THOMSON CS186 Manuale utente

THOMSON

46, quai Alphonse Le Gallo

92648 Boulogne

Cedex FRANCE

www.thomson.net

56123200

CS186 EN 8/2/06 2:10 PM Page 2

SOURCEBACKS

ELECT

PHONES

BAND/INFORECORDDELETETUNE/PRESET

DEMO/DIMMER

CD-R/RWCOMPATIBLE

ON/ECO

DIGITAL MUSIC STUDIO

CS186

Sleep

CDCDCD

USB

CS186

It is important to read this instruction book prior to using your new product for the first time.

user

manual

CS186 EN 8/2/06 3:16 PM Page 3

Getting Started

Using the FM and MW Antennas

Before you use your audio system, you’ll want to

make sure both the FM and MW antennas are

positioned properly. Uncoil the FM antenna at

the back of the unit, making sure it is fully

extended (you may even want to tape it to the

wall behind the unit if possible. The higher the

better.) You’ll also need to connect the MW

antenna loop to the back of the unit if you listen

to MW stations. Rotate the MW loop antenna for

better reception.

Connecting the Speakers

Speaker terminal tabs marked L are for left while

R are for right. Each speaker has a black

(negative) and a red (positive) wire. When

connecting the speakers, match the red wires to

the red jacks and the black wires to the black

jacks.

Installation

To ensure sufficient ventilation, keep the spacings

shown below free from other surfaces:

10 cm

Front View

10 cm

5 cm

Side View

Release tab to lock wire in

the terminal.

NOTE: Make sure the insulation is completely removed from the

ends of the speaker wires at all connection points.

Speaker Wire Connection

Push Speaker terminal tab

down to insert wire.

CS186 EN 8/2/06 2:10 PM Page 10

General Controls

Main Unit - Front View

ON/ECO - Press briefly to turn on and off the

unit. Press and hold in standby mode to enter

ECO (power saving, without clock display) mode.

The red standby indicator lights above the

button.

DEMO/DIMMER - Activates and deactivates

demonstration.

SOURCE - Selects among CD player, tuner, USB

and AUX.

BAND/INFO - In CD mode - Selects display

options to show track elapse time, track remain

time or disc remain time.

In mp3 / WMA mode - Shows ID3 tag.

In USB mode - Shows memory usage.

In Tuner mode - selects radio band.

BACK - In navigation mode - navigates

backwards.

In rename mode - edits previous alphabet

SELECT - In mp3 / WMA / USB stop mode - Enters

navigation mode.

In navigation mode - navigates forward.

In rename mode - confirms the editing alphabet

RECORD - Starts and stops record to USB device.

DELETE - When reviewing program, removes

track / file from Program List.

In rename mode - deletes current alphabet

In USB mode - Removes file from the connected

USB device.

(PLAY/PAUSE) - Starts and pauses playback

for CD and USB.

TUNE/PRESET - Stops CD and USB

In Tuner mode - selects tune or preset mode.

(SKIP FORWARD) - In CD mode - Goes to

the next CD track and setting options; searches

forward through CD;

In USB mode - Skips to the next file;

In Tuner mode - Tunes up radio frequency.

(SKIP BACKWARD) - In CD mode - Goes to

the previous CD track and setting options;

searches backward through CD;

In USB mode - Skips to the previous file;

In Tuner mode - Tunes down radio frequency.

Tips:

In STANDBY mode, press ON/ECO to turn

the system on in the previously used mode.

Press SOURCE to select the corresponding

mode. Look at the display icons to identify

the current mode.

CS186 EN 8/2/06 2:10 PM Page 11

USB Storage Device

This Audio System allows you to connect your

own USB storage device. It supports all Mass

Storage Class mp3 players and storage devices.

Connecting/Disconnecting USB

storage device to the Main Unit

Lift the cover marked “mp3 player ”. Insert

the USB port of the USB storage device you want

to connect into the USB connector of the main

unit. Unplug the device to disconnect.

Selecting USB Mode

Press SOURCE repeatedly to select USB mode.

USB Playback Features

Start and Pause Playback

Press PLAY / PAUSE to start and pause

playback.

Stop Playback

Press to stop playback operations.

The unit enters navigation mode for 10 seconds

before entering stop mode.

Stop Mode Navigation Mode

Skipping Files

• Press / to skip to the previous or

next file.

• Press and hold / to search through

a file while it is playing.

Memory Usage

Press BAND/INFO on the main unit or CD/INFO

on remote to view memory usage on the USB

storage device.

TRACKS

FOLDERS

Tips:

In stop mode, press (RIGHT / ENTER)

to enter navigation mode and show disc menu.

In navigation mode, press (LEFT / BACK)

to return to stop mode.

CS186 EN 8/2/06 2:10 PM Page 19

File Navigation

Main Unit

SELECT - Enters navigation mode from mp3 /

WMA / USB stop mode.

Enters selected folder in navigation mode.

Begins playback of the selected file in navigation

mode.

BACK - Goes back up one level in navigation

mode; returns to stop mode from navigation

mode when at root level.

RECORD - Starts and stops record to USB device.

DELETE - When reviewing program, removes

track / file from Program List.

In rename mode - deletes current alphabet

In USB mode - Removes file from the connected

USB device.

Volume Control - Rotate clockwise to navigate

downwards.

Rotate counter-clockwise to navigate upwards.

Remote Control

(LEFT / BACK)- Navigates backwards.

Returns to the previous navigation menu level.

Returns to stop mode from navigation mode.

(RIGHT / ENTER)- Navigates forward.

Enters navigation mode from mp3 / WMA / USB

stop mode.

Enters current folder and shows the first

file/folder from current folder.

(UP) - Navigates upwards.

Enters navigation mode from mp3 / WMA / USB

stop mode.

Selects previous file/folder on the navigation

menu.

(DOWN)- Navigates downwards.

Enters navigation mode from mp3 / WMA / USB

stop mode.

Selects next file/folder from the navigation menu.

ADD - In mp3 / WMA / USB navigation mode -

adds the selected file into Program List.

DEL - When reviewing program, removes the

selected file from Program List.

In USB mode - Deletes selected file.

Advanced Navigation Controls

DEL

ADD

SOURC

ECO

AND

D INF

DIMMER

BOOST

INTR

O/CT

LOC

EPE

T/RDS

LEEP

TIMER

ECO

B BOOST
