Thrane&Thrane Explorer 727 Manuale utente

InstallatIon manual

ExplorEr® 727

17865-TT Installation manual A5.indd 1 03/04/08 13:17:58

EXPLORER®727

Including 19" Rack Version

Installation manual

Document number: 98-126844-D

Release date: September 8, 2011

Disclaimer

Any responsibility or liability for loss or damage in connection with the use of this

product and the accompanying documentation is disclaimed by Thrane & Thrane. The

information in this manual is provided for information purposes only, is subject to

change without notice and may contain errors or inaccuracies.

Manuals issued by Thrane & Thrane are periodically revised and updated. Anyone

relying on this information should acquire the most current version e.g. from thrane.com

or from the distributor.

Thrane & Thrane is not responsible for the content or accuracy of any translations or

reproductions, in whole or in part, of this manual from any other source.

Trademark acknowledgements

•Thrane & Thrane is a registered trademark of Thrane & Thrane A/S in the European

Union and the United States.

•EXPLORER is a registered trademark of Thrane & Thrane A/S in the European Union

and the United States.

•Windows and Outlook are registered trademarks of Microsoft Corporation in the

United States and other countries.

•Inmarsat is a registered trademark of International Maritime Satellite Organisation

(IMSO) and is licensed by IMSO to Inmarsat Limited and Inmarsat Ventures plc.

• Inmarsat’s product names are trademarks or registered trademarks of Inmarsat.

• Other product and company names mentioned in this manual may be trademarks or

trade names of their respective owners.

Company web site

thrane.com

iii

Safety summary 1

The following general safety precautions must be observed during all

phases of operation, service and repair of this equipment. Failure to comply

with these precautions or with specific warnings elsewhere in this manual

violates safety standards of design, manufacture and intended use of the

equipment. Thrane & Thrane A/S assumes no liability for the customer's

failure to comply with these requirements.

Observe marked areas

Under extreme heat conditions do not touch

areas of the terminal or antenna that are

marked with this symbol, as it may result in

injury.

Microwave radiation hazards

During transmission the antenna in this system

radiates Microwave Power.This radiation may

be hazardous to humans close to the antenna.

When the system is powered, make sure that

nobody gets closer than the recommended

minimum safety distance.

The minimum safety distance is 1 m to the side and above the antenna when

the EXPLORER 727 is powered. The safety distance of 1 m does not apply

directly below the antenna, as the radiation forms a hemisphere above the

antenna.

Service

User access to the interior of the system units is prohibited. Only a

technician authorized by Thrane & Thrane A/S may perform service - failure

to comply with this rule will void the warranty.

Do not service or adjust alone

Do not attempt internal service or adjustments unless another person,

capable of rendering first aid resuscitation, is present.

Power supply

The voltage range is 10.5 - 32 V DC; 14 A - 5.5 A. Be aware of high start-up

peak current: 20 A@24 V, 5 ms.

Do not operate in an explosive atmosphere

Do not operate the equipment in the presence of flammable gases or fumes.

Operation of any electrical equipment in such an environment constitutes a

definite safety hazard.

Keep away from live circuits

Operating personnel must not remove equipment covers. Component

replacement and internal adjustment must be made by qualified

maintenance personnel. Do not replace components with the power cable

connected. Under certain conditions, dangerous voltages may exist even

with the power cable removed. To avoid injuries, always disconnect power

and discharge circuits before touching them.

Install and use the antenna with care

Thrane & Thrane assumes no liability for any damage caused by the antenna

falling off the vehicle or stressing the mounting base. It is the responsibility

of the customer to ensure a safe and correct installation of the antenna. The

instructions in the Installation manual are only guidelines.

Note the following safety guidelines for mounting the antenna with

magnetic mounts:

Under normal driving circumstances the magnetic force of the magnetic

mount kit for the antenna should be sufficient to hold the antenna. However,

the magnets may not be able to hold the antenna in place, if:

• the vehicle is involved in an accident,

• the magnets are not mounted properly,

Caution! Do not place your fingers underneath the antenna when

placing the antenna on the vehicle!

The magnetic force is very powerful and your fingers

may be hurt if they are caught between the antenna and

the mounting surface.

• the roof is not plain or made of a material that will not stick properly to

the magnets,

• the speed of the vehicle is too high and/or

• the road is very bumpy.

We recommend mounting the antenna on the roof rails or directly on the

roof instead of using the magnetic mount kit. Make sure that all mounting

bolts and nuts are secured properly, and that the material of the mounting

surface is strong enough to hold the antenna during the intended use.

About the manual 2

Intended readers

This is an installation manual for the EXPLORER 727 system,

intended for installers of the system and service personnel.

Personnel installing or servicing the system must be properly

trained and authorized by Thrane & Thrane. It is important that

you observe all safety requirements listed in the beginning of this

manual, and install the system according to the guidelines in this

manual.

Manual overview

Note that this manual does not cover general use of the system nor

does it cover how to use the IP handset that comes with the

system. For this information, refer to the user manual for this

system and the user manual for the IP handset, both listed in the

next section.

This manual has the following chapters:

•System units contains a short description of each main unit in

the system.

•Installing the system describes where to place the system units,

how to mount them, distance to other equipment etc.

•Connecting power explains how to connect the terminal to

power and gives recommendations for cables.

•Hardware interfaces describes each interface on the terminal

and shows pin-out for the connectors.

•Starting up the system explains how to insert the SIM card,

power up the system and enter the PIN. It also gives a short

overview of how to use the system.

•Troubleshooting describes the function of the Reset button and

the light indicators on the terminal. It also describes event

messages that may appear in the web interface.

vii

Related documents

The below list shows the documents related to this manual and to

the EXPLORER 727 system.

Title and description Document

number

EXPLORER 727 Including 19" Rack Version

User Manual

Explains how to set up and use the

EXPLORER 727 system.

98-126882

EXPLORER 727 Quick Guide

A short guide to the most important functions

of the EXPLORER 727 system.

98-126881

EXPLORER 727 Getting Started

Explains how to start up your EXPLORER 727

system and make the first call or data session.

TT98-126880

Thrane IP Handset, User Manual

Explains the features and functions of the

Thrane IP Handset. The IP handset works as a

standard IP handset, but also serves as a user

interface for the EXPLORER 727 system.

98-126059

viii

Typography

In this manual, typography is used as indicated below:

Bold is used for the following purposes:

• To emphasize words.

Example: “Do not touch the antenna”.

• To indicate what the user should select in the user interface.

Example: “Select SETTINGS > LAN”.

Italic is used to emphasize the paragraph title in cross-references.

Example: “For further information, see Connecting Cables on

page...”.

Table of contents

Chapter 1 System units

1.1 Introduction ............................................................... 1

1.2 EXPLORER 727 terminal ............................................. 1

1.3 Antenna .....................................................................3

1.4 Thrane IP Handset & Cradle .......................................4

Chapter 2 Installing the system

2.1 Unpacking .................................................................7

2.2 Placing the antenna ...................................................8

2.3 Installing the antenna ................................................9

2.4 Placing the terminal .................................................17

2.5 Installing the EXPLORER 727 terminal .......................19

2.6 Installing the 19” Rack Terminal ...............................23

Chapter 3 Connecting power

3.1 Power source ........................................................... 27

3.2 Power cable selection ..............................................28

3.3 Connecting power ....................................................34

Chapter 4 Hardware interfaces

4.1 The connector panel ................................................39

4.2 Antenna interface on terminal .................................40

4.3 DC power input .........................................................41

4.4 19” rack version only: Terminal block .......................43

4.5 Analogue Phone/Fax interface .................................44
