Thule 1212 Manuale utente
ISO 11154-E
Instructions
xx kg
xx Ibs 7 kg
15,4 Ibs
km/h
Mph
0
80 km/h
50 Mph
40 km/h
25 Mph
130 km/h
80 Mph
ThuleRapidSystemKitXXXX
Instructions
ThuleRapidSystem754
Instructions
Thule Rapid System Kit xxxx
Instructions
Security
Thule Rapid System Kit xxxx
Instructions
ThuleRapidSystemKitXXXX
Instructions
ThuleRapidSystem754
Instructions
Thule Rapid System 754
Instructions
.............
i
Thule Rapid System 754
Instructions
AUDI A4, 4-dr Sedan, 01-04, 05-07 / *02-08
AUDI RS4, 4-dr Sedan, *04-08
AUDI S4, 4-dr Sedan, *04-08
SEAT Exeo, 4-dr Sedan, 09–
*North America
Max.
165 Ibs
Max.
75 kg
Thule Rapid System Kit 1212
141212
C.20120627
519-1212-02
2
1
x1
x1
389 x4
07 x4
XXX
ThuleRapidSystemKitXXXX
Instructions
ThuleRapidSystem754
Instructions
Thule Rapid System Kit xxxx
Instructions
519-1212-02
X (scale) X (mm) X (inch)
AUDI A4, 4-dr Sedan, 01-04, 05-07 / *02-08 34,5 996 39 1/
4
AUDI RS4, 4-dr Sedan, *04-08 34,5 996 39 1/
4
AUDI S4, 4-dr Sedan, *04-08 34,5 996 39 1/
4
SEAT Exeo, 4-dr Sedan, 09– 34,5 996 39 1/
4
Y (scale) Y (mm) Y (inch)
AUDI A4, 4-dr Sedan, 01-04, 05-07 / *02-08 31 961 37 7
/8
AUDI RS4, 4-dr Sedan, *04-08 31 961 37 7
/8
AUDI S4, 4-dr Sedan, *04-08 31 961 37 7
/8
SEAT Exeo, 4-dr Sedan, 09– 31 961 37 7
/8
X
Y
2
X/Y
Thule Rapid System 754
Instructions
3
2
519-1212-02
389 07 38907
389 07 38907
XXX
XXX
XXX
XXX
AUDI A4, 4-dr Sedan, 01-04, 05-07 / *02-08
AUDI RS4, 4-dr Sedan, *04-08
AUDI S4, 4-dr Sedan, *04-08
SEAT Exeo, 4-dr Sedan, 09–
3
xxx
Thule Rapid System 754
Instructions
519-1212-02
ww
NA
Thule Sweden AB, Box 69, 330 33 Hillerstorp, SWEDEN
Thule Inc., 42 Silvermine Road, Seymour, Connecticut 06483, USA www.thule.com
Phone: 800-238-2388
W (mm) Z (mm) W (inch) Z (inch)
AUDI A4, 4-dr Sedan, 01-04, 05-07 / *02-08 i* i* i* i*
AUDI RS4, 4-dr Sedan, *04-08 i* i* i* i*
AUDI S4, 4-dr Sedan, *04-08 i* i* i* i*
SEAT Exeo, 4-dr Sedan, 09– i* i* i* i*
3
W Z
5
i
i* = information
W/Z
Thule Rapid System 754
Instructions
