Tiger Electronics Game.com Pocket Pro Manuale utente
1
MODEL 71-801
2
TABLE OF CONTENTS
•Introduction
•System Diagram
•Explanation of Features
•Using game.com – Cartridges
– Phone Book
– Calendar
– Calculator
– High-Score Save
– Solitaire
•Epilepsy Warning
•Other Medical Precautions
•Caring for Your System and Carts
•Inserting Batteries
•Warranty
•FCC Information
123456789012345678901234567890121234
1
2345678901234567890123456789012123
4
1
2345678901234567890123456789012123
4
123456789012345678901234567890121234
CONTENTS
3
INTRODUCTION
game.com ACTIVE! With the touch of a button, you’ll enter - and
hear! - the next generation of portable gaming. With its
innovative touch screen/stylus interface, built-in speech
capability, built-in organizer functions and optional Internet/email
and Web Link capabilities, game.com propels cartridge-based,
portable gaming years ahead. And, with its extensive library of
challenging games, it provides endless hours of fun.
The system is cartridge-based, which means a large variety of
games designed specifically for it can be purchased and played.
Since games are specially designed to take advantage of
game.com’s unique features, only cartridges labeled
“game.com” will work with the system.
In addition to playing games, game.com has several built-in
functions: a phone book, calendar and calculator. Each has
been developed for ease-of-use to keep life organized on the
go. Also built-in are an automatic high-score save feature, which
retains the highest score earned in up to 10 different games, and
a special touch screen version of the classic card game Solitaire.
123456789012345678901234567890121234567890123456789
1
2345678901234567890123456789012123456789012345678
9
1
2345678901234567890123456789012123456789012345678
9
123456789012345678901234567890121234567890123456789
INTRODUCTION
4
12345678901234567890123456789012123456789012
1
234567890123456789012345678901212345678901
2
1
234567890123456789012345678901212345678901
2
12345678901234567890123456789012123456789012
On/Off KEY
DIRECTIONAL PAD A, B, C, D KEYS
MENU KEY
LED BACKLIGHT
INDICATOR
PAUSE KEY
SCREEN
SPEAKER
SYSTEM DIAGRAM
FRONT
BACKLIGHT
SYSTEM DIAGRAM
5
RESET BUTTON
STYLUS
CARTRIDGE PORT
VOLUME CONTROL
CONTRAST CONTROL
COM PORT
DC ADAPTER JACK
HEADPHONE
JACK MAIN BATTERY
COMPARTMENT
BACKUP BATTERY
COMPARTMENT
SYSTEM DIAGRAM
BACK
12345678901234567890123456789012123456789
1
2345678901234567890123456789012123456789
1
2345678901234567890123456789012123456789
12345678901234567890123456789012123456789
GETTING STARTED
In only 3 simple steps your game.com is
ready to use.
1. Remove the Battery Insulator (see inset).
2. Install 2 AA/LR6 batteries (please refer to
INSERT BATTERIES).
3. Press the ON key to start playing.
6
EXPLANATION OF FEATURES
IMPORTANT NOTE: Your system is equipped with an AUTO TIME-
OUT feature that will turn the main unit off if there has been no
user activity for three minutes. A warning tone will sound just
before the unit shuts off. Pressing any key before the unit turns off
resets the timer.
You can make screen selections one of two ways: use the STYLUS
to touch your choice, or use the DIRECTIONAL PAD to position the
cursor on your selection. Then press the Akey to enter your
choice.
PAUSE KEY
Press this button to pause game play. PAUSE will only activate
while playing a game. Pressing PAUSE causes all activity in a
game to stop. Pressing the PAUSE button again resumes play.
Note that while playing Solitaire, the unit will automatically turn
off after being in PAUSE mode for 3 minutes.
1234567890123456789
1
23456789012345678
9
1
23456789012345678
9
1234567890123456789
FEATURES
7
FEATURES
VOLUME CONTROL
Adjusts the sound level.
HEADPHONE JACK
Accepts headphones with
the proper adapter.
CONTRAST CONTROL
Adjusts the contrast of
the LCD screen.
WARNING:
When playing with a game cartridge, PAUSE will not automatically
turn the unit off. If you leave the unit in PAUSE for an extended
period of time, you risk draining the batteries and losing any
information you may have saved.
8
FEATURES
AC ADAPTER JACK
Accepts AC 9V adapter
to conserve batteries.
RESET BUTTON
Press to restart the system.
CARTRIDGE PORT
Where a game cartridge is
inserted.
COM PORT
Accepts optional cables for a
variety of Internet–related and
head–to–head gameplay activities.
9
USING game.com
1. Press the ON button to activate the unit.
2. An opening sequence appears and “game.com ACTIVE!” is
heard. Then the MAIN MENU appears.
KEY FUNCTIONS
DIRECTIONAL PAD In the MAIN MENU, use this key to move
the black cursor to make a selection.
A key This key functions as the ENTER key for menu selections
and as the START key for game functions.
B, C, D keys In cartridge games these keys are assigned
specific functions. Please refer to the individual game manual for
correct operation.
MENU This key will allow you to return to the MAIN MENU. Once
selected, touch YES or NO with the STYLUS, or use the
DIRECTIONAL PAD to select the option you want. If you use the
DIRECTIONAL PAD, press the Akey to confirm your selection.
12345678901234567890123456789012123456789012
1
234567890123456789012345678901212345678901
2
1
234567890123456789012345678901212345678901
2
12345678901234567890123456789012123456789012
1234567890123456789012345678901212345678901234567
1
23456789012345678901234567890121234567890123456
7
1
23456789012345678901234567890121234567890123456
7
1234567890123456789012345678901212345678901234567
USING
game.com
10
The MAIN MENU screen displays the following options:
Cartridge
Phone Book
Calendar
Calculator
High Score
Solitaire
Select an option from the MAIN MENU one of two ways: Touch
your selection with the STYLUS, or use the DIRECTIONAL PAD to
move the cursor until your choice turns dark, indicating it’s
available. Then press the Akey to enter your selection.
CARTRIDGE
IMPORTANT NOTE: Turn the system off before inserting or removing
cartridges. Inserting or removing cartridges when the unit is
active will result in a system error, and the unit will have to be
reset.
To activate a cartridge once it’s been inserted, select
CARTRIDGE.
USING game.com
