TomTom Ease Manuale utente
TomTom EASE
Getting started1.
2
Getting started
Mounting your navigation device
1. Push the EasyPort™ Mount on your TomTom EASE against the windshield
in your car.
2. Adjust the angle of your device.
3. Lock the EasyPort Mount by twisting the base.
4. Insert the Car Charger into your device.
1
2
3
4
3
5. Insert the Car Charger into the cigarette lighter in your car.
6. Switch your device on by pressing the On/Off button on the back of your
device.
7. You now have to answer some questions to set up your device. Tap the
screen to answer the questions.
8. To remove the Mount from your windshield, first unlock the EasyPort
Mount, then gently pull one of the tabs. The Mount comes off of the wind-
shield.
GPS reception
When you first start your TomTom EASE navigation device, the device may
need a few minutes to determine your GPS position and show your current
position on the map. In the future, your position will be found much faster,
usually within a few seconds.
To ensure good GPS reception, you should use your device outdoors. Large
objects such as tall buildings can sometimes interfere with reception.
Changeable covers
You can personalize your TomTom EASE from a selection of protective cov-
ers.
5
6
7
8
4
Toremovethecoverfromthedevice,firstremovethemount.Thenholdeither
sideofthecover and pushthroughthecenterofthe cover todetachthedevice
from the cover as shown in the diagram. To attach the new cover, push itgen-
tly into place as shown.
Troubleshooting
In rare cases, your TomTom EASE navigation device may not start correctly
or may stop responding to your taps.
First, check that the battery is properly charged. To charge the battery, con-
nect your device to the car charger.
If this does not solve the problem, you can reset the device. To do this, do the
following.
1. Remove the Mount from the device by pressing the release button on the
Mount.
2. Pull the back cover off the device by holding either side of the cover and
pushing the device through the center of the cover.
3. Use a straightened paper clip, or something similar, to push the reset but-
ton. The reset button is on the bottom of your device.
1
2
5
3
Driving View2.
6
Driving View The Driving View shows your current location on the map together with
detailed information such as current speed and route instructions.
Tap the center of the screen at any time to open the Main Menu.
AYour current position.
BThe name of the next street or street sign information.
CYour speed and the speed limit, if known.
Tap this panel on the status bar to adjust the volume and to repeat the next
instruction.
DNext route instruction.
Tap this panel on the status bar to switch between 2D and 3D views of the
Driving View.
EThe name of the street you are on.
FInformation about your trip: trip time, remaining distance and arrival time.
Tap this panel on the status bar to see a route summary.
Advanced Lane Guidance3.
7
Advanced Lane Guidance
Advanced Lane Guidance
Note: Lane guidance is not available for all junctions or in all countries.
Your TomTom EASE helps you prepare for highway exits and junctions by
showing the correct driving lane for your planned route.
As you approach an exit or junction,the lane you need is shown on the screen.
For some exits and junctions, the lane you need is shown in the status bar.
Main Menu4.
8
Main Menu The Main Menu is the starting point for planning a route, looking at a map or
changing your device settings.
To open the Main Menu from the Driving View, tap the center of the screen.
To return to the Driving View from the Main Menu, tap done.
Main Menu buttons
The following buttons are shown on the Main Menu.
Sound
Plan route
Tap this button to plan a new route.
This button is shown when you have not planned a route.
Change route
Tap this button to change the existing route or to plan a new route.
This button is shown when you have planned a route.
Browse map
Tap this button to look at the map.
sound
Tap this button to turn the sound off.
9
Night /Day
Options
Help
sound
Tap this button to turn the sound on.
night
Tap this button to set the night color scheme, which reduces the brightness
of the screen and shows the map using dark colors.
This is useful when driving at night or in dark environments such as long
tunnels.
day
Tap this button to set the day color scheme, which increases the brightness
of the screen and shows the map using bright colors.
options
Tap this button to adjust the settings for your device.
For more information, see the chapter Options.
help
Tap this button to see contact details for local emergency services and
other special services, such as veterinary clinics. You can then plan a route
to your chosen service center.
For more information, see the chapter Help.
Browse map5.
10
Browse map To look at the map in the same way as you might look at a traditional paper
map, tap Browse map in the Main Menu.
You can move the map by touching the screen and sliding your finger across
the screen.
AThe scale bar
BMarker
Markers point to your current location, your home location and your desti-
nation. The marker shows the distance to the location.
Tap a marker to center the map on the location pointed to by the marker.
CGPS button
Tap this button to center the map on your current position.
DThe POI button
Tap this button to select which POIs are shown.
EThe cursor
FThe Find button
Tap this button to find specific addresses.
GThe Cursor button
Tapthis button to plan aroute tothe cursorposition,create a Favorite at the
cursor position or find a Point of Interest near to the cursor position.
HThe zoom bar
Zoom in and out by moving the slider.
