Thule 2018 Manuale utente

Hook the brackets

into place in the

tensioning

attachments.

Thule System Kit 2018

6,5 Kg

940 mm / 37 inch

mm/inch

Re-fit the moulding and

the plastic cover.

Press the tensioning

attachment onto the moulding.

The rearmost attachment must

be pressed on and then slid

back to the correct position.

150 mm

600 mm

x4

Unscrew the 6 TORX

screws which keep the

plastic moulding in place.

Bend the moulding out a

bit as shown in the

picture.

Open the doors. Remove

the plastic cover behind

the door. Unscrew the

TORX screw (1 off) using

TORX tool 15 and

remove the cover.

x4

29

90

x4

746•3DFK/501-2018-02

SATURN Coupé, 97–

MAX

75 K

g

LOAD

Before the load carrier can be fitted, tensioning attachments must first

be mounted. The tensioning attachments should always be left on

the vehicle (The load carrier should be removed when not in use).

Read through these instructions carefully before starting the work of

assembly. If you feel in any doubt about how to proceed, ask your

local

Thule dealer for advice. You will need a TORX tool, number 15, for

assembly.
