Comfort!

Speciﬁcations

1. Output based on Annual Fuel Utilization Efﬁciency rated by manufacturer.

2. Seasonal Efﬁciency (also called AFUE - Annual Fuel Utilization Efﬁciency) ratings are based on tests following the U.S. Department of Energy

test procedures.

3. To permit largest recommended air conditioning (at .5 static pressure), selection of the highest motor speed is required.

Form No. PL81410041003 - 1/07 - 10Ms

Printed in the U.S.A.

Phone: 574-896-2133

www.thermopride.com

Model Number OH6FX072DV4R

Heating Capacity Low Capacity High Capacity

Low Fire High Fire Low Fire High Fire

Heat Input Rate (BTUH) 70,000 85,000 85,000 106,250

Output BTUH161,500 74,000 74,000 91,000

Seasonal Efﬁciency2 (AFUE) 87.3 86.4

Largest Recommended A/C34 Tons 4 Tons

Nominal Temperature Rise 64° 64° 64° 64°

Dimensions (inches) H x W x D 45” x 20” x 30”

Nominal Flue Outlet Diameter 5”

Approximate Shipping Weight (lbs.) 250

Quantity and Size of Permanent Filters (1) 24-3/4” x 15-3/4”

Electrical Requirements 120 / 60 / 1

Maximum Fuse Size /ECM 15

Total Current (AMPS) /ECM 12.3

Height from Floor to Center of Flue 40-3/4”

Supply Air Outlet Size W x D 18” x 19”

Return Air Ductwork Connection

Flange Size on Filter D x H 24-1/2” x 15”

Return Air Inlet Opening Size in Side

Casing (to be cut-out by dealer) D x H 23” x 14”

Accessory Items

Programmable Thermostat 350866

2-Stage Burner Easy Setup

e 2-Stage burner is easy to set up and service. Your

contractor merely moves a pin and adjusts it for

low ﬁre as with a traditional burner, then moves the

pin again and sets it up for high ﬁre. Lastly, he will

move the pin to the third setting to run. e burner

will then switch from low to high ﬁre automatically

as needed. e burner is also mounted on a double

hinge making it easy to service as needed.
