THOMSON DPL915VD-DVD Manuale utente

DVD Player

Basic Playback Features

1. Press SOURCE on the main unit until “DVD/CD” appears

on the display or DVD source key on the remote to select

DVD/CD input source.

2. Open disc tray for loading

discs with label side facing

up. Press again to close it.

3. Press PLAY/PAUSE on the unit or PLAY on the remote

control to start playback

• Press PLAY/PAUSE on the unit or PAUSE to pause playing

during playback. Press PLAY/PAUSE on the main unit or

PLAY on the remote to resume normal playback.

• Press SKIP REVERSE to go back to the previous chapter

or SKIP FORWARD to move to the next chapter.

• Press STOP once to stop playback and go into resume

mode.

Quick search

1. While playing a disc, press REVERSE on the remote con-

trol to scan backwards through the disc. Press FORWARD

on the remote for scanning forward.

Press repeatedly to change searching speed to 1,2 or 3

times for VCD and 1,2,3 or 4 for DVD.

2. Press PLAY at any time to resume normal playback.

Freeze frame, frame advance and frame

backward

1. Press PAUSE to freeze picture during playback. Each time

you press again, the picture advances one frame.

2. Press PAUSE repeatedly to move forward in still frame.

3. Press PLAY to resume normal playback.

DIGITAL BAN

RPT

mp3

ET +

OUND

SURROUND

SOURCE

PRESET -PRESET +

DIGITAL BAND/APP

RPT/PGM

TUNE -

mp3

SET +

ROUND

SURROUND

/ ECO

SOURCE

PRESET -PRESET +

SAT/

CAB

VIDEO/

VCR ok

DIGITAL

PRO.LOGIC

INTRORANDOM

LCR

LFE

DVD

VCD

MP3

mp3

ET +

OUND

NOTE

RESUME MODE:

The next time PLAY is pressed, the unit will begin

playback at the location where it was last stopped.

Press STOP again on the remote control to cancel

the resume mode.

NOTE

Remote control selector must be on

dvd/cd.

DVD Player

Slow motion playback

1. Press PLAY/PAUSE on the main unit or PAUSE in the

remote control to freeze the picture during playback.

2. Advance picture in slow motion. Press FAST FORWARD

on the unit or FORWARD on the remote control for slow

motion in forward direction. Press FAST REVERSE or

REVERSE for slow motion in reverse direction (DVD only).

Press repeatedly to change speed to 1/16 times, 1/8 times,

1/4 times and 1/2 times.

3. Press PLAY/PAUSE on the main unit or PLAY on the

remote control to resume normal playback.

On-screen banner display

You can access the on-screen banner display during play-

back to select many playback features. Each feature is illus-

trated with an icon. However, each banner display feature

is available only if the disc was created with that particular

feature.

An invalid icon appears on the screen when you

select an icon that does not function. Also, the icon

is “grayed out” to tell you so.

General use

1. Set Remote control selector to dvd/cd.

2. Press INFO on the remote

control during playback to

show on-screen banner.

3. Use the LEFT or RIGHT arrows on the remote control to

move cursor on the banner. Selected feature icon will be

highlighted. Press OK to open menu under selected

feature.

3. Alternatively, press the

corresponding menu button

to access menu directly

- Audio language

selection menu

- Subtitle language

selection menu

title - Title selection meu

- Angle selection menu

SET +

OUND

ET +

UND

AL BAND/APP

RPT/PGM

TREBLE

TUNE -TUNE +

Title Audio

Subtitles

Camera angles Disc type

Chapter Bookmarks

Time

indicator

Title icon is being

highlighted in

this example

SAT/

CAB

VIDEO/

VCR ok

SAT/

CAB

VIDEO/

VCR ok

SAT/

CAB

VIDEO/

VCR ok

NOTE

Remote control selector must be on

dvd/cd.

SAT/

CAB

VIDEO/

VCR ok

DVD Player

Selecting a title

1. Refer to previous page “General use” to open the title

menu.

2. Enter title number using the number keys on the remote

control. Add 0 in front of single-digit title number

(e.g. 9 = 09).

Selecting a chapter

1. Refer to previous page “General use” to open the title

menu.

2. Enter chapter number using the number keys on the

remote control. Add 0 in front of single-digit chapter

number (e.g. 9 = 09)

Selecting audio language

1. Refer to the previous page “General use” to open the

title menu.

2. Press OK repeatedly until the audio language you want

appears on the banner. Press INFO to exit.

Selecting subtitle language

1. Refer to previous page “General use” to open the subti-

tle menu.

2. Press OK to select and confirm subtitle language.

4. Press the SUBTITLE button to turn subtitles on or off .

5. Press INFO to exit.

NOTE

Some discs have one title only.

NOTE

The chapter feature will not work if the disc is not

formatted with separate chapters.

NOTE

This feature only works if the disc was created with

multiple audio tracks.

SAT/

CAB

VIDEO/

VCR ok

SAT/

CAB

VIDEO/

VCR ok

SAT/

CAB

VIDEO/

VCR ok

NOTE

This feature only works if the disc was created with

subtitles.

SAT/

CAB

VIDEO/

VCR ok

SAT/

CAB

VIDEO/

VCR ok

DVD Player

Selecting camera angle

1. Refer to page 20 “General use” to open the camera

angle menu.

2. Press the Angle button to select the camera angle you

want.

3. Press INFO to exit.

Using bookmarks

The bookmark feature allows you to mark a point on the

disc that you can go to quickly. You can store up to 9

bookmarks.

Adding bookmarks

1. Refer to Page 20 “General use” to open the bookmark

menu.

2. Use the arrows on the remote to move the cursor (yellow

frame) to the “Mark” check line, then press OK to add

bookmark when you reach the scene you want to do so.

3. To add another bookmark, move the cursor to the right

with arrow button and then press OK when you reach

another scene you want to do so.

4. Move cursor to the door icon and then press OK

to exit menu.

Recalling bookmarks

1. Refer to page 20 “General use” to open the bookmark

menu.

2. Use the arrows on the remote to move cursor (yellow

frame) to the “Go To” check line and to the bookmarked

scene you want to recall.

3. Press OK to recall bookmarked scene.

4. Move cursor by using the arrows to the door icon

and then press OK to exit menu.

Clearing bookmarks

The bookmarks are cleared each time a disc is removed

from the player or when the power is turned off

completely.

If all 9 bookmarks are in use, you can still mark new scenes

but the previous bookmarks will be erased starting from

the earliest one.

SAT/

CAB

VIDEO/

VCR ok

NOTE

This feature only works if the disc was created with

multiple angles.

SAT/

CAB

VIDEO/

VCR ok

SAT/

CAB

VIDEO/

VCR ok

DVD Player

Repeat (During Playback Only)

1. During playback, press the RPT/PGM button on the

main unit repeatedly to select among the repeat modes -

Repeat Disc > Repeat Title > Repeat Chapter >

Repeat Off > (Repeat Disc). Selected mode is displayed in

the banner display on screen.

Program playback

Edit program

1. In stop mode, press and hold RPT / PGM on the main

unit to display program edit playlist.

2. The box under “Title” will be highlighted automatically.

Use the arrows on the remote to select title and chapter.

3. “Add” will be highlighted automatically after chapter is

selected. Press OK to add selected track and chapter(s) onto

playlist.

4. Move to highlight “Play” (start program playback) or

“Done” (return normal playback with program saved), then

press OK to start program playback or return to stop mode.

GITAL TREBLE

TUNE -TUNE +

BAND/APP

RPT/PGM

IGITAL TREBLE

TUNE -TUNE +

BAND/APP

RPT/PGM

SAT/

CAB

VIDEO/

VCR ok

SAT/

CAB

VIDEO/

VCR ok

SAT/

CAB

VIDEO/

VCR ok

NOTE

• Repeat and Random features are only availabe in

VCD mode when PBC is off

• Random feature not available for DVD playback.

NOTE

You can select at maximum 32 items by repeating

steps 2 - 3.

SAT/

CAB

VIDEO/

VCR ok

DVD Player

Delete program

1. In stop mode, press and hold RPT / PGM on the main

unit to display program edit playlist.

2. Use the arrows on the remote to select and highlight the

programmed item you want to delete on the playlist.

3. Highlight “Delete” and then press OK to delete item.

4. Repeat steps 2 and 3 to delete additional items.

5. Use the arrows to select and highlight “Play” (start pro-

gram playback) or “Done” (return to normal playback with

program saved) and then press OK.

Insert chapter

1. In stop mode, press and hold RPT / PGM on the main

unit to display program edit playlist.

2. Use the UP or DOWN arrows to select and highlight item

on the playlist where you want to insert a chapter before

it.

3. Use the LEFT and RIGHT arrows to select Title or

Chapter, then the UP and DOWN arrows to select the

number.

4. Use the LEFT and DOWN arrows to highlight “Insert”

and then press OK.

5. Use the arrow buttons to highlight “Play” (start program

playback) or “Done” (return to normal playback with pro-

gram saved) and then press OK.

Cancel program

Program will be cancelled when;

1. disc tray is opened;

2. power is turned off;

3. STOP is pressed twice. The red PGM indicator will disap-

pear on display and player will resume normal playback

mode. Nevertheless, the program will remain in memory

and can be recalled by pressing PROGRAM again.

SAT/

CAB

VIDEO/

VCR ok

SAT/

CAB

VIDEO/

VCR ok

SAT/

CAB

VIDEO/

VCR ok

SAT/

CAB

VIDEO/

VCR ok

SAT/

CAB

VIDEO/

VCR ok

SAT/

CAB

VIDEO/

VCR ok

NOTE

Remote control selector must be on

dvd/cd.

DVD Player

Set up menu

General use

1. Press MENU in stop mode to display the set up menu on

screen. The menu shows current settings.

2. Use arrow buttons to highlight options and press OK to

open selected menu.

3. Press LEFT arrow to go back to the previous menu.

Audio language

This step will define the default audio language. Choosing

an audio language from the on-screen banner display will

only overwrite this setting temporarily.

1. Refer to “General use” to open audio language menu.

2. Use UP and DOWN arrows to select language and then

press OK.

For languages other than options available:

3. Press DOWN to select “Other” and then press OK.

4. Enter language code into boxes and then select OK to

return to main menu. Press OK on the remote. (Refer to

page 45 for Language Code)

VIDEO/

VCR ok

SAT/

CAB

VIDEO/

VCR ok

SAT/

CAB

VIDEO/

VCR ok

SAT/

CAB

VIDEO/

VCR ok

NOTE

if you press during disc playback, the disc’s own

menu will be displayed.

NOTE

If language selected is not available on disc, the

language designated as default by each disc will

be selected.

SAT/

CAB

VIDEO/

VCR ok

NOTE

Remote control selector must be on

dvd/cd.

DVD Player

Subtitle language

This step will define the default subtitle language.

Choosing a subtitle language from the on-screen banner

display will only overwrite this setting temporarily.

1. Refer to page 25 “General use” to open subtitle

language menu.

2. Press UP and DOWN arrow to select language and then

press OK.

For languages other than options available:

3. Move down and select “Other” and then press OK.

4. Enter language code into boxes (refer to page 45 for

language code) and then select OK to return to main

menu. Press OK button on the remote.

Menu language

This step will define the language of menus and other

short messages shown on screen.

1. Refer to page 25 “General use” to open menu language

menu.

2. Use the UP and DOWN arrows to scroll the selections

and select the language and then press OK to return to

main menu.

SAT/

CAB

VIDEO/

VCR ok

SAT/

CAB

VIDEO/

VCR ok

NOTE

If language selected is not available on disc, the

language designated by each disc as default will be

selected.

SAT/

CAB

VIDEO/

VCR ok

DVD Player

Rating (Parental control)

This step will disable the playing of some DVDs (especially

U.S. type) which are not suitable for some audience, e.g.

children. Such kind of DVDs is encoded with a specific rat-

ing level. If the rating level of the disc is higher than the

preset level (to be set in this step), the playing will be pro-

hibited unless the password (see next step) is entered.

1. Refer to page 25 “General use” to open the rating menu.

2. Use the UP or DOWN arrows to highlight the rating that

would require a password to play. Press OK to return to

main menu. Ratings highlighted in blue require password.

The rating systems is based on information encoded on the

DVD disc being played, so movies may carry a rating sym-

bol, the disc may or may not contain that rating in its soft-

ware. In addition to the five standard (MPAA) rating sym-

bols of “G” (level 2), “PG” (Parental Guidance, level 4),

“PG13” (Parental Guidance and 13 years old, level 4), “R”

(Restricted, level 6) and ”NC17” (from 17 years old, level 7),

the DVD will accommodate a total of 8 rating steps, as set

by the DVD makers. These additional steps allows for more

critical control of program playback for all audiences.

Level 8: All DVDs can be played (Factory preset).

Level 7 to 2: DVDs for general audiences/ children can be

played.

Level 1: DVDs for children can be played, DVDs for adults/

general audiences are prohibited.

Password

Set password

To disable the viewing of rated DVDs, a four-digit password

must be selected.

1. Refer to page 25 “General use” to open the “Set

Password” menu.

2. Select “Set Password” and press OK.

3. Use the number buttons to enter password and then

press OK.

4. Repeat step 3 to confirm password.

SAT/

CAB

VIDEO/

VCR ok

SAT/

CAB

VIDEO/

VCR ok

DVD Player

Change password

Current password must be entered first to change

password.

1. Refer to page 25 “General use” to open the password

menu.

2. Use the number buttons to enter password and then

press OK.

3. Use the UP and DOWN arrows to select “Change

Password” and then press OK.

4. Use the number buttons to enter new password and

then press OK.

5. Repeat the above step to confirm password and return

to password menu. Use the LEFT arrow to return to the

main menu.

Clear password

1. Refer to page 25 “General use” to open the password

menu.

2. Use the number buttons to enter password and then

press OK.

3. Move up or down the menu using the UP or DOWN

arrows and select “Clear Password”. Press OK to clear pass-

word. Use the LEFT arrow to return to the main menu.

NOTE

• When incorrect password is entered, new

password menu appears and you can enter and

confirm password again.

• A lock icon shows on unit display when password

is required to view rated discs.

Important: keep the password in a safe place or

remember it reliably as access to rated discs or

rating/ password menus requires the correct

password.

SAT/

CAB

VIDEO/

VCR ok

SAT/

CAB

VIDEO/

VCR ok

SAT/

CAB

VIDEO/

VCR ok

Indice

Altri manuali THOMSON Lettore DVD

THOMSON

THOMSON DTH 270 Manuale utente

THOMSON

THOMSON DPL930VD Manuale utente

THOMSON

THOMSON DTH6350E Manuale utente

THOMSON

THOMSON DVD3660H Manuale utente

THOMSON

THOMSON DTH210U Manuale utente

THOMSON

THOMSON DTH616 - annexe 1 Manuale utente

THOMSON

THOMSON DTH115E Manuale di istruzioni

THOMSON

THOMSON etc011 Manuale utente

THOMSON

THOMSON DTH460E Manuale utente

THOMSON

THOMSON DVDPB-10 Manuale utente

THOMSON

THOMSON DTH8000 Manuale utente

THOMSON

THOMSON DPL950 - RECEIVER Manuale utente

THOMSON

THOMSON DTH720 Manuale utente

THOMSON

THOMSON DTH6100 Manuale utente

THOMSON

THOMSON DTH175EL Manuale utente

THOMSON

THOMSON DTH160E Manuale utente

THOMSON

THOMSON DTH616 - annexe 1 Manuale utente

THOMSON

THOMSON DTH227E Manuale utente

THOMSON

THOMSON DTH111E Manuale utente

THOMSON

THOMSON DTH 250E - ADDENDUM Manuale utente

THOMSON

THOMSON DTH8040E Manuale utente

THOMSON

THOMSON DTH8657E Manuale utente

THOMSON

THOMSON DTH8005E Manuale utente

THOMSON

THOMSON DTH220U Manuale utente

Manuali Lettore DVD popolari di altre marche

Sony

Sony DVP-F11 Manuale utente

Philips

Philips DVP3560K/F8 Manuale utente

LENCO

LENCO DVP-740 X2 Manuale utente

JVC

JVC XV-N650BEU Manuale utente

Aiwa

Aiwa XD-DV370 Manuale utente

MedeaWiz

MedeaWiz Sprite 4K DV-S4 Manuale utente

Denon

Denon DVM-1805 - DVD Changer Manuale utente

Toshiba

Toshiba SD-3815 Manuale utente

Tevion

Tevion 44330 Manuale utente

Samsung

Samsung DVD-HD860 Manuale utente

Sylvania

Sylvania DP170SL8 Manuale utente

Toshiba

Toshiba SD-P1200 Manuale utente

JVC

JVC XV-D9000E Manuale utente

Dolby Laboratories

Dolby Laboratories CP650 Manuale utente

Philips

Philips DVD737K/931 Manuale utente

Denon

Denon DVD-5900 Manuale utente

Philips

Philips DVD 951 Manuale utente

Philips

Philips DVDR3460 Manuale utente
