Toro 134-3722 Manuale utente

FormNo.3431-222RevA

GroomerBrushKit

ProStripe560Mower

ModelNo.134-3722

InstallationInstructions

Safety

SafetyandInstructional

Decals

Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea

ofpotentialdanger.Replaceanydecalthatisdamagedormissing.

decal134-3990

134-3990

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.Toro.com.OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved*3431-222*A

Installation

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.

ProcedureDescriptionQty.Use

1Nopartsrequired–Preparethemachine.

Brush-adjustmentbracket1

Groomerbrush1

Capscrew(8x60mm)4

Washer(8mm)8

Locknut(8mm)4

Brush-heightplate2

Carriagebolt(8x25mm)2

Knob2

Strut(brush)2

Capscrew(6x20mm)2

Washer(6mm)4

Locknut(6mm)2

2Assemblethebrushmount.

Lowerbrushbracket2

Self-tapping,ange-headscrew(6x20

mm)4

Capscrew(6x20mm)2

Washer(6mm)4

Locknut(6mm)2

Assemblethebrushkittothemachine.

Capscrew(6x20mm)2

Washer(6mm)4

4Locknut(6mm)2

Assemblethebrushstrutstothe

machine.

5FrontFins1Installthefrontnsandthewheels.

6Nopartsrequired–Finishthekitinstallation.

PreparingtheMachine

NoPartsRequired

Procedure

WARNING

Thebladeissharp;contactingthebladecan

resultinseriouspersonalinjury.

Weargloveswhenservicingtheblade.

WARNING

Tippingthemachinemaycausethefuelto

leak.Fuelisammableandexplosive,and

cancausepersonalinjury.

Runtheenginedryorremovethefuelwitha

handpump;neversiphonthefuel.

Important:Donotaddfueltothefueltankprior

toinstallinggroomerbrushkit.

1.Runenginetoemptythefueltankorremovethe

fuelwithahandpump.

Ifyoudonotuseallthefuelinthetank,usea

handfuelpumptoremovethefuel.

2.Movethemachinetoalevelsurface,ensure

thattheengineisshutoff,andensurethatall

movingpartsstop.

3.Disconnectthespark-plugwirefromthespark

plug;refertotheOperator’sManualforyour

machine.

AssemblingtheBrush

Mount

Partsneededforthisprocedure:

1Brush-adjustmentbracket

1Groomerbrush

4Capscrew(8x60mm)

8Washer(8mm)

4Locknut(8mm)

2Brush-heightplate

2Carriagebolt(8x25mm)

2Knob

2Strut(brush)

2Capscrew(6x20mm)

4Washer(6mm)

2Locknut(6mm)

AssemblingtheGroomerBrushto

theBrush-AdjustmentBracket

g284576

Figure1

1.Capscrew(8x60mm)4.Locknut(8mm)

2.Washer(8mm)5.Groomerbrush

3.Brush-adjustmentbracket

1.Aligntheholesinthebrush-adjustmentbracket

withtheholesinthegroomerbrushasshown

inFigure1.

2.Assemblethebrush-adjustmentbrackettothe

groomerbrush(Figure1)with4capscrews(8

x60mm),8washers(8mm),and4locknuts

(8mm).

3.Tightenthecapscrewsandlocknuts.

AssemblingtheBrush-Adjustment

BrackettotheBrushMount

1.Assemblethebrushandbrush-adjustment

brackettothebrushmountasshowninFigure2.

Note:Ensurethattherodendsofthehandle

forthebrush-adjustmentbracketalignthrough

theslotsinthebrushmount.

g284577

Figure2

1.Endofthehandle

(brush-adjustment

bracket)

2.Slot(brushmount)

2.Assembleabrush-heightplateovertherodend

ofthehandleforthebrush-adjustmentbracket

asshowninFigure3.

g284575

Figure3

1.Brush-heightplate4.Brushmount

2.Handle(brush-adjustment

bracket)

5.Carriagebolt(8x25mm)

3.Knob6.Brush-adjustmentbracket

3.Assembleacarriageboltthroughtheopening

inthebrush-adjustmentbracket,theslotin

thebrushmountandthelowerholeinthe

brush-heightplate(Figure3).

4.Threadaknobontothecarriagebolt,andtighten

theknob(Figure3).

5.Repeatsteps2through4attheotherendofthe

brushmount.

AssemblingtheStrutstothe

BrushMount

1.Aligntheholeinthebrushstrutwiththeholeon

thetabofthebrushmountasshowninFigure4.

g284578

Figure4

1.Capscrew(6x20mm)4.Tab(brushmount)

2.Strut(brush)5.Locknut(6mm)

3.Washer(6mm)

2.Securethebrushstruttothebrushmount

(Figure4)withacapscrew(6x20mm),2

washers(6mm),andalocknut(6mm).

3.Repeatsteps1and2forthebrushstrutatthe

otherendofthebrushmount.

AssemblingtheBrushKit

totheMachine

Partsneededforthisprocedure:

2Lowerbrushbracket

4Self-tapping,ange-headscrew(6x20mm)

2Capscrew(6x20mm)

4Washer(6mm)

2Locknut(6mm)

RemovingtheWheels

1.Removetheangelocknut(3/8inch)that

securesthewheeltotheaxle,andremovethe

wheel(Figure5).

g284602

Figure5

1.Axle3.Flangelocknut(3/8inch)

2.Wheel

2.Repeatstep1forthewheelattheothersideof

themachine.

RemovingtheFrontFins

1.Tipthemachineontoitssidewiththeairlter

up(Figure6).

g283871

Figure6

2.Removethe7self-tapping,ange-headscrews

(6x20mm)thatsecurethefrontnstothe

supportsofthemowerdeck,andremovethe

frontns(Figure7).

Note:Youwillnotusethesefrontnswiththe

groomerbrushkit.

g284601

Figure7

1.Support(frontn—mower

deck)

3.Self-tapping,ange-head

screw(6x20mm)

2.Frontns

AssemblingtheLowerBrush

BracketstotheMachine

1.Aligntheholesinthelowerbrushbracketwith

theholesinthegroomerbrushsupportofthe

mowerdeckasshowninFigure8.

g284634

Figure8

1.Lowerbrushbracket3.Support(groomer

brush—mowerdeck)

2.Self-tapping,ange-head

screw(6x20mm)

2.Securethelowerbrushbrackettothegroomer

brushsupport(Figure8)with2self-tapping,

ange-headscrews(6x20mm).

3.Repeatsteps1and2fortheotherlowerbrush

bracketattheothersideofthemachine.

4.Carefullylowerthemachine(Figure9).

g284636

Figure9

AssemblingtheGroomerBrushto

theLowerBrushBrackets

1.Assembleacapscrew(6x20mm)andwasher

(6mm)throughtheholeinthebrushmount

(Figure10).

g284658

Figure10

1.Capscrew(6x20mm)3.Hole(brushmount)

2.Washer(6mm)

2.Assembletheothercapscrew(6x20mm)and

washer(6mm)throughtheotherholeinthe

brushmount(Figure10).

3.Alignthecapscrewsthatyouassembledinsteps

1and2throughtheholesofthelowerbrush

bracketsasshowninFigure11.

g284657

Figure11

1.Capscrew(6x20mm)3.Washer(6mm)

2.Lowerbrushbracket4.Locknut(6mm)

4.Assemblethebrushmountandcapscrewsto

thelowerbrushbrackets(Figure11)with2

washers(6mm)and2locknuts(6mm).

5.Tightenthecapscrewsandlocknuts.

InstallingtheBrushStruts

totheMachine

Partsneededforthisprocedure:

2Capscrew(6x20mm)

4Washer(6mm)

2Locknut(6mm)

DrillingtheDeckfortheRight

BrushStrut

1.Attherightsideofthemowerdeck,alignthe

brushstrut90°tothetothebrushmount(Figure

12).

g284670

Figure12

1.Centerpunchmark

(mowerdeck)

2.6.5mmdrillbit

2.Marktheholelocationofthebrushstrutontothe

deck(Figure12).

3.Movethestrutupandcenterpunchthemidpoint

ofthemarkthatyoumadeinstep2.

4.Drillthecenterpunchmarkwitha6.5mmdrill

bit(Figure12).

5.Removeanyburrsfromthehole.

AssemblingtheRightBrushStrut

totheMachine

1.Aligntheholeinthebrushstrutwiththeholein

thedeck.

g284669

Figure13

1.Capscrew(6x20mm)4.Locknut(6mm)

2.Washer(6mm)5.Deck

3.Rightbrushstrut

2.Assemblethebrushstruttothemowerdeck

(Figure13)withacapscrew(6x20mm),2

washers(6mm),andalocknut(6mm).

3.Tightenthecapscrewandlocknut.

DrillingtheDeckfortheLeftBrush

Strut

1.Attheleftsideofthemowerdeck,alignthe

brushstrut90°tothetothebrushmount(Figure

14).

g284728

Figure14

1.6.5mmdrillbit2.Centerpunchmark(mower

deck)

2.Marktheholelocationofthebrushstrutontothe

deck(Figure14).

3.Movethestrutupandcenterpunchthemidpoint

ofthemarkthatyoumadeinstep2.

4.Drillthecenterpunchmarkwitha6.5mmdrill

bit(Figure14).

5.Removeanyburrsfromthehole.

AssemblingtheLeftBrushStrut

totheMachine

1.Aligntheholeinthebrushstrutwiththeholein

thedeck(Figure15).

g284725

Figure15

1.Leftbrushstrut4.Locknut(6mm)

2.Capscrew(6x20mm)5.Washer(6mm)

3.Deck

2.Assemblethebrushstruttothemowerdeck

(Figure15)withacapscrew(6x20mm),2

washers(6mm),andalocknut(6mm).

3.Tightenthecapscrewandlocknut.

InstallingtheFrontFins

andtheWheels

Partsneededforthisprocedure:

1FrontFins

AssemblingtheFrontFinstothe

Machine

1.Aligntheholesinthenewfrontnwiththeholes

inthesupportsofthemowerdeck(Figure16).

g285247

Figure16

1.Support(frontn—mower

deck)

3.Self-tapping,ange-head

screw(6x20mm)

2.Frontns

2.Assemblethefrontnstothemowerdeck

(Figure16)withthe7self-tapping,ange-head

screws(6x20mm)thatyouremovedin

RemovingtheFrontFins(page5).

3.Tightentheself-tapping,ange-headscrews.

AssemblingtheWheelstothe

Machine

1.Assembleawheelontotheaxlewiththeange

locknut(3/8)thatyouremovedinRemovingthe

Wheels(page5).

g284727

Figure17

1.Axle3.Flangelocknut(3/8inch)

2.Wheel

2.Tightenthelocknut.

3.Repeatsteps1and2forthewheelattheother

sideofthemachine.

FinishingtheKit

Installation.

NoPartsRequired

Procedure

Addfueltothefueltank;refertotheOperator’s

Manualforyourmachine.

Operation

AdjustingtheBrushAngle

1.Loosentheknobsatthesidesofthebrush

mount(Figure18).

g284762

Figure18

1.Knob

2.Usethehandleofthebrush-adjustmentbracket

toadjusttheangleofthegroomerbrush(Figure

18).

Note:Tiltingthebrushforwardincreasesits

aggressiveness.Tiltingthebrushrearward

decreasesitsaggressiveness.

3.Tightentheknobs(Figure18).

AdjustingtheBrushHeight

1.Loosentheknobsatthesidesofthebrush

mount(Figure19).

g284761

Figure19

1.Knob2.Brush-heightplate

2.Usethehandleofthebrush-adjustmentbracket

toraiseorlowerthegroomerbrush(Figure19).

Note:Ensurethatthebrush-heightplatepoints

tothesameheightnumberatbothsidesofthe

brushmount.

3.Tightentheknobs(Figure19).
