Torqueleader QSA series Manuale utente
Ergo Quickset- Calibrated
Torque Screwdriver
QSN&QSAModels
KalibriertDrehmomentschraubendreher-Tournevisdynamométrique,
Calibradoatornillador-CalibratocoppiaCacciavite
OperatorsManual
InstructionPartNumber P26630Issue2
ErgoQuickset–CalibratedTorqueScrewdriver –QSN& QSA
2
Products:QSN –All Models
QSA –All Models
MechanismType:Slipping
ISO 6789 Designation:Type 2, Class D
Repeatability:+/-6%ofTorqueSetting
Calibration Period:Every12Monthsor 5000cycles (minimum)
•UseonlyasaTorqueScrewdriver.
•Donotuseasahammer,chiselorprybar.
•Onlyholdthetoolusing thehandle.
•Forincreasedleverage,usetheT-Bar provided (QSN600/900 &QSA50/80only)
•Always ensurethat thescrewdriverisin correct alignmentwiththe
fastener.
•Torquetoolsshouldberegularlycalibratedandinspectedtoensure
correctoperation.
•Ensurethetoolis cleanandfreeof oil,greaseandwater beforeuse.
•Neverdip intocleaningfluidorpetroleum.
Safety& Maintenance
Spareparts, servicingandcalibrationinstructionsareavailablefrom
Torqueleader.Pleasecontactusorvisit www.torqueleader.com for
furtherinformation.
SalesHotline+44(0)1483894476
ErgoQuickset–CalibratedTorqueScrewdriver –QSN& QSA
3
1
2
3
4
www.torqueleader.com
AdjustmentProcedure
PressKnob
Engagetheadjustingmechanismbypressing
andholdingdowntheanodisedadjustingknob.
IncreaseTorque
Rotatethehandleclockwiseuntil therequired
torqueisselectedonthecalibratedscale.
Reduce Torque
When adjusting,alwaysapproachtherequired
torquefromalowersetting.
Rotatethehandleanti-clockwisepastyour
setting,thenincreasetorquetotherequired
value.
IncreaseLeverage
QSN500,QSN900,QSA50 &QSA90models
areprovidedwithaSliding T-Bartoincrease
theleverageathighertorques. Thisfitsintothe
¼”SquareDriveintheendofthehandle.
ErgoQuicksetScrewdriverisdesignedforuse
withsocketsandscrewdriverbitsandblades.
At thesettorque,thehandlerotatesthrough
an angleof 60Obeforeresetting.
Afteruse, setthescrewdriveratthelowest
settingonthescale.
Torqueleader–TakingTheRiskoutOf Tightening
Measure
LaboratoryCalibrate
Apply
•Regularcalibration toInternationalStandards
isvital toensurethatyourtorqueequipmentis
operating atitspeakperformance.
•WehaveaUKASCalibrationLaboratory,
accredited toISO/IEC17025:2005onsite,
capableof recalibrating most HandTorque
Tools,Analysersand Transducersin
accordancewiththe InternationalStandards.
•Torquemeasuringtoolsareused inResearch,
Development,InspectionandQualityControl
wherethereisaneedtochecktorque settings.
Thistype oftoolcan alsobeused inaservicing
orProduction environmenttoapplytorque.
•Measuring TorqueToolsfeatureadialordigital
readoutand areavailableinscrewdriveror
wrenchformats, coveringtorque valuesupto
2000N.m.
•Torqueapplying toolsareused toapplyaset
torque toafastener.Thetool will Click, Break or
Slip tosignal tothe operatorwhen theset torque
hasbeenachieved.
•Preset toolsareidealforproductionareaswhere
the sametorqueisapplied repeatedly.
•CalibratedScale toolsareoperatoradjustable
andareidealforservicing applicationswhere
easeof adjustmentisessential.
Torqueleaderoffertwotypesof TorqueAnalyser:
•Mechanical Analysersofferalowcost robust
andeasytousedevice, designedtosetand
calibratelowrange torquetools.
•Digital Analysersallowthe usertodownload
test results,testpowered torquetoolsand reach
highertorquevaluesthanarepossibleusing
mechanical analysers.
