Toa 800D Series Manuale utente

Page 1 of 9

800D Series Mixer Amplifier

LOG DATA REFERENCE SHEET

(INTERNAL USE ONLY)

Page 2 of 9

Simplified chart for log data

Revision ＃

Date

Contents

1.0

2021/3/31

Original

Page 3 of 9

1. Summary

The document is reference purpose for 800D of log data contents which consists of Code # and Opt #.

2. Simplified chart for log data

All of log data indicates contents as below. Log data indicates as follows and it can refer each content with Code #

and Opt #.

Example:

0456 03 3C 2021-03-18T11:16:18+09:00 00:00:01.500 Chime volume adjustment -60 dB

No. Code Opt Date Time Content

Please refer below chart for your reference.

Chart of Code and Opt

OPERATIONS

Code

Opt

Description (Code)

Description (opt)

Remark

Energized

Main power ON

Start unit working

Bit 0-6

CPU input port operation

For developer usage

00 ～60

(DEC),

FF(-∞)

Ducker depth adjustment

Attenuation (dB: negative

sign omitted)

02 40 = adjusting amount of

Ducker depth is -40 dB

00 ～60

(DEC),

FF(-∞)

Chime volume adjustment

Attenuation (dB: negative

sign omitted)

03 20 = adjusting amount of

Chime volume is -20 dB

00 ～60

(DEC),

FF(-∞)

Master volume adjustment

Attenuation (dB: negative

sign omitted)

04 10 = adjusting amount of

Master volume is -10 dB

00 ～60

(DEC),

FF(-∞)

Remote master volume

adjustment

Attenuation (dB: negative

sign omitted)

05 60 = adjusting amount of

Remote master volume is -60

Initialize network settings

00: fixed

Pressed reset button while press

power button and hold.

Insert AC cable while press

power button and hold.

00 ～FF

HTTP Command reception

Refer “2-1 Command opt”

chart

HTTP Command reception

(Factory inspection start)

00: fixed

Page 4 of 9

COMMAND DETAILS

Code

Opt

Description (Code)

Description (opt)

Remark

Command details

(Connection check)

00: False

01: True

Command details (Power

control)

00: OFF

01: ON

00 ～60

(DEC),

FF(-∞)

Command details

(Software master volume

control)

Attenuation (dB: negative

sign omitted)

bit 0

bit 1-7

Command details (Switch

the mode)

0: Standard Control mode

1: Manual Control mode

0: fixed

bit 0

bit 1

bit 2

bit 3

bit 4

bit 5

bit 6

bit 7

Command details (Muting

the audio input)

0: Unmute, 1: Mute

For Audio Input 1

For Audio Input 2

For Audio Input 3

For Audio Input 4

For Audio Input 5

For Audio Input 6

For Input Module 1

For Input Module 2

Opt number is necessary to

calculate from Hexadecimal to

Binary number.

39 05 = 39 00000101

Audio Input 1 and 3 are muting

and less of inputs are unmuting.

Command details (Release

mute)

0: False

1: True

bit 0-1

bit 2-3

bit 4-5

bit 6-7

Command details (Set the

parameters of the EQ)

EQ1Type（00：Not used、

01：LPF、10：HPF、11：

PEQ）

EQ2Type（00：Not used、

01：LPF、10：HPF、11：

PEQ）

EQ3Type（00：Not used、

01：LPF、10：HPF、11：

PEQ）

00: Fixed

Opt number is necessary to

calculate from Hexadecimal to

Binary number.

3E B4 = 3E 00011110

EQ1: HPF

EQ2: PEQ

EQ3: LPF

bit 0-3

bit 4

bit 5-7

Command details (Set the

priority broadcast 1)

Priority (Emergency: 0,

Priority 1 to 8, Not priority

(normal): 9, Invalid: F).

Chime Not used:0, Used:1.

0: Fixed

Opt number is necessary to

calculate from Hexadecimal to

Binary number.

02 : 00010010

Priority 2 broadcasting with

chime.

Page 5 of 9

bit 0

bit 1

bit 2

bit 3

bit 4

bit 5

bit 6

bit 7

Command details (Set the

priority broadcast 2)

0: Unmute, 1: Mute

For Audio Input 1

For Audio Input 2

For Audio Input 3

For Audio Input 4

For Audio Input 5

For Audio Input 6

For Input Module 1

For Input Module 2

Opt number is necessary to

calculate from Hexadecimal to

Binary number.

92 : 10010010

Audio Input 2, 5 and Module 2

are muted.

00: OFF

01: ON

Command details (Set the

Network Setting)

Obtain IP address

automatically (0: OFF, 1:

ON)

ACTION

Code

Opt

Description (Code)

Description (opt)

Remark

The power status has

been changed

00: Standby

01: ON

CPU output port has been

changed

Operation mode

00: Normal Mode

01: Factory Inspection

Mode

Mode of Power amplifier

module has been changed

00: SPAN Other mode

01: SPAM standby mode

bit 0-3

bit 4

bit 5-7

Priority broadcast has

been controlled

Priority (Emergency: 0,

Priority 1 to 8, Not priority

(normal): 9, Invalid: F).

Chime Not used:1, Used:2.

0: Fixed

Opt number is necessary to

calculate from Hexadecimal to

Binary number.

09 : 00001001

Priority 1 broadcasting without

chime.

bit 0

bit 1

bit 2

bit 3

bit 4

bit 5

bit 6

bit 7

The audio input has been

muted

0: Unmute, 1: Mute

For Audio Input 1

For Audio Input 2

For Audio Input 3

For Audio Input 4

For Audio Input 5

For Audio Input 6

For Input Module 1

For Input Module 2

Opt number is necessary to

calculate from Hexadecimal to

Binary number.

00 : 00000000

All of audio input is unmuted.

09: 00001001

Audio input 1 and 4 are muted.

Page 6 of 9

00 ～60

(DEC),

FF(-∞)

Total Volume value has

been adjusted

Attenuation (dB: negative

sign omitted)

67 30 = Total volume amount is

-30 dB

The output impedance has

been changed

00: Low-z mode

01: Hi-z mode

Auto Sync

00: WebSocket end

01: WebSocket start

PROTOCOL RESPONSE

Code

Opt

Description (Code)

Description (opt)

Remark

00 ～FF

Protocol response (200)

Refer “2-1 Command opt”

chart

Command request is accepted

00 ～FF

Protocol response (202)

Refer “2-1 Command opt”

chart

Command request is accepted

and in progress for processing

00 ～FF

Protocol response (400)

Refer “2-1 Command opt”

chart

Command message has an

error

00 ～FF

Protocol response (403)

Refer “2-1 Command opt”

chart

Identification is necessary

00 ～FF

Protocol response (404)

Refer “2-1 Command opt”

chart

No found next processing step.

00 ～FF

Protocol response (405)

Refer “2-1 Command opt”

chart

Not supporting method

00 ～FF

Protocol response (500)

Refer “2-1 Command opt”

chart

Internal Server error

ERROR

Code

Opt

Description (Code)

Description (opt)

Remark

bit 0

bit 1

bit 2

bit 3-7

Power amplifier module

error

Thermal Protection

0：Normal、1：protection

Over Current

0：Normal、1：Protection

Status Unmatched

0：Normal, 1:Unmatched

0: Fixed

Opt number is necessary to

calculate from Hexadecimal to

Binary number.

E0 02 : E0 00000010

Over current has been

protected.

00 ～FF

WDT error

Second(s)

If counter will be reset or not

record more than 5 seconds,

Firmware update failure

00: fixed

History save failure

00: fixed

Setting error has been

occurred

00：Management area

10：Unit setting

20：Network setting

30：Unit Status

Page 7 of 9

bit 0

bit 1

bit 2

bit 3

bit 4

bit 5

bit 6-7

Priority broadcast setting

error

Abnormal status

（0：Normal、1：Abnormal）

Detect Audio Input 1

（0：Normal、1：Abnormal）

Detect Audio Input 2

（0：Normal、1：Abnormal）

Detect Module 1

（0：Normal、1：Abnormal）

Detect Module 2

（0：Normal、1：Abnormal）

Emergency Broadcast

（0：Normal、1：Abnormal）

0: Fixed

Opt number is necessary to

calculate from Hexadecimal to

Binary number

E8 20 = E8 00100000

Emergency Broadcast setting

has error

NOTIFICATION

Code

Opt

Description (Code)

Description (opt)

Remark

00 ～FF

Additional time

information (High)

This information for clockwise

and use internally.

00 ～FF

Additional time

information (Low)

This information for clockwise

and use internally.

Ignore priority broadcast

activation

00: Fixed.

While higher priority

broadcasting is working, unit

receive lower priority activating

instruction from contact or

audio signal.

1 ～31

Date info

0 ～23

Time info

-48 ～

Time zone info

It is UTC base and EST: -5:00 :

opt amount indicates “-20” (-5×

4).

Page 8 of 9

2-1 Command opt

Opt number is necessary to convert from Hexadecimal to Binary number and 2 contents are including. First 3

digits is action and last 5 digits is contents.

Example; Log data indicates Code is 90 and opt is 44. Opt 44 converts to Binary number : 01000100

It divides first 3 digits “010”and less 5 digits “00100”. Refer below table to pick up log info,

Code 90 opt 44 is Protocol response (200) PUT Power.

Action

Binary #

API

Last 3 digits

000

GET

001

POST

010

PUT

011

DELETE

100

HEAD

101

OPTIONS

110

TRACE

111

CONNECT

Contents

Binary #

API

Last 5 digits

00000

00001

Logout

00010

Equipment-info

00011

Connection-check

00100

Power

00101

Status

00110

AGC

00111

Volume

01000

Manual

01001

Mute start

01010

Mute stop

01011

Zero start

01100

Zero stop

01101

Date time zone

01110

01111

FBS

10000

Setting

10001

Input priority

10010

Bus

10011

Input priority-edit

10100

Network

Page 9 of 9

10101

Firmware

10110

Log

10111

Reset

11000

Soft volume memory

11001

Default-priority

11010

Start auto sync

11011

Auto sync

11100

Close auto sync

11101

Flash

11110

Test

11111

SPI flash

01110

01111

FBS

10000

Setting

10001

Input priority

10010

Bus

10011

Input priority-edit

10100

Network

10101

Firmware

10110

Log

10111

Reset

11000

Soft volume memory

11001

Default-priority

11010

Start auto sync

11011

Auto sync

11100

Close auto sync

11101

Flash

11110

Test

11111

SPI flash
