Timotion TDH13P Manuale utente

Hand Control Programming- TDH13P

Version 4 August 2021

1 of 10

error codes

20210811

User Manual

Hand Control

Programming-

TDH13P

Hand Control Programming- TDH13P

Version 4 August 2021

2 of 10

Contents

Contents .....................................................................................................................................................................2

Disclaimer ..................................................................................................................................................................3

1. User Interface Guide.............................................................................................................................................4

2. Reset....................................................................................................................................................................5

3. Adjusting the Height.............................................................................................................................................6

4. Setting the Memorized Position ...........................................................................................................................6

5. Setting the upper and lower height limit ...............................................................................................................7

6. Presetting the Desk Starting Height .....................................................................................................................8

7. Switching Metric and Imperial Unit .......................................................................................................................8

8. Restore Factory Setting ........................................................................................................................................9

9. Error Codes ..........................................................................................................................................................9

10. Power Saving Function - Waking up the Control .................................................................................................10

Hand Control Programming- TDH13P

Version 4 August 2021

3 of 10

Disclaimer

This user manual is ONLY for generic TiMOTION products. Manufacturers may have altered product settings

causing them to differ from this user manual. Please contact the manufacturer for a revised manual if the

product settings are different than this manual.

Hand Control Programming- TDH13P

Version 4 August 2021

4 of 10

1.User Interface Guide

3-digit height display

Memory setting buttons

Up and down buttons

Hand Control Programming- TDH13P

Version 4 August 2021

5 of 10

2.Reset

1. Simultaneously press and for 3 seconds. Continue pressing the buttons until both columns are

in the lowest position. When finished with the reset, the control box will make a “beep” sound and the

buttons can be released.

2. When finished with the reset, the display will show the starting height.

3. Users must conduct a reset when operating the desk for the first time.

Hand Control Programming- TDH13P

Version 4 August 2021

6 of 10

3.Adjusting the Height

Press or button until the desk reaches the preferred height.

4.Setting the Memorized Position

TDH13P supports a maximum of 4 memory positions.

How to memorize a position:

1. Adjust the desk to the desired height.

2. Press preferred memory button (1, 2, 3, 4), with either + or - for 2 seconds, once the display shows P1 or

P2 or P3 or P4, the position is memorized.

3. Press (and hold) button 1, 2, 3 or 4 to move the desk to the memorized position. (Note 1)

Note 1: It depends on the control box setting whether or not the memory button needs to be held.

Hand Control Programming- TDH13P

Version 4 August 2021

7 of 10

5.Setting the upper and lower height limit

A. Setting the upper height limit:

(1) Adjust the desk to the preferred upper height limit.

(2) Press + and - buttons together for less than 3 seconds, holding + and release - button. (Note 2)

(3) Re-press - for more than 3 times at a slow pace.

(4) A beeping sound will notify you that the process has been completed.

B. Disable the upper height limit:

(1) Move the desk to the upper height limit being set.

(2) Repeat instructions #2~4 above to disable the upper limit setting.

C. Setting the lower height limit:

(1) Adjust the desk to the preferred lower height limit.

(2) Press + and - buttons together for less than 3 seconds, holding - and release + button. (Note 3)

(3) Re-press + for more than 3 times at a slow pace.

(4) A beeping sound will notify you that the process has been completed.

D. Disable the lower height limit:

(1) Move the desk to the lower height limit being set.

(2) Repeat instructions #2~4 above to disable the lower limit setting.

Note 2: Some control boxes may not support setting the upper and lower height limit functionality.

Note 3: More than 3 seconds will direct to “Reset” mode.

Hand Control Programming- TDH13P

Version 4 August 2021

8 of 10

6.Presetting the Desk Starting Height

(1) Press button until the desk reaches its lowest position and then release button. Re-press button

again for 5 seconds and the digital display will flash for 10 seconds.

(2) Adjust the starting height number with the + or - button.

(3) After 10 seconds, the display will stop flashing and this will confirm that you have successfully set the

starting height.

7.Switching Metric and Imperial Unit

(1) Press memory buttons 1, 2 and 4 for 5 seconds.

(2) The digital display will show “C-I”. If no further instruction is input within 5 seconds, the system reverts to

the normal operation mode.

How to choose a metric unit

Press button 2, the digital display will show “C” to stand for centimeter.

How to choose an imperial unit

Press button 3, the digital display will show “I” to stand for inch.

Hand Control Programming- TDH13P

Version 4 August 2021

9 of 10

8.Restore Factory Setting

(1) Refer to Chapter 2-Reset: after the “beep” sound, press + and - buttons together for 15 seconds, the

control box will twice make a “beep” sound.

(2) The settings below will restore to the original factory settings:

Memorized position

Desk starting height

Upper and lower height limit

T-touch or TCS1 sensitivity

9.Error Codes

The digital display shows the error codes below to suggest the issues that users may encounter during the

operation. (Note 4)

Error code

Descriptions

000

Resetting

E00

Not reset completely

E01

Overuse protection

E02

Unbalance protection

E03

Anti-collision

E04

T-touch Protection

E11

M1 Motor over-current protection

E12

M2 Motor over-current protection

E13

M3 Motor over-current protection

E21

No Hall sensor from M1

E22

No Hall sensor from M2

E23

No Hall sensor from M3

E31

No current from M1

E32

No current from M2

E33

No current from M3

Note 4: Some control boxes may not support this function.

Hand Control Programming- TDH13P

Version 4 August 2021

10 of 10

10. Power Saving Function - Waking up the

Control

The digital display automatically turns off if no buttons are pressed within 25 seconds. Press any button

to light up the display again.

The system goes into <0.1W standby mode (Note 5) if no buttons are pressed within 30 seconds. Long

pressing any button will wake up the system and show desk height on the digital display.

Note 5: It depends on the control box whether it will support 0.1W standby mode or not.
