ThL 4000 Manuale utente

user manual

Model name:thl 4000

Brand name:thl

Contents

Safety

....................................................................................................................3

Environment

........................................................................................................4

1 Getting Started

.................................................................................................5

1.1 Getting to know your touch phone

....................................................5

1.2 Installing the SIM card, battery, and storage card

.............................5

1.3 Charging the Battery

..........................................................................6

1.4 Starting up the device

.........................................................................7

1.5 Status Icons

........................................................................................9

2 Using phone features

.....................................................................................11

2.1 Turning the phone function on and off

............................................11

2.2 Making a call

...................................................................................11

2.3 Answering and Ending a call

...........................................................12

2.4 In-call options

..................................................................................12

2.5 Using call history

.............................................................................13

2.6 Call settings

......................................................................................13

3 Setting on your device

....................................................................................14

4 ActiveSync

.......................................................................................................17

5 Contacts

..........................................................................................................20

6 Exchanging Messages

....................................................................................22

7 Internet

...........................................................................................................27

7.1 Ways of Connecting to the Internet

.................................................27

7.2 Browser

............................................................................................27

8 Experiencing Multimedia

..............................................................................29

8.1 Camera & Picture

.............................................................................29

8.2 Music

................................................................................................32

8.3 FM Radio

.........................................................................................34

8.4 Sound record

....................................................................................34

9 Other applications

..........................................................................................34

9.1 Calendar...........................................................................................34

9.2 Alarm Clock.....................................................................................35

9.3 Calculator.........................................................................................36

10 Play Store*....................................................................................................37

Safety

Never attempt to disassemble your phone. You alone are responsible for how

you use your phone and any consequences of its use.

As a general rule, always switch off your phone wherever the use of a phone is

prohibited. Use of your phone is subject to safety measures designed to protect

users and their environment.

Do not use your phone in damp areas (bathroom, swimming pool…). Protect it

from liquids and other moisture.

Do not expose your phone to extreme temperatures lower than - 10°C and

higher than + 55°C.

The physicochemical processes created by chargers impose temperature limits

when charging the battery. Your phone automatically protects the batteries in

extreme temperatures.

Do not leave your phone within the reach of small children (certain removable

parts may be accidentally ingested).

Electrical safety: Only use the chargers listed in the manufacturer’s catalogue.

Using any other charger may be dangerous; it would also invalidate your

warranty. Line voltage must be exactly the one indicated on the charger’s serial

plate.

Aircraft safety: When traveling by plane, you will need to switch your phone

off when so instructed by the cabin crew or the warning signs.

Using a mobile phone may be dangerous to the operation of the aircraft and may

disrupt the phone network.

Its use is illegal and you could be prosecuted or banned from using cellular

networks in the future if you do not abide by these regulations.

Explosive materials: Please comply with warning signs at petrol station asking

you to switch your phone off. You will need to comply with radio equipment

usage restrictions in places such as chemical plants, fuel depots and at any

location where blasting operations are under way.

Electronic equipment: To avoid the risk of demagnetization, do not let

electronic devices close to your phone for a long time.

Electronic medical equipment: Your phone is a radio transmitter which may

interfere with electronic medical equipment or implants, such as hearing aids,

pacemakers, insulin pumps, etc. It is recommended that a minimum separation

of 15 cm be maintained between the phone and an implant. Your doctor or the

manufacturers of such equipment will be able to give you any advice you may

need in this area.

Hospitals: Always make sure that your phone is switched off in hospitals when

so instructed by warning signs or by medical staff.

Road safety: Do not use your phone when driving. In order to give your full

attention to driving, stop and park safely before making a call. You must comply

with any current legislation.

Distance of operation: This phone model has been tested and meets

radiofrequency exposure guidelines when used as follows:

• Against the ear: Place or receive a phone call and hold the phone as you would

a wire line telephone.

• Body worn: When transmitting, place the phone in a carry accessory that

contains no metal and positions the phone a minimum of 1.0 cm form your body.

Use of other accessories may not ensure compliance with radiofrequency

exposure guidelines. If you do not use a body worn accessory and are not

holding the phone at the ear, position the phone a minimum of 1.0 cm from your

body,

• Data operation: When using a data feature, position the phone a minimum of

1.0 cm from your body for the whole duration of the data transmission.

Environment

Packaging: To facilitate the recycling of packaging materials, please obey the

sorting rules instituted locally for this type of waste.

Batteries: Spent batteries must be deposited at the designated collection points.

The product: The crossed-out waste bin mark affixed to the product means that

it belongs to the family of electrical and electronic equipment.

To promote the recycling and recovery of waste electrical and electronic

equipment (WEEE) and at the same time safeguard the environment, European

regulations require you to obey the sorting rules instituted locally for this type

of waste.

1 Getting Started

1.1 Getting to know your touch phone

1.2 Installing the SIM card, battery, and storage card

You need to remove the back cover before you can install the SIM card and

battery. Also, make sure to always turn off the power before installing or

replacing the SIM card and battery.

To remove the back cover

1. Make sure your device is turned off.

2. Firmly hold the device with both hands and the front panel facing down.

3. Push the back cover up with your thumbs until it disengages from the device

and then slide it up to remove.

To remove the battery

1. Make sure your device is turned off.

2. Remove the back cover.

3. The bottom of the phone has a notch. Lift the battery by the notch to remove

it.

To install the SIM card

The SIM card contains your phone number, service details, and phonebook/

message memory. Your device is supported both 2G and 3G (WCDMA) SIM

cards.

1. Remove the battery if it is installed.

2. Locate the SIM card slot, and then insert the SIM card with its gold contacts

facing down and its cut-off corner facing out the card slot.

3. Slide the SIM card completely into the slot.

Note: • The phone can be supported the double SIM cards. The card slot

1/2 will be both supported 3G SIM card (WCDMA), but one SIM card can

use 3G networks only.

If you need to use 3G operation, please insert 3G card in the card slot

1(Default SIM1 card, defined in the menu Settings/More…/Mobile

networks/Preferred networks type), the SIM2 card will be supported 2G

network only (If insert 3G card in the card slot 2, you can also use 2G

operation only).

• Some legacy SIM cards may not function with your device. You should

consult with your service provider for a replacement SIM card. There may

be fees for this service.

To install a memory card

To have additional storage for your images, videos, music, and files, you can

purchase a memory card and install it into your device.

1. Make sure that your device is turned off, and then remove the back cover.

2. Locate the memory card slot on the upper part of the exposed right panel.

3. Insert the memory card into the slot with its gold contacts facing down until it

clicks into place.

Note: To remove the memory card, press it to eject it from the slot.

To install the battery

Your device comes with a rechargeable Lithium-ion battery and is designed to

use only manufacturer-specified original batteries and accessories. Battery

performance depends on many factors, including network configuration, signal

strength, and usage patterns.

Warning: To reduce risk of fire or burns:

• Do not attempt to open, disassemble, or service the battery pack.

• Do not crush, puncture, short external contacts, or dispose of in fire or water.

• Replace only with the battery pack designated for this product.

• Recycle or dispose of used battery as stipulated by local regulations.

1. Align the battery’s exposed copper contacts with the battery connectors at the

bottom part of the battery compartment.

2. Insert the contacts side of the battery first and then gently push the battery

into place.

3. Replace the back cover.

1.3 Charging the Battery

New batteries are shipped partially charged. Before you start using your device,

it is recommended that you install and charge the battery. Some batteries

perform best after several full charge/discharge cycles.

Note: Only the AC adapter and USB sync cable provided with your device must

be used to charge the device.

Connect the USB connector of the AC adapter to the sync connector on your

device, and then plug in the AC adapter to an electrical outlet to start charging

the battery.

As the battery is being charged while the device is on, a charging icon appears

in the title bar of the Home screen. After the battery has been fully charged, a

full battery icon appears in the title bar of the Home screen.

Warning: • Do not remove the battery from the device while you are charging it

using the AC or car adapter.

• As a safety precaution, the battery stops charging before it overheats.

1.4 Starting up the device

Power on/off

To power off your phone, press & hold POWER. On release, the Phone options

menu opens. Select ‘Power off’ and confirm.

To power on again, press & hold POWER.

Silent mode

To silence your phone quickly, press & hold the – volume button to zero volume.

Or on the Home screen, touch and select Settings > Audio profiles >

‘Silent’check box.

Screen sleep

After a period of inactivity, your screen will go to sleep (display will turn black).

In sleep, your phone uses less battery power. You can control this behavior:

Set screen timeout period

1. On the Home screen, touch and select Settings.

2. Select Display > Screen timeout. Select a time from the menu.

Prevent sleep while charging

1. On the Home screen, then touch and select Settings.

2. Select Developer options > ‘Stay awake’ check box.

Lock screen & put phone to sleep

Except when on a phone call, from any screen, press POWER (immediately).

While not on a call, to lock your control buttons and screen from accidental

touch activation, press POWER.

You can increase the security of your phone by setting ‘Screen lock’ pattern.

Once set, in order to unlock your screen, you’ll have to draw the correct unlock

pattern. You can set your screen unlock pattern as follows:

1. On the Home screen, touch and select Settings.

2. Select Security and then scroll down to ‘Screen lock’pattern.

3. Set or change your unlock pattern by selecting ‘Screen lock’ pattern, as

applicable.

4. Follow the prompts to define your pattern.

Note: You must slide your finger along the screen to create the pattern, not

select individual dots. Connect at least four dots.

If you want your pattern to be hidden as you draw it, clear ‘Make pattern

visible’check box.

Home screen

The Home screen is your starting point for using all the applications on your

phone. You can customize your Home screen to display applications, shortcuts,

and widgets as you like.

1. The Home screen actually extends beyond the screen width. On Home screen,

slide your fingertip left and right along the screen to reveal the full width of the

Home screen. This additional space gives you more room to customize Home

with applications, shortcuts, and widgets.

2. Create Home screen shortcuts and widgets:

• On Home screen, touch MENU or touch and hold the blank screen with your

fingertip to reveal the widgets.

• Touch and hold to pick up an Application shortcut, a Shortcut to some of your

saved information (such as a play list), a Widget (a clock or picture frame) for

your Home screen. You can place the widget slide your fingertip right along the

screen to reveal the width of the Home screen.

• The application, shortcut, folder, or widget appears on Home screen.

3. To create an application shortcut quickly, touch the application tab to reveal

all the application icons, then touch & hold an application icon. Its shortcut is

added to the Home screen; close the application tab to see it.

4. To remove a shortcut or widget from your Home screen, touch & hold the

item to enter “Remove mode”. Drag the item to ‘Remove’ button and release.

You’ll know when your item is in ‘Remove’ because the item and the tab will

turn red.

5. Move objects on the Home screen

• To move an icon or other item on the Home screen, you must first touch &

hold it to enter ‘Remove mode’. The object will magnify when it’s ready to be

moved.

• Without lifting your finger (or you’ll drop out of remove mode), drag the

object to the new position. To move an item to a section of the Home screen not

in view, move it to the edge of the screen and hold it there for a moment. The

screen view will shift; position the object and release.

1.5 Status Icons

Connection status icons

Along the top of your phone screen is the status bar. On the left side, icons will

appear, notifying you of a new message, upcoming calendar event, or something

else you should notice. On the right side of the status bar, you’ll see connection

status icons.

Network signal

Sign-in/sync error

EDGE service

connected, data

flowing

WCDMA service

connected, data

flowing

Call forward

Song is playing

Missed call WLAN service

connected

SMS/MMS

Call in progress

Alarm is set Wireless services are

off (Airplane mode)

Indice

Altri manuali ThL Telefono cellulare

ThL

ThL T200 Manuale utente

Manuali Telefono cellulare popolari di altre marche

Zte

Zte BLADE A520 Manuale utente

Nokia

Nokia Lumia 620 Manuale utente

Blackbe;rry

Blackbe;rry KEYone Manuale utente

Bea-fon

Bea-fon X5 Premium Manuale utente

Blackbe;rry

Blackbe;rry 8707 Series Manuale utente

Blackbe;rry

Blackbe;rry Storm Istruzioni operative

LG LM-X420QN Manuale utente

LifeWatch

LifeWatch V Manuale utente

Bea-fon

Bea-fon SILVER LINE SL860 Manuale utente

IKI Mobile

IKI Mobile KF4.5i Manuale utente

Hitech

Hitech HT-850 Manuale utente

Yezz

Yezz Fashion F10 Manuale utente

Point Mobile

Point Mobile PM60 Manuale utente

Blackbe;rry

Blackbe;rry Q10 Manuale utente

Blackbe;rry

Blackbe;rry Bold 9900 Manuale utente

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuale utente

LG LM-K420EMW Manuale utente

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuale utente
