List of Figures and Tables
Figure 2-1: RSX actuator with RP (Reverse Parallel)
motor mount............................... 9
Figure 2-2: RSX actuator major components ....... 9
Figure 3-1 RSX ordering codes and descriptions ... 10
Figure 3-2 RSX front flange option.............. 11
Figure 3-3 RSX mounting plates option .......... 11
Figure 3-4 RSX rear clevis mount option on reverse
parallel motor mount actuator ................. 11
Figure 3-5 RSX trunnion mount option........... 12
Figure 3-6 RSX rod clevis option ............... 12
Figure 3-7 RSX external thread option ........... 12
Figure 3-8 RSX extended tie rods option ......... 13
Figure 3-9 RSX position sensors ............... 13
Figure 4-1 Lift RSX properly using hoist and eyebolts 16
Figure 4-2 Lift RSX properly without eyebolts ...... 16
Figure 4-3 RSX RP motor and pulley ............ 17
Figure 4-4 RSX belt pulley diagram ............ 18
Figure 4-5 RSX motor coupler for LMI (inline) motor
mounting ................................ 20
Figure 4-6 RSX front flange option.............. 21
Figure 4-7 RSX trunnion mount option........... 22
Figure 4-8 RSX mounting plates option .......... 22
Figure 4-9 RSX rear clevis mount option on reverse
parallel motor mount actuator ................. 23
Figure 4-10 RSX extended tie rod mount option .... 24
Figure 4-11 RSX rod clevis option .............. 25
Figure 6-1 RSX seal cartridge exploded view ...... 27
Figure 6-2 RSX lubrication access cover
exploded view............................. 28
Table 4-1 RSX actuator weights (add stroke per unit
weight to base actuator weight)................ 15
Table 4-2 RSX motor pulley set screw torque
requirements ............................. 17
Table 4-3 RSX belt tension specifications......... 18
Table 4-4 RSX motor fasteners torque requirements. 19
Table 4-5 RSX reverse parallel cover fasteners torque
requirements ............................. 19
Table 4-6 RSX motor coupler set screw torque
requirements ............................. 20
Table 4-7 RSX motor fasteners torque requirements. 20
Table 4-8 RSX front flange fasteners torque
requirements ............................. 21
Table 4-9 RSX trunnion diameter and tolerance .... 22
Table 4-10 RSX mounting plates torque
requirements ............................. 23
Table 4-11 RSX rear clevis mount diameter and
tolerance ................................ 23
Table 4-12 RSX extended tie rod mounting torque
requirements ............................. 24
Table 4-13 RSX pilot holes diameter and tolerance.. 24
Table 4-14 RSX rod end torque requirements...... 24
Table 4-15 RSX rod clevis bore diameter and
tolerance ................................ 25
Table 4-16 RSX rod clevis width and tolerance..... 25
Table 4-17 RSX rod clevis torque requirements .... 25
Table 5-1 RSX breather/purge port thread size..... 26
Table 6-1 RSX seal cartridge torque requirements .. 27
