Toshiba TS605 Manuale operativo

MOBILE COMMUNICATIONS DIVISION

CUSTOMER SERVICES

Version 1.0 22/11/2006

Created by Konrad Szombara Page 1 of 103

TS605 / TS2050

Technical Service

Manual

MOBILE COMMUNICATIONS DIVISION

CUSTOMER SERVICES

Version 1.0 22/11/2006

Created by Konrad Szombara Page 2 of 103

INDEX PAGE

1.0 GENERAL ADVICE 5

1.1 CUSTOMER CARE SOLUTIONS 6

1.2ESDPROTECTION 7

2.0 HANDSET SPECIFICATION AND INTRODUCTION 8

2.1 HANDSET SPECIFICATION 9

2.1.1 HARDWARE 9

2.1.2 SOFTWARE 10

2.1.3 PHYSICAL 11

2.1.4 VIDEO 12

2.1.5 OTHERS 13

2.1.6 PRODUCT OVERVIEW 15

2.2INTERFACES 16

2.2.1 SIM CARD INTERFACE 16

2.2.2 MEMORY CARD INTERFACE 18

2.2.3 BATTERY INTERFACE 20

2.2.4 CHARGING THE BATTERY 21

2.2.5 CHARGING INDICATOR 22

2.3 HANDSET USER INTERFACE 23

2.3.1 HANDSET DESCRIPTION 23

2.3.2 KEY FUNCTIONS 24

2.3.3 DISPLAY CONCEPT 26

2.3.4 MAIN MENU 27

2.4MMITEST 29

3.0 MECHANICAL CONCEPT 30

3.1 EXPLODED VIEW 31

3.2 MECHANICAL SPARE PARTS LIST 33

3.3 SPARE PARTS PHOTO 34

4.0 DISASSEMBLY AND REASSEMBLY PROCEDURE 35

4.1DISASSEMBLY 36

4.2REASSEMBLY 43

MOBILE COMMUNICATIONS DIVISION

CUSTOMER SERVICES

Version 1.0 22/11/2006

Created by Konrad Szombara Page 3 of 103

INDEX PAGE

5.0 SOFTWARE DOWNLOAD 53

5.1 SOFTWARE DOWNLOAD 54

5.1.1 DOWNLOAD CABLES 54

5.1.2 DOWNLOAD TOOL 55

5.1.3 EQUIPMENT SETTING 56

5.1.4 MAIN PROGRAM INTERFACE 57

5.1.5 BACKUP TOOL 59

6.0 SYSTEM MODULE AND USER INTERFACE 60

6.1 TECHNICAL DESCRIPTION 61

6.1.1 RF OVERVIEW 61

6.1.2 RF FUNCTION BLOCK DIAGRAM 62

6.1.3 FREQUENCY PLAN 63

6.1.4 TRANSMITTER 64

6.1.5 RECEIVER 65

6.2 BASEBAND OVERVIEW 66

6.2.1 INTRODUCTION 67

6.2.2 CPU MEMORY 68

6.2.3 REAL TIME CLOCK (RTC) 68

6.2.4 LCD MODULE 68

6.2.5 CAMERA / BACKEND IC 68

6.3SWITCHES 69

6.3.1 KEYPAD 69

6.3.2 POWER KEY 69

6.4 AUDIO SYSTEM 70

6.4.1 VOICE BAND CODEC 71

6.4.2 MICROPHONE 72

6.4.3 RECEIVER 72

6.4.4SPEAKER 73

6.5 POWER MANAGEMENT 73

6.5.1 POWER ON SEQUENCE 74

6.5.2 POWER SOURCE 75

6.5.3 REGULATOR CONTROL 75

6.5.4VOLTAGE REGULATION 75

MOBILE COMMUNICATIONS DIVISION

CUSTOMER SERVICES

Version 1.0 22/11/2006

Created by Konrad Szombara Page 4 of 103

INDEX PAGE

7.0 TROUBLE SHOOTING 77

7.1 MAIN TROUBLE SHOOTING DIAGRAM 78

7.1.1 NO POWER UP 79

7.1.2 FLASH FAILED 80

7.1.3 WILL NOT READ SIM CARD 81

7.1.4 POOR SERVICE 82

7.1.5 WILL NOT CHARGE 83

7.1.6 LCD FAILURE 84

7.1.7 BUZZER FAULT 85

7.1.8 VIBRATOR FAULT 86

7.1.9 FAULTY KEYPAD 87

7.1.10 FAULTY RTC 88

7.1.11FAULTY MICROPHONE 89

7.1.12 LCD TESTING 90

7.1.13 FAULTY CAMERA 91

7.2 CONNECTIONS 92

7.2.1 CONNECTIONS ON BOARD 92

7.2.2 ACF CONNECTIONS 93

7.2.3 MAIN BASEBAND IC’S 94

7.2.4 MAIN RF IC’S 96

7.2.5 CONNECTORS ON KEYPAD PCB 97

7.3 ACF – ANISOTROPIC CONDUCTIVE FILM 98

7.4 LABEL SPECIFICATION 103

MOBILE COMMUNICATIONS DIVISION

CUSTOMER SERVICES

Version 1.0 22/11/2006

Created by Konrad Szombara Page 5 of 103

1.0 GENERAL ADVICE

MOBILE COMMUNICATIONS DIVISION

CUSTOMER SERVICES

Version 1.0 22/11/2006

Created by Konrad Szombara Page 6 of 103

1.1 CUSTOMER CARE SOLUTIONS

TECHNICAL DOCUMENTATION

Warnings

1- Care must be taken on installation in vehicles fitted with electronic

engine management systems and ABS. Under certain faulty conditions,

emitted RF energy can affect their operation.

2- The handset must not be operated in areas likely to contain potentially

explosive atmospheres, e.g. Petrol/Gas stations.

3- Operation of any radio transmitting equipment may interfere with the

functionality of inadequately protected medical equipment. All

electronic equipment may also be subject to interference.

4- All documentation within this service manual must remain confidential

and should not be shared with any unknown 3rd party, without written

consent from Toshiba MCD, UK.

Cautions

1- Servicing and alignment must be undertaken by qualified personnel

only.

2- Ensure all work is carried out at an ESD protected work station.

3- Ensure that the qualified technician is wearing all necessary ESD

protective clothing such as wrist straps and heel straps.

4- Ensure solder, wire and/or other foreign matter do not enter the

handset as damage may result.

5- Use only approved components as specified in the parts list.

6- Ensure all components are correctly refitted after servicing and

alignment. Ensure all mechanical fittings are reassembled correctly.

MOBILE COMMUNICATIONS DIVISION

CUSTOMER SERVICES

Version 1.0 22/11/2006

Created by Konrad Szombara Page 7 of 103

1.2 ESD (Electro Static Discharge)PROTECTION

SERVICE REQUIRMENTS

1- Toshiba require that all TPSV’s ensure that the technicians work bench

has sufficient ESD protection.

2- Accessories such as batteries, chargers, multimedia cards and sim

cards can be replaced in normal conditions (Non ESD protected

environment).

3- A mobile handset contains many parts such as LCD’s and cameras.

These parts, along with more discreet components such as resistors

and capacitors are susceptible to ESD.

4- Metallised protective bags must be used during any transportation of

ESD sensitive parts, including the PCB.

5- All repair actions other than accessory replacement, must be

conducted under ESD protection.

Should you require any further information on ESD please refer to

www.static-sol.com

MOBILE COMMUNICATIONS DIVISION

CUSTOMER SERVICES

Version 1.0 22/11/2006

Created by Konrad Szombara Page 8 of 103

2.0 HANDSET

SPECIFICATION AND

INTRODUCTION

MOBILE COMMUNICATIONS DIVISION

CUSTOMER SERVICES

Version 1.0 22/11/2006

Created by Konrad Szombara Page 9 of 103

2.1 HANDSET SPECIFICATION

2.2.1 HARDWARE

Item Description Remark

Frequency EGSM-900(880MHz– 960MHz).

GSM-1800(1710MHz– 880MHz)

PCS-1900(1850MHz– 990MHz)

Three-band

Display 1.93" 176X220 TFT Citizen

Camera 1.3 Mega CMOS

w/o Marco

Bluetooth

V1.2

Vender: CSR

Chipset: BC3-ROM

Support: v1.2

Power Class: Class 2 or 3

Max Size of data of phone

memory : 350KB

FM Radio with RDS Silicon Lab SI4701

IrDA N/A

Multimedia Chip AIT 811T Support MP3, 1.3 M, T-flash

Audio Codec Wolfson

System Memory 256Mb(NOR) + 64Mb(SRAM) Study Nuro bit type

Built-In Memory Option

External Memory Card 1024Mb Micro SD Flash

Base Band AD6527 + AD6537B

RF CX74117+CX77328

MOBILE COMMUNICATIONS DIVISION

CUSTOMER SERVICES

Version 1.0 22/11/2006

Created by Konrad Szombara Page 10 of 103

2.1.2 SOFTWARE

Item Description Remark

WAP WAP 2.0

MMS OMA 1.1

DRM Ver. 1.0 Openwave

IMPS Ver. 1.2 Magic4

Java Yes Esmertec

Doja N/A

KVM yes JTWI 1.0

JSR-75 PDA PIM & FC yes

JSR-120 WMA 1.1 Yes

JSR-135 Yes

JSR-205 WMA 2.0 Yes

JSR-234 Advanced

Multimedia Supplements N/A

JSR-248 Mobile Service

Architecture for CLDC N/A

JSR-185 JTWI

Yes JTWI (Mandatory: JSR-30

CLDC 1.0 + JSR -120

Wireless Messaging API +

JSR-118 MIDP 2.0)

(Conditional: JSR-135

MMAPI (mobile multimedia

API) + JSR-139 CLDC 1.1)

Text Input T9 Input 6.1.3 TBD, define by Toshiba

SynML DS 1.1.2 ExtendSI

SynML DM N/A

Email POP3/SMTP

QR code recognition N/A TBD
