THOMSON SPEEDTOUCH 330 - Manuale utente
SpeedTouch™
USB/330
ADSL USB Modem
Installation and User’s Guide
300
SERIES
3EC 36716 BAAA TCZZA Ed. 01
SpeedTouch™
USB/330
Installation and User’s Guide
RFC1483 Bridged
3EC 36716 BAAA TCZZA Ed. 01
Status Released
Change Note PeckelbeenS
Short Title CD-UG STUSB/330 R2.0 RFC en
Copyright © 2002 THOMSON multimedia. All rights reserved. Passing on, and copying of this docu-
ment, use and communication of its contents is not permitted without written authorization
from THOMSON multimedia. The content of this document is furnished for informational
use only, may be subject to change without notice, and should not be construed as a commit-
ment by THOMSON multimedia. THOMSON multimedia assumes no responsibility or
liability for any errors or inaccuracies that may appear in this document.
3EC 36716 BAAA TCZZA Ed. 01 1
Contents
1 SpeedTouch™ Introduction.......................................... 3
2 Get Acquainted to the SpeedTouch™......................... 5
2.1. First Steps ............................................................................................................. 6
2.2. What You Need ................................................................................................... 7
2.3. SpeedTouch™ Support ....................................................................................... 8
3 SpeedTouch™ for Microsoft Windows ........................ 9
3.1. Installing the SpeedTouch™............................................................................. 10
3.2. Using the SpeedTouch™................................................................................... 16
3.2.1. Bridging Connections.....................................................................................................................17
3.2.2. Bridged PPPoE Connections ........................................................................................................18
4 SpeedTouch™ for Mac OS .......................................... 19
4.1. Installing the SpeedTouch™............................................................................. 20
4.2. Using the SpeedTouch™................................................................................... 23
4.2.1. Bridging Connections.....................................................................................................................24
4.2.2. Bridged PPPoE Connections ........................................................................................................25
23EC 36716 BAAA TCZZA Ed. 01
5 Troubleshooting ........................................................... 27
1 SpeedTouch™ Introduction
3EC 36716 BAAA TCZZA Ed. 01 3
1 SpeedTouch™ Introduction
Welcome to the SpeedTouch™USB and SpeedTouch™330 ADSL USB modems !
With the Award-winning SpeedTouch™ Asymmetric Digital Subscriber Line (ADSL)
modem surfing the Internet will become a whole new experience.
With download speeds up to 8 Megabits per second (Mbps), your SpeedTouch™ is the
ideal solution for exploring the Internet, high-speed interactive gaming and enjoying
online audio and video streaming.
With the included installation CD-rom the installation of the SpeedTouch™ is really
straightforward : surfing the Internet is only a few clicks away.
Terminology For readability, both the SpeedTouch™USB and SpeedTouch™330 will be referred to as
SpeedTouch™ further in this User's Guide.
Safety instructions Prior to connecting the SpeedTouch™, read the Safety Instructions.
Trademarks The following trademarks are used in this document:
•SpeedTouch™ is a trademark of THOMSON multimedia.
•Windows™ and Internet Explorer™ are trademarks of Microsoft Corporation.
•Apple® and Mac® OS are registered trademarks of Apple Computer Inc.
•Netscape® and Netscape Navigator® are registered trademarks of Netscape
Communications Corporation.
Other products may be trademarks or registered trademarks of their respective manu-
facturers.
3EC 36716 BAAA TCZZA Ed. 01
1 SpeedTouch™ Introduction
4
Service Provider For readability, the term Service Provider (SP) will be used to designate all organizations
which provide either DSL connectivity, Internet access or Corporate access, for
example an Internet Service Provider (ISP).
SpeedTouch™
documentation and
software updates
Due to the continuous evolution of ADSL technology, existing products are regularly
upgraded.
For more information on the newest technological breakdowns, software upgrades, and
documents, please consult:
•http://www.speedtouch.com
2 Get Acquainted to the SpeedTouch™
3EC 36716 BAAA TCZZA Ed. 01 5
2 Get Acquainted to the SpeedTouch™
Introduction This chapter will assist you in getting acquainted with the SpeedTouch™ and will guide
you through the first steps in preparing the SpeedTouch™ for Internet connectivity.
In this chapter
Topic Page
2.1. First Steps 6
2.2. What You Need 7
2.3. SpeedTouch™ Support 8
3EC 36716 BAAA TCZZA Ed. 01
2 Get Acquainted to the SpeedTouch™
6
2.1. First Steps
Delivery check Check your SpeedTouch™ package for the following items:
•The SpeedTouch™USB or SpeedTouch™330
•2m DSL cable (RJ11/RJ11, RJ14/RJ14)
•The SpeedTouch™ Installation CD-rom.
Damaged or missing
items
In the event of damaged or missing items, contact your local product dealer for further
instructions.
Other materials Your SpeedTouch™ shipping carton may also include release notes, safety and confor-
mity declarations and other materials.
Your SpeedTouch™ Unlike most traditional modems, the electronic circuitry of the SpeedTouch™ has been
shaped into a stylish body. The input/output wiring is moulded in an ergonomically
designed pigtail.
On the rear end of the pigtail you find the USB connector. That's the interface which
connects the SpeedTouch™ to your Personal Computer (PC). The ADSL Line port is
situated in the inline receptacle. This port connects the SpeedTouch™ to the ADSL
highway.
Note: As you notice, there is no separate mains plug, cord, or power adapter. This is
because the SpeedTouch™ is powered via the USB connection.
