4.Lubricatethe spindleof thepolisherbeforeinstallationif possible. Makesure
that thereisno guardleveraround the collarof the polisher.
5. Whileplanetarypolisherbaseisonaflat surface, insert the spindleof the
polisherintothe input shafthorizontally.
Tip:Whentryingtothreadthespindleintotheinputshaftinstall oneoftheback holdersand
turnitclock wise.Thespindleshould tightenintotheinputshafteasily.
if possible
Polisherspindle
Threaded input shaft
Collar
