Tomy Verbot Manuale utente

INSTR

:TION M

TABLE OF CONTENTS

IDENTIFICATION

PARTS.

. . . .. . . . . . . . . .. . . . . . . ..

BATTERY INSERTION

......................

:........

BATTERY REPLACEMENT

...........................

OPERATION

........................................

ARM ADJUSTMENT

.................................

HINTS, TIPS &REMINDERS

..........................

~HECKLIST

FOR CORRECTING DISORDERS

.........

.~RE

&MAINTENANCE

.............................

HOW

VERBOT RECOGNIZES YOUR VOiCE

........

...

GAMES

.............................................

TOM~

No. 5401 (2) Frequency:

49.860MHz

1111:1"1

IlIIrl~llun

Memory Light

(Indicates when

commands are

registered)

~emory

Buttons

..I11~~lIll!:ldj

~I~

cor registering

.\,J r

UI:

III

•

commands)

ON/OFF Switch

-+m-Antenna

(Receiver)

ON/OFF Switch

ON/OFF Indicator Light

.,~

Antenna Cord.

(Transmits)

BATTERY

INSERTION

You

will need: 1 9-volt Alkaline Battery

2 "C" size Alkaline Batteries

"AP\'

size Alkaline Batteries

Before loading the batteries, make sure that all switches

are turned

OFF.

VOICE TRANSMITTER

Turn the Voice Transmitter around

to the back. Slide Battery Cover

Door open and take it off.

Insert one 9-volt Alkaline Battery as

shown. Slide Battery Cover Door back

into place and snap shut.

8tt)

VERBOT

Turn Verbot upside down. Slide Battery Cover Door in the

direction indicated and open.

BATTERY

INSERTION

INSERT BATTERIES:

Place the 4 "AI\' size Alkaline Batteries into their

indicated slots.

2. Fit the 2 "C" size Alkaline

Batteries into place.

Close Battery

Cover

Door

and SNAP shut. 5

BATTERY

REPLACEMENT

When to replace the Batteries:

BATTERY SYMPTOMS

VOICE One 9-volt Alkaline e The ON/OFF indicator light grows dim.

TRANSMITTER ® The Distance necessary to transmit commands

becomes shorter.

4 "AA" size Alkaline • The ON/OFF indicator light grows dim.

VERBOT • Verbol's memory light stays on and does not flash.

• Verbot continually functions improperly.

• Verbot moves of its own accord.

® Verbot does not respond to commands even after

repeated attempts.

I 2

"c"

size Alkaline ® Verbot's movements become slower.

The

n batteries control Verbot's movement. The "AJ!\' batteries control Verbot's voice recognition function.

The 9-volt battery controls transmission of voice commands.

-BEFORE PROGRAMMING VERBOT, READ ALL

OPERATING INSTRUCTIONS.

Verbot is programmed by pressing Memory Buttons

and entering commands. Under each Memory Button is

a small picture of Verbot's function. (See picture below,

FIG. 1)

You

will need to program a separate Command

Word (or words) for each Memory Button.

IlIbSTOPdIt

Verbot stops

the motion

Eyes flash withI Hands grab

talking sound & arms lift

Arms descend

& hands let go

D 0

01,-----,

¢:I~l,l.

,~c:>

()~\I

Verbot moves I Moves IVerbot rotates

forward backward to left Rotates

FIG.1

U~I:KAIIU~

Choose Command Words that are very short, 2

syllables at the most.

THE GOLDEN RULE: COMMANDS MUST BE

LEAST .2 SECONDS LONG,

BUT NOT LONGER THAN 1.2

SECONDS. IF

YOU

PROGRAM

A COMMAND LONGER THAN

1.2 SECONDS, VERBOT WILL

AUTOMATICALLY ERASE

IT.

Also, Command Words should sound very different

from each other. For example, don't use "Turn Left" as

one command, if you're going to use "Turn Right" as

another. They sound too much alike to Verbot, and he

may confuse them. ("Rotate Left" and "Turn Right"

would be good chOices.)

(Continued)

UP'l:nAllUn

,,,un

I villI

The following chart (FIG. 2) gives some suggested

Command Words:

IilSTOpil

II!..~

STOP

BOY

HELLO

THERE

STAY

SMILE

HOLD IT!

YA!

PICK

CARRY

LIFT IT!

PUT DOWN

PLACE

DOWN

BOY!

~1.1,

,~c>

I/I'~O

TURN LEFT I RIGHT

ROTATE

LEFT RIGHT TURN

SWING LEFT CIRCLE RIGHT

GO STRAIGHT I

BACKWARD

FORWARD REVERSE

JET

MOVIN', BACK-UP

FIG. 2

Turn Verbot's switch to the "ON" position (FIG. 3).

Carefully place Verbot

his back (FIG 4).

FIG.3

3. Turn the Voice Transmitter's switch to the "ON" position

(FIG. 5).

f.!C23J\:

MICROPHONE

FIG. 5

ill

OFF/ON III IIID

;9,-

Follow steps

Band

C to program Verbot:

Hold the first Memory Button (the "STOP" Button)

down (FIG. 6). The Memory Light will begin

flashing. While the Memory Ught flashes, speak

into the Voice Transmitter's microphone (FIG. 7).

Say the Command Word

(s)

that you want Verbot to

memorize (such

"STOP BOY!" or "STAY"). Keep

your voice loud, speak clearly, and hold the Voice

Transmitter 3-6 inches from your mouth.

IiiiiBnM

I 'til

"V''IIII#'

1'tII

l1li

,."

Once Verbot memorizes the word, the Memory

Light will stop flashing and stay on. If the Light

ccntinues to flash, press the Memory Button down

again and repeat the Command. Once the Light

stays on, the word is programmed. Release the

Memory Button to let the Light go off.

Follow steps A and B with each of the remaining

Memory Buttons.

YOU

WILL FIND BLANK PROGRAMMING

CHARTS

THE BACK COVER OF THE

MANUAL. FILL THEM

HELP

YOU

REMEMBER YOUR COMMAND WORDS.

(Continued)

",rliiiii.IrUIolIUIl

II"'II~

'V'''II~

1iIII#'

After you've programmed all 8 Memory Buttons, stand

Verbot up for a trial run. Speak into ths Microphone

exactly the same tone, accent and wording that you

used to program Verbot. The maximum range from

Voice Transmitter to Verbot is approximately

feet.

(Make sure there are no walls or obstacles between the

antennas.)

":'L

•••

0 •

. "

Verbot fails to respond to your Command after several

tries (or

he makes the wrong movements), here are

some things to try:

Press the Memory Button again and re-program the

word until he gets it.

Make sure you are making the Command in the

same tone, accent and wording as you did when

programming Verbot.

Make sure your Commands are different enough in

sound and tone for Verbot to tell them apart.

Remember or write down the Command Words that

you programmed into Verbol.

Decrease the distance between Verbot and the Voice

Transmitter.
