Toro 04266 Manuale utente

FormNo.3427-206RevA

Out-FrontBrushKit

Greensmaster®800/1000/Flex™18/21/Flex™1800/2100/eFlex®

1800/2100Mower

ModelNo.04266

InstallationInstructions

Installation

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.

DescriptionQty.Use

Leftbrushbracket1

Rightbrushbracket1

Flangeheadbolt(3/8x1inch)2

Bolt(M10x30mm)2

Leveladjustmentscrew2

Jamnut(5/16inch)2

Locknut(5/16inch)2

Brushspring2

Brushrod2

Bolt(M6x40mm)4

Spacer4

Locknut(M6)4

Mountthebrushbrackets(GreensmasterFlexmodels

only)

Leftbrushbracket1

Rightbrushbracket1

Bolts(fullythreaded,5/16x1-1/2inches)4

Locknut(5/16inch)4

Leveladjustmentscrew2

Jamnut(5/16inch)2

Locknut(5/16inch)2

Brushspring2

Brushrod2

Bolt(M6x40mm)4

Spacer4

Locknut(M6)4

Mountthebrushbrackets(Greensmaster800/1000/2000

modelsonly)

Brush1

Brushtab2

Bolt(M8x60mm)4

Washer4

Locknut(M8)4

Flange-headbolt(M6x20mm)4

Flangenut(M6)4

Mountthebrush.

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.T oro.com.OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved*3427-206*A

Mountingthe

BrushBrackets

GreensmasterFlexModelsonly

1.Positionthemachineonalevelsurface,engage

theparkingbrake,removethekey(ifequipped),

disconnectthebattery,andshutoffthemachine.

2.Removetheboltandwashersecuringtheleft

endofthefrontframetothetabontopofthe

cuttingunit(Figure1).

g018505

Figure1

1.Bolt3.Frontframe

2.Washer

3.Mounttheleftbrushbrackettothefrontframe

andtabasfollows:

•OnFlex1800/2100models,securethe

brushbrackettothefrontframeandtabwith

aangeheadbolt(3/8x1inch)asshownin

Figure2.

•OnFlex18/21models,securethebrush

brackettothefrontframeandtabwithanew

bolt(M10x30mm)andthewasherthatwas

previouslyremoved(Figure2).

g018486

Figure2

1.Boltandwasher(Flex

18/21models)

4.Jamnut(5/16inch)

2.Flangeheadbolt(Flex

1800/2100models)

5.Brushbracket

3.Leveladjustmentscrew6.Locknut(5/16inch)

Note:Thebracketistobepositionedsothe

holeinthebottomistothefront.Thebracket

shouldtovertheendofthefrontframeandtab.

4.Looselymounttheleveladjustmentscrewtothe

brushbracketwithajamnut(5/16inch)anda

locknut(5/16inch)asshowninFigure2.

5.Mountabrushspringandbrushrodtothebrush

bracketwith(2)bolts(M6x40mm),spacers

andlocknuts(M6)asshowninFigure3.

Note:Ensurethatthebrushspringismounted

withthebumptotheoutside.Thebrushrod

shouldbecenteredinthebrushspringwhenitis

rotatedupward,intothestorageposition.

g017161

Figure3

1.Locknut(M6)4.Brushspring

2.Brushrod5.Bolt(M6x40mm)

3.Spacer

6.Repeatthisprocedureontheoppositesideof

themachine.

Note:Therewillbeleftoverlocknuts.

Mountingthe

BrushBrackets

Greensmaster800/1000/2000Models

only

1.Positionthemachineonalevelsurface,engage

theparkingbrake,removethekey(ifequipped)

andshutoffthemachine.

2.Removethe2boltsandwasherssecuringthe

grassbasketmountingrodtotheleftsideplate

(Figure4).Discardtheboltsbutretainthe

washers.

g017162

Figure4

1.Bolt3.Grassbasketmounting

rod

2.Washer

3.Securethegrassbasketmountingrodtotheleft

sideplatewith2new,fullythreadedbolts(5/16

x1-1/2inches)andthe2washersthatwere

previouslyremoved(Figure5).

4.Inserttheleftbrushbracketontotheboltand

secureitwith2locknuts(5/16inch)asshown

inFigure5.

g018504

Figure5

1.Leveladjustmentscrew3.Brushbracket

2.Jamnut4.Locknut(5/16inch)

Note:Thebracketistobepositionedsothat

theholeinthebottomistothefront.

5.Looselymounttheleveladjustmentscrewtothe

brushbracketwithajamnut(5/16inch)anda

locknut(5/16inch)asshowninFigure5.

6.Mountabrushspringandbrushrodtothebrush

bracketwith2bolts(M6x40mm),spacers,and

locknuts(M6)asshowninFigure6.

Note:Ensurethatthebrushspringismounted

withthebumptotheoutside.Thebrushrod

shouldbecenteredinthebrushspringwhenitis

rotatedupward,intothestorageposition.

g017164

Figure6

1.Locknut4.Brushspring

2.Brushrod5.Bolt

3.Spacer

7.Repeatthisprocedureontheoppositesideof

themachine.

MountingtheBrush

1.Ifthebrushisgoingtobeusedonan18inch

cuttingunit,measureandcut1-1/2inchesoff

eachendofthebrush.

2.Mountabrushtabtoeachendofthebrushwith

2bolts(M8x60mm),washers,andlocknuts

(M8).PositionthetabsasshowninFigure

7.Usetheouterholesforinstallationona21

inchcuttingunitandtheinnerholesfor18inch

cuttingunit.

Note:Thebrushbristlesarecutatanangle.

Mountthebrushsothelongerbristlesare

closesttothemachinewhenmowing.

3.Secureabrushrodmountingbrackettoeach

brushtabwith2angeheadbolts(M6x20mm)

andangenuts(M6)(Figure7).

g017165

Figure7

1.Brushweight(optional)6.Flangeheadbolt(M6x20

mm)

2.Flangenut(M6)7.Brush

3.Bolt(M8x60mm)8.Washer

4.Brushtab9.Locknut(M8)

5.Brushrodmounting

bracket

4.Adjusttheoperatingheightofthebrushand

levelitbylooseningthejamnuts,rotatingthe

adjustmentscrewstothedesiredpositionand

tighteningthejamnuts.

Note:Theendsofthebrushbristlesshouldbe

atonthegroundduringthemowingoperation.

Ifthebrushhopsduringoperation,rotatethe

brushsothatonlythefrontbristlestouchthe

surfaceandtherearbristlesarelessthan1/2

inchabovethesurface.

5.Rotatethebrushupwardandsecuretherods

intothebrushspringswhenthebrushisnot

required.
