Toshiba E-Studio 2007 Manuale utente

OPEN SIDE COVER

MISFEED E130

Printed in China 6LJ83562200

e-STUDIO2007/2507/2507i Ver01 F 2013-11

Troubleshooting

On Bypass tray

Toner empty

Paper misfeed

x 10

User's Guide: Chapter 6

Basic Operations Before Use

This manual describes the components, preparations, basic operations, and troubleshooting for the equipment. Before using the equipment,

read the Safety Information (Printouts). The DVD bundled with the equipment contains the User's Guide (PDF le) besides this guide.

Trademarks

Company names and product names in this manual are the trademarks of their respective companies.

MULTIFUNCTIONAL DIGITAL SYSTEMS

Component Description

Quick Guide

Equipment User's Guide: Chapter 1

Behind transfer unit

In Side cover

789

In RADF

Turning on

Control panel

4321

24232221201918171615

13 1411109876 12

Reversing1.

Automatic

Document Feeder

(RADF)*

Platen sheet

Original glass3.

Control panel4.

Platen Cover*5.

Side cover6.

USB port7.

Bypass tray8.

Automatic9.

Duplexing Unit*/**

Toner cartridge

10.

Front cover11.

D r a w e r12.

Paper Feed Unit13.

(PFU)*

Paper Feed

14.

Pedestal*

Drawer Module*

15.

Power switch16.

Paper exit stopper17.

AC-IN terminal18.

(rear)

FAX port*

19.

Network interface20.

connector

USB terminal

21.

(4-pin)

Receiving tray

22.

Scanning area23.

Original scale24.

RESOLUTION*1.

PAUSE*2.

MULTI.*3.

ADDRESS BOOK*4.

One Touch*5.

COPY6.

SCAN7.

FAX8.

USER FUNCTIONS9.

JOB STATUS10.

SETTINGS11.

TEMPLATE12.

ENERGY SAVER13.

FUNCTION CLEAR14.

DRAWER15.

LCD screen16.

DATA17.

Alert lamp18.

CANCEL19.

20.

OK21.

Digital keys22.

START23.

CLEAR/STOP24.

In PFU

* optional

** standard for e-STUDIO2507i

Before Use Basic Operations

Component Description Troubleshooting

Printer

and scanner

functions

are available.

1. Select [Print] from the application's [File] menu. Scan to USB Memory

1. Place the original(s).

2. Press [SCAN].

3. Connect the USB storage device to the equipment and wait a

few seconds.

4. Press or to select “USB”, and then press [OK].

5. Press to make the scan settings as required.

6. Press [START] to scan your documents.

TWAIN Scan

1. Place the original(s).

2. Launch a TWAIN-compliant application.

3. Select the device from the application’s [File] menu.

4. Select the menu to scan from the application’s [File] menu.

5. Make the scan settings, and then click [Scan].

3. Enter the number of copies with

the digital keys

, and then press

[START]

to copy.

To stop copying

Press [CLEAR/STOP]

Shortcut keys

Press : “ORIGINAL MODE”

Press : Europe and Americas“EXPOSURE”,

Except Europe and Americas “ID CARD”

2. Select your printer

, and then

click [Preferences]

3. Make print option settings, and then click [OK].

4. Click [Print] ([OK]).

Copier User's Guide: Chapter 2

Printer User's Guide: Chapter 3 Scanner User's Guide: Chapter 4

Bypass tray

Drawer

Loading paper User's Guide: Chapter 1

To reset settings and LCD screen after copying

Press [FUNCTION CLEAR]

2. Press [COPY] and make the copy

settings.

READY

100%

AUTO EXPOSURE

TEXT/PHOTO

1A4

RADF

1. Place the original(s). Original glass

Sending a Fax

1. Place the original(s).

2. Press [FAX].

3. Make settings for transmission

conditions.

4. Specify the destination.

5. Press [START].

Fax Fax Guide

Registering an Address Book

1. Press [USER FUNCTIONS].

2. Select “ADDRESS BOOK” →“PHONE

BOOK”.

3. Make settings for“SPEED DIAL”,

“GROUP DIAL”, and “ONE TOUCH”, and

then press [OK].

To set paper size of Drawer

When you load paper in the drawer, a pop-up window appears. Follow the

instructions and set the paper size. (When the "POP UP" function is set to

“ENABLE”.)

Installing the driver requires the administrator authority.

For Windows 7, Windows 8, Windows Server 2008 R2, or

Windows Server 2012, use the installer.

Note when installing from installer

Close all running applications.•

If the installer does not automatically start, double-click “Setup.exe”•

in the DVD.

Driver installation Software Installation Guide: Chapter 2

Using installer

1. Close all running applications.

2. When a USB cable is connected, make sure that the equipment is

turned o.

3. Insert the DVD into the computer.

4. Double-click “Setup.exe”.

5. Follow the on-screen instructions.

Connecting computer

Before installing the drivers, connect the equipment and the

computer with a USB cable or Network interface cable.

Connecting Cables

1. Line Connect a telephone line.

2. TEL Connect an external telephone.
