CONNECTINGTHETOOLTOAN AIRSUPPLY
1. Determineifthetoolneedsoil and, ifnecessary, placetwodropsof
oil intheAIRPLUG(GJ003)asshowninFigure2.Ifyouareusing an
automaticin-lineoiler, checkand add oilifnecessary.
2.Turnthecompressoron and settheregulatortotheproperpressure
forthesize andtypeoffastenerbeingused.
3. Connectthetooltotheairsupply(see Setup forairsupplyconnec-
tionrecommendations).
LOADINGTHEFASTENERS
1. Depress theLOCK(DB011)toreleasetheMOVABLEMAGA-
ZINE(HM033)andpull themagazineoutfullyasshowninFigure
3.
2. Placeafullclipofthespecifiedtypeandsize fastenersonthe
FIXEDMAGAZINE(GD038), upto100fastenersmaybe loaded
inthemagazine.
3.PushtheMOVABLEMAGAZINEASSEMBLYforwarduntil
itwaslocked.
OPERATINGTHETOOL
Testthedriving depthina samplepieceofwood beforeusing.If thefastenersarebeing driventoo farornot
farenough, adjusttheregulatortoprovideless airpressureormoreairpressure.
1.Connectthetooltotheairsupply.Makesuretheairpressureisincorrectrangedenotedinsection of
SPECIFICATIONS.
2.Loadfastenerasabovethedirectiongiveninthesection calledLOADTHEFASTENER.
3. HoldtheBody (KT046)and press theDriveguide(DT047)and safebrackettoworksurface, being surethe
toolisstraightandthengentlydepress theTrigger(BB007)todrivethefastener.
4.Liftthetooloff theworksurface.
5. Thetoolhastwodriving modes:
1). Putthedriveguideontheworking surface,lightlypushthetooltowardtheworkingsurfaceuntil the
safebracketisdepressed,then,depressthetriggertodrivethefastener.
2).First,depresstheTrigger,then,repeatedlyimpacttheSafebracket,thetoolcanrepeatedlydrivethe
fasteners.ThetoolwilldriveonefastenerwhentheSafebracketisimpactedonetime.
REGULARMAINTENANCE
1. Frequent, butnotexcessive, lubricationisrequiredforbestperformance.Oil addedthroughtheairlinecon-
nection willlubricateinternalparts.Anautomaticairlineoilierisrecommendedbutoil maybeaddedmanually
beforeeveryoperation orafterabout1hourofcontinuoususe. Onlya fewdropsofoil ata timearenecessary.
Toomuchoilwill collectinsidethetooland beblownoutduring theexhaustcycle. ONLYUSEPNEUMATIC
TOOLOIL. Donotusedetergentoiloradditives,astheselubricantswillcauseacceleratedweartotheseal
inthetool.
2. Usea small amountofoil on all moving surfaceand pivots.
3.Dirtand waterintheairsupplyaremajorcausesofpneumatictoolwear.Useafilter/oilerforbetter
performanceand longerlife.Thefiltermusthaveadequateflowcapacityforthespecificapplication. Con-
sultthemanufacturer'sinstructionsforpropermaintenanceofyoufilter.
4. Keeptoolscleanforbetterand saferperformance. Usenonflammablecleaning solutions (CAUTION: Such
solutionsmaydamagedO-ring and othertoolparts) onlyifnecessary- DONOTSOAK.
FIXEDMAGAZINE
LOCK
