Toastmaster 357S/357SCAN Manuale utente

USE AND CARE GUIDE

MODELS 357S/357SCAN

357S/357SCAN

4-Slice

Toaster-Oven-Broiler

with Removable Liner

Questions

Call toll free 1-800-947-3744

Monday–Friday, 8:00 a.m.-5:30 p.m. CST

www.toastmaster.com

•Dishwasher safe removable stainless steel liner

•Large capacity handles 4 slices of toast, 5 lb. chicken,

8" pie pan

•2-hour timer

•Cool wall exterior

•Auto shut-off when cooking time is reached

•Electronic toast control

•Includes wire rack, bake/broil pan and broil insert

•Adjustable thermostat

357S/357SCAN Cover TL 14/5/02 13:33 Page 1

READ AND SAVE

THESE INSTRUCTIONS

WARNING: A risk of fire and electrical shock exists in all electrical

appliances and may cause personal injury or death. Please follow all

safety instructions.

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should

always be followed to reduce the risk of fire, electrical shock and

injury to persons, including the following:

◆Read all instructions before using appliance.

◆Close supervision is necessary when any appliance is used near

children.

◆This appliance is not for use by children.

◆Do not touch hot surfaces. Use handles or knobs and oven mitts.

◆Do not operate any damaged appliance. Do not operate with a

damaged cord or plug, or after the appliance malfunctions or has

been dropped or damaged in any manner. Contact Consummer

Service for examination, repair, electrical or mechanical

adjustment.

◆Before using this appliance, move it four to six inches from the

wall or any object on the countertop. Do not store any item on top

of the appliance. Do not use on surfaces where heat may cause a

problem.

◆A fire may occur if this appliance touches or is covered by

flammable material, including curtains, draperies, walls, etc., when

in operation.

◆Do not store any materials, other than manufacturer’s

recommended accessories, in this oven when not in use.

◆Do not cover crumb tray or any part of the oven with metal foil.

This will cause overheating of the oven.

◆Extreme caution should be exercised when using containers

constructed of materials other than metal.

◆Do not place any flammable material such as paper, cardboard,

plastic, etc. in the oven.

◆When broiling, the bake/broil tray and broil insert rack must be used.

357S/357SCAN TOB TL 14/5/02 13:32 Page 1

2. 4-Slice Toaster-Oven-Broiler with Removable Liner Use and Care Guide

◆Do not use outdoors or while standing in a damp area.

◆Do not clean with metal scouring pads. Pieces of the pad may

break off and touch electrical parts.

◆Unplug from outlet when not in use and before cleaning. Allow to

cool before attaching or removing parts and before cleaning the

appliance.

◆CAUTION: Never leave toaster-oven-broiler unattended when

broiling or toasting.

◆Do not let cord hang over edge of table or counter, or touch hot

surfaces.

◆The toaster-oven-broiler is off when the temperature knob and the

timer are in the off position.

◆Extreme caution must be used when moving an appliance

containing hot oil or other hot liquids.

◆Use extreme caution when removing broiling tray or disposing of

hot grease.

◆Do not place on or near a hot gas or electric burner or in a heated

oven.

◆Use attachments only if recommended by Toastmaster Inc.

◆Only use appliance as indicated in these instructions.

SAVE THESE INSTRUCTIONS

CAUTION: A short power supply cord is provided to reduce the risk

of personal injury resulting from becoming entangled in or tripping

over a longer cord. Extension cords are available from local hardware

stores and may be used if care is exercised in their use. If an

extension cord is required, special care and caution is necessary. Also

the cord must be: (1) marked with an electrical rating of 125 V and at

least 13A, 1625 W, and (2) the cord must be arranged so that it will

not drape over the countertop or tabletop where it can be pulled on

by children or tripped over accidentally.

POLARIZED PLUG: This appliance has a polarized plug, (one blade

is wider than the other). As a safety feature to reduce the risk of

electrical shock, this plug is intended to fit in a polarized outlet only

one way. If the plug does not fit fully in the outlet, reverse the plug. If

it still does not fit, contact a qualified electrician. Do not attempt to

defeat this safety feature.

357S/357SCAN TOB TL 14/5/02 13:32 Page 2

ELECTRIC POWER: If the electric circuit is overloaded with other

appliances, your appliance may not operate properly. It should be

operated on a separate electrical circuit from other appliances.

This product is for household use only.

Remove all packaging materials including the piece of paper that has

been placed between the top of the oven door and oven for protection

during shipping. Also remove the piece of cardboard that has also been

placed between the bottom of the oven door and the oven.

Your product may vary slightly from illustration.

Power Light

Mode

Knob

TEMPERATURE

Knob

TIMER

Figure 1 Wire Rack

Upper Shelf

Positions 1 and 2

Lower Shelf

Positions 3 and 4

Broil Insert Rack

(P/N 21497)

Bake/Broil Pan

(P/N 21498)

Figure 2

357S/357SCAN TOB TL 14/5/02 13:32 Page 3

4. 4-Slice Toaster-Oven-Broiler with Removable Liner Use and Care Guide

Figure 3

Wire Rack

(Shelf Positions 1 and 3)

(P/N 21499)

Wire Rack Inverted

(Shelf Positions 2 and 4)

Removable Liner

(P/N 21500)

Wire

Handle

Figure 4

Figure 5

Dark

Toast

Broil

Oven

OFF OFF

Stay on

120

TIMER

Light

357S/357SCAN TOB TL 14/5/02 13:32 Page 4

Getting To Know

Your Toaster-Oven-Broiler

Your new Toastmaster toaster-oven-broiler has the versatility to bake,

broil, defrost, toast, top brown and keep foods warm. The adjustable

thermostat allows you to prepare recipes according to package or

recipe directions. The Power Light will be on any time the unit is

operating. Both upper and lower heating elements will be on when

toasting, baking, defrosting, top browning and keeping foods warm. Only

the upper elements will be on when broiling.

CAUTION: APPLIANCE SURFACES ARE HOT DURING AND

AFTER USE.

CAUTION: ALWAYS WEAR PROTECTIVE, INSULATED OVEN

MITTS ON HANDS WHEN TOUCHING HOT OVEN OR HOT

DISHES AND FOOD OR WHEN INSERTING OR REMOVING

RACK, PAN OR BAKING DISH.

Ovenware manufacturers do not recommend using see-through glass

baking containers or lids in this oven. Glass-ceramic baking containers

may be used. Do not use oven roasting bags in this oven, as they may

come in contact with the heating elements.

Bake/Broil Pan, Toast Rack

And Broil Insert

For best results use pan to bake, defrost, top brown, keep warm and

to minimize clean-up due to spills.

For toasting, place bread directly on rack.

When broiling, both the bake/broil pan and the broil insert rack

must be used.

Timer

The TIMER control dial also acts as the oven’s ON and OFF switch.

Turn the timer clockwise to select the appropriate cooking time up to

2 hours. When timer is complete, a signal will sound and the unit will

turn off automatically. If cooking for less than 10 minutes, using the

timer is not recommended.

357S/357SCAN TOB TL 14/5/02 13:32 Page 5

6. 4-Slice Toaster-Oven-Broiler with Removable Liner Use and Care Guide

If you do not wish to use the timer feature, turn the dial to STAY ON

to turn the oven on and watch food for doneness. Turn dial to OFF

position when cooking is complete.

Wire Rack

The wire rack must be used for all cooking functions. It may be inserted

in either the upper or lower rack position as shown in Figure 1.

The wire rack may also be inverted for two additional positions

(see Figure 3). Each section of instructions suggest a rack specific

position. However, the rack may be adjusted to accommodate the

different thickness of foods.

Instructions For Toast

1. Remove bake/broil pan and rack.

2. Plug into 120 V ~ 60 Hz outlet.

Center food on rack. Place in shelf position 2 or 3 of oven and close

the door.

4. Turn TOAST control to the desired shade.

5. Press the TOAST button. The power light will come on.

Condensation may build up on door glass, but will evaporate

during toasting.

6. The unit shuts off automatically when the cycle is complete. The

power light will go off. Note: Watch toast until desired color is

achieved and shut off unit manually by opening the oven door.

This will shut the unit off without damaging the oven. To restart,

push TOAST button again.

Hints For Toast

◆Follow toaster food directions.

◆Frozen and heavy bread require a darker setting

(e.g. bagels and English muffins.)

◆One slice requires a lighter setting than several slices.

357S/357SCAN TOB TL 14/5/02 13:32 Page 6

Instructions For Top Brown

1. Remove bake/broil pan and rack.

2. Plug into 120 V ~ 60 Hz outlet.

3. Adjust TOAST control to desired shade.

4. Center a baking container or food on rack, or use bake pan. Place

shelf position 2 or 3

of oven and close door.

5. Press TOAST button. The power light will come on.

6. The unit shuts off automatically when the cycle is complete. The

power light will go off. Watch food to avoid over-browning. To stop

cycle manually, open the oven door.

7. Unplug and allow to cool before cleaning.

Hints For Top Brown

◆For a darker color set the toast control to a darker shade and restart

the cycle by pressing the TOAST button; watch until desired color is

achieved and shut unit off manually by opening the oven door.

◆Top Brown may be used to top brown bagels, English muffins or

melt cheese on sandwiches or casseroles.

Instructions For Keep Warm

1. Remove bake/broil pan and rack.

2. Plug into 120 V ~ 60 Hz outlet.

3. Turn OVEN control to 200° and TIMER to desired time or to Stay

On. The power light will come on.

4. Center a baking container or food on the rack, or use bake pan;

place in

shelf position 2 or 3

and close door.

5. When finished open the door and remove food. Turn the OVEN and

TIMER controls to the OFF position. The power light will go off.

6. Unplug and allow to cool completely before cleaning.

357S/357SCAN TOB TL 14/5/02 13:32 Page 7

8. 4-Slice Toaster-Oven-Broiler with Removable Liner Use and Care Guide

Hints For Keep Warm

◆Use for short periods of time after food is cooked.

◆To heat frozen or cold foods, see instructions for defrost.

Instructions For Bake

1. Remove bake/broil pan and rack.

2. Plug into 120 V ~ 60 Hz outlet.

3. Turn OVEN control to desired setting. Turn TIMER to desired

time or to Stay On. If utilizing timed baking, allow approximately

10 minutes for preheat. The power light will come on.

4. Center a baking container or food directly on rack or use bake

pan. Place in

shelf position 2 or 3

of oven and close door.

5. Bake according to package or recipe directions.

6. When finished turn OVEN and TIMER controls to the OFF

position. The power light will go off.

7. Unplug and allow to cool before cleaning.

Hints For Bake

◆To prevent heat loss, avoid opening door excessively.

◆Foil may be used to cover glass-ceramic baking container if ends

are tucked closely against edge of pan.

◆For best results, foods that contain a leavening agent should be

baked on shelf position #4.

Instructions For Defrost

1. Remove bake/broil pan and rack.

2. Plug into 120 V ~ 60 Hz outlet.

3. Turn OVEN control to 200° and TIMER to desired time or to Stay

On. The power light will come on.

357S/357SCAN TOB TL 14/5/02 13:32 Page 8

Instructions For Defrost (cont.)

4. Place rack in

shelf position 2 or 3

of oven.

5. Center a baking container or food on rack or use bake pan. Note:

Defrost will take approximately 1/3 of the time recommended on

the package for defrosting at room temperature.

6. When finished turn the OVEN and TIMER controls to the OFF

position. The power light will go off.

7. Unplug and allow to cool completely before cleaning.

Hints For Defrost

◆Do not use this method for meat, poultry or fish.

◆Do not cover food.

◆Brush frozen dough with vegetable oil to prevent drying out and

remove food to preheat oven before baking.

Instructions For Broil

1. Remove bake/broil pan and rack.

2. Place broil insert in bake pan and position food on broil insert.

3. Place rack in shelf position 1 or 2.

4. Plug into 120 V ~ 60 Hz outlet.

5. Turn OVEN control to broil and TIMER to desired time or to Stay On.

6. Broil according to package or recipe instructions.

7. When finished turn OVEN and TIMER controls to the OFF

position. The power light will go off.

8. Unplug and allow to cool completely before cleaning.

357S/357SCAN TOB TL 14/5/02 13:32 Page 9

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Toastmaster Forno

Toastmaster

Toastmaster 353 Manuale utente

Toastmaster

Toastmaster TOV625 Manuale utente

Toastmaster

Toastmaster TOV2W T Manuale utente

Toastmaster

Toastmaster 310/310CAN Manuale utente

Toastmaster

Toastmaster 354 Manuale utente

Toastmaster

Toastmaster TLWTOB6 Manuale utente

Toastmaster

Toastmaster SC-7 Manuale utente

Toastmaster

Toastmaster TCO2114 Manuale utente

Toastmaster

Toastmaster TOV211DEH Manuale utente

Toastmaster

Toastmaster RH36 Manuale operativo

Toastmaster

Toastmaster XO-1MTD Manuale utente

Toastmaster

Toastmaster TM-160TR Manuale utente

Toastmaster

Toastmaster TOV2RMX Manuale utente

Toastmaster

Toastmaster ES-13 Manuale utente

Toastmaster

Toastmaster TOV320 Manuale utente

Toastmaster

Toastmaster TTOB4 Manuale utente

Toastmaster

Toastmaster TOV350W Manuale utente

Toastmaster

Toastmaster SC-14 Manuale utente

Toastmaster

Toastmaster TOV400CAN Manuale utente

Toastmaster

Toastmaster 328BC Manuale utente

Toastmaster

Toastmaster TOV425RLCAN Manuale utente

Toastmaster

Toastmaster UltraVection TUV48S Manuale utente

Toastmaster

Toastmaster ES-6 Manuale utente

Toastmaster

Toastmaster 18BCAN Manuale utente

Manuali Forno popolari di altre marche

Bosch

Bosch HVA531NS0 Manuale utente

Electrolux

Electrolux EOF6P46X Manuale utente

NEFF

NEFF B44S32 5GB Series Manuale utente

Combi

Combi BLODGETT BC142GDS Manuale utente

AEG

AEG COMPETENCE 311704300 Manuale utente

Falcon

Falcon DOMINATOR PLUS G3106 Series Guida utente

Rational

Rational SCC WE 61G Manuale utente

Smeg

Smeg DOSPA38X Manuale di installazione e funzionamento

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manuale utente

Miele

Miele HR 1954-2 Manuale utente

KHIND

KHIND OT50 Manuale utente

Henny Penny

Henny Penny Smoker Box Manuale utente

Lang

Lang ECOD-AP Manuale utente

AEG

AEG BEK455310M Manuale utente

Frigidaire

Frigidaire FNGE90JGR Manuale utente

Hotpoint

Hotpoint FE9 S831 JSH IX Manuale utente

GE Advantium SCB2000 Manuale utente

AEG

AEG DE401301DM Manuale utente
