thomann Stage TRI LED Bundle Complete Manuale utente
Stage TRI LED Bundle
Complete
LED lighting set
user manual
Musikhaus Thomann e.K.
Treppendorf 30
96138 Burgebrach
Germany
Telephone: +49 (0) 9546 9223-0
E-mail: [email protected]
Internet: www.thomann.de
08.01.2013
Table of contents
1 General notes............................................................................................................................................... 5
2 Safety instructions..................................................................................................................................... 8
3 Features....................................................................................................................................................... 13
4 Installation.................................................................................................................................................. 14
5 Starting up.................................................................................................................................................. 19
6 Connections and operating elements........................................................................................... 22
7 Operation.................................................................................................................................................... 27
7.1 Starting up the device.................................................................................................................... 27
7.2 Main menu.......................................................................................................................................... 27
7.3 Menu overview................................................................................................................................. 34
7.4 Functions in 2-channel DMX mode (d.-P5)............................................................................. 37
7.5 Functions in 3-channel DMX mode (d.-P1)............................................................................. 39
7.6 Functions in 4-channel DMX mode (d.-P2)............................................................................. 40
7.7 Functions in 7-channel DMX mode (d.-P7)............................................................................. 40
7.8 Functions in 8-channel DMX mode (d.-P3) ............................................................................ 43
Table of contents
Stage TRI LED Bundle Complete
3
7.9 Functions in 14-channel DMX mode (d.-P4).......................................................................... 44
7.10 Functions in 15-channel DMX mode (d.-P6)........................................................................ 46
7.11 Functions of foot switch.............................................................................................................. 47
8 Technical specifications....................................................................................................................... 49
9 Cleaning....................................................................................................................................................... 50
10 Protecting the environment.............................................................................................................. 51
Table of contents
LED lighting set
4
1 General notes
This user manual contains important information on safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to other users, be sure
that they also receive this manual.
Our products are subject to a process of continuous development. We therefore reserve the
right to make changes without notice.
General notes
Stage TRI LED Bundle Complete
5
This section provides an overview of the symbols and signal words used in this user manual.
Signal word Meaning
DANGER! This combination of symbol and signal word
indicates an immediate dangerous situation
that will result in death or serious injury if it is
not avoided.
WARNING! This combination of symbol and signal word
indicates a possible dangerous situation that
can result in death or serious injury if it is not
avoided.
NOTICE! This combination of symbol and signal word
indicates a possible dangerous situation that
can result in material and environmental
damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
Symbols and signal words
General notes
LED lighting set
6
Warning signs Type of danger
Warning – hot surface.
Warning – danger zone.
General notes
Stage TRI LED Bundle Complete
7
2 Safety instructions
This device is intended to be used as an electronic illumination effect using LED technics. Use
the device only as described in this user manual. Any other use or use under other operating
conditions is considered to be improper and may result in personal injury or property damage.
No liability will be assumed for damages resulting from improper use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
Intended use
Safety
Safety instructions
LED lighting set
8
DANGER!
Electric shock caused by short-circuit
Do not modify the mains cable or the plug. Failure to do so could result in electric
shock/death or fire. If in doubt, seek advice from a registered electrician.
DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
Safety instructions
Stage TRI LED Bundle Complete
9
DANGER!
Electric shock caused by short-circuit
Always use proper ready-made insulated mains cabling (power cord) with a pro‐
tective contact plug. Do not modify the mains cable or the plug. Failure to do so
could result in electric shock/death or fire. If in doubt, seek advice from a regis‐
tered electrician.
WARNING!
Eye damage caused by high light intensity
Never look directly into the light source.
WARNING!
Risk of epileptic shock
Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons
should avoid looking at strobe lights.
Safety instructions
LED lighting set
10
