Satellite®A500 Series

Resource Guide

Keep this guide in a convenient place to access important

information about your computer.

If you need assistance:

❖Toshiba’s Support Web site

pcsupport.toshiba.com

❖Toshiba Customer Support Center

Calling within the United States (800) 457-7777

Calling from outside the United States (949) 859-4273

Please fill in for your reference and future use:

Model name______________________________________

Part number______________________________________

Serial number____________________________________

RG 5.375 x 8.375 ver 2.3.2

Contents

Introduction ...................................................................................... 23

Setting up your computer and getting started................................... 25

Adding memory (optional)................................................................ 29

Your computer’s TFT display............................................................. 36

Inserting an ExpressCard®............................................................... 36

Removing an ExpressCard®.............................................................. 37

Learning the basics........................................................................... 37

Using the TouchPad™....................................................................... 38

Using the optical drive ...................................................................... 42

Moving the computer........................................................................ 46

Mobile computing............................................................................. 47

Taking care of your battery ............................................................... 50

If something goes wrong.................................................................. 53

If you need further assistance........................................................... 56

Power cord/cable connectors ........................................................... 57

Features and specifications............................................................... 57

Index ................................................................................................. 58

5.375 x 8.375 ver 3.1

Handling the cord on this product will expose you to lead, a chemical known

to the State of California to cause birth defects or other reproductive harm.

Wash hands after handling.

Model: Satellite®A500 Series

Recordable and/or ReWritable Drive(s) and

Associated Software Warranty

The computer system you purchased may include Recordable and/or

ReWritable optical media drive(s) and associated software, among the most

advanced data storage technologies available. As with any new technology,

you must read and follow all set-up and usage instructions in the applicable

user guides and/or manuals enclosed or provided electronically. If you fail

to do so, this product may not function properly and you may lose data or

suffer other damage. TOSHIBA AMERICA INFORMATION SYSTEMS,

INC. (“TOSHIBA”), ITS AFFILIATES AND SUPPLIERS DO NOT

WARRANT THAT OPERATION OF THE PRODUCT WILL BE

UNINTERRUPTED OR ERROR FREE. YOU AGREE THAT TOSHIBA,

ITS AFFILIATES AND SUPPLIERS SHALL HAVE NO

RESPONSIBILITY FOR DAMAGE TO OR LOSS OF ANY BUSINESS,

PROFITS, PROGRAMS, DATA, NETWORK SYSTEMS OR

REMOVABLE STORAGE MEDIA ARISING OUT OF OR RESULTING

FROM THE USE OF THE PRODUCT, EVEN IF ADVISED OF THE

POSSIBILITY THEREOF.

Protection of Stored Data

For your important data, please make periodic back-up copies of all the

data stored on the hard disk or other storage devices as a precaution against

possible failures, alteration, or loss of the data. IF YOUR DATA IS

ALTERED OR LOST DUE TO ANY TROUBLE, FAILURE OR

MALFUNCTION OF THE HARD DISK DRIVE OR OTHER

STORAGE DEVICES AND THE DATA CANNOT BE RECOVERED,

TOSHIBA SHALL NOT BE LIABLE FOR ANY DAMAGE OR LOSS

OF DATA, OR ANY OTHER DAMAGE RESULTING

THEREFROM. WHEN COPYING OR TRANSFERRING YOUR

DATA, PLEASE BE SURE TO CONFIRM WHETHER THE DATA

HAS BEEN SUCCESSFULLY COPIED OR TRANSFERRED.

TOSHIBA DISCLAIMS ANY LIABILITY FOR THE FAILURE TO

COPY OR TRANSFER THE DATA CORRECTLY.

5.375 x 8.375 ver 3.1

Critical Applications

The computer you have purchased is not designed for any “critical

applications.” “Critical applications” means life support systems, medical

applications, connections to implanted medical devices, commercial

transportation, nuclear facilities or systems or any other applications where

product failure could lead to injury to persons or loss of life or catastrophic

property damage. ACCORDINGLY, TOSHIBA, ITS AFFILIATES

AND SUPPLIERS DISCLAIM ANY AND ALL LIABILITY

ARISING OUT OF THE USE OF THE COMPUTER PRODUCTS IN

ANY CRITICAL APPLICATIONS. IF YOU USE THE COMPUTER

PRODUCTS IN A CRITICAL APPLICATION, YOU, AND NOT

TOSHIBA, ASSUME FULL RESPONSIBILITY FOR SUCH USE.

EU Declaration of Conformity

TOSHIBA declares that this product conforms to the following Standards:

This product is carrying the CE-Mark in accordance with the related

European Directives. The party responsible for CE-Marking is TOSHIBA

Europe GmbH, Hammfelddamm 8, 41460 Neuss, Germany.

The European Union WEEE (Waste from Electrical and

Electronic Equipment) Directive Information

The European Union WEEE (Waste from Electrical and Electronic Equipment)

Directive is intended to protect the quality of the environment and human health

through the responsible use of natural resources and the adoption of waste

management strategies that focus on recycling and reuse. This Directive requires

producers of electrical and electronic products put on the market in European

Union (EU) member countries after August 2005 to mark such products with a

crossed-out wheeled bin with a black bar symbol. If the product’s battery or

accumulator contains more than the specified values of lead (Pb), mercury (Hg),

and/or cadmium (Cd) defined in the Battery Directive (2006/66/EC), then the

chemical symbols for lead (Pb), mercury (Hg) and/or cadmium (Cd) will appear

below the crossed out wheeled bin symbol on the battery.

Supplementary

Information:

*The product complies with the

requirements of the Low Voltage

Directive 73/23/EEC, the EMC Directive

89/336/EEC and/or the R&TTE

Directive 1999/5/EC.

Pb, Hg, Cd

5.375 x 8.375 ver 3.1

In the European Union, these symbols indicate that when the last end user wishes

to discard this product, it must be sent to appropriate facilities for recovery and

recycling. This Directive applies to EU member countries only and does not

apply to end users in other countries such as the United States.

Although the initial emphasis is in Europe, Toshiba is already working with

design engineers, suppliers, and other partners to determine appropriate

worldwide product life cycle planning and end-of-life strategies for our products.

Please contact your local government for applicable laws and regulations

governing the disposal of this product. For information on how to trade-in or

recycle your product, visit www.reuse.toshiba.com.

VCCI Class B Information

Modem Warning Notice

Conformity Statement

The equipment has been approved to [Commission Decision “CTR21”] for

pan-European single terminal connection to the Public Switched Telephone

Network (PSTN).

However, due to differences between the individual PSTNs provided in

different countries/regions the approval does not, of itself, give an

unconditional assurance of successful operation on every PSTN network

termination point.

In the event of problems, you should contact your equipment supplier in the

first instance.

Taiwan

The legal communications mentioned in the above item refer to radio

communications operated in accordance with telecommunication laws and

regulations.

Article 14 Unless approved, for any model accredited low power radio frequency electric

machinery, any company, trader or user shall not change the frequency,

increase the power or change the features and functions of the original design.

Article 17 Any use of low power radio frequency electric machinery shall not affect

aviation safety and interfere with legal communications. In the event

interference is caused, the use of such electric machinery shall be immediately

discontinued. Operation of such products can be resumed only when they are

modified and can no longer cause interference.

5.375 x 8.375 ver 3.1

Low power radio frequency electric machinery shall resist against

interference from legal communications or from industrial, scientific and

medical radio emission electric machinery.

Using this Equipment in Japan

In Japan, the frequency bandwidth of 2,400 MHz to 2,483.5 MHz for

second generation low-power data communication systems such as this

equipment overlaps that of mobile object identification systems (premises

radio station and specified low-power radio station).

1. Sticker

Please put the following sticker on devices incorporating this product.

2. Indication

The indication shown below appears on this equipment.

12.4: This equipment uses a frequency of 2.4 GHz.

2DS: This equipment uses DS-SS modulation.

OF: This equipment uses OFDM modulation.

3The interference range of this equipment is less than 40m.

4This equipment uses a frequency bandwidth from

2,400 MHz to 2,483.5 MHz.

It is possible to avoid the band of mobile object identification systems.

The frequency bandwidth of this equipment may operate within the

same range as industrial devices, scientific devices, medical

devices, microwave ovens, licensed radio stations and non-licensed

specified low-power radio stations for mobile object identification

systems (RFID) used in factory product lines (Other Radio Stations).

1. Before using this equipment, ensure that it does not interfere with

any of the equipment listed above.

2. If this equipment causes RF interference to other radio stations,

promptly change the frequency being used, change the location

of use, or turn off the source of emissions.

3. Contact TOSHIBA Direct PC if you have problems with interference

caused by this product to Other Radio Stations.

2.4DSOF4

(1) (2) (3)

(4)

5.375 x 8.375 ver 3.1

The indication shown below appears on this equipment.

12.4: This equipment uses a frequency of 2.4 GHz.

2FH: This equipment uses FH-SS modulation.

3The interference range of this equipment is less than 10m.

4This equipment uses a frequency bandwidth from 2,400 MHz to

2,483.5 MHz.

3. TOSHIBA Direct PC

Monday – Friday: 10:00 – 17:00

Toll Free Tel: 0120-15-1048

Direct Dial: 03-3457-4850

Fax: 03-3457-4868

Device Authorization

This device obtains the Technical Regulation Conformity Certification and

the Technical Conditions Compliance Approval, and it belongs to the

device class of radio equipment of low-power data communication system

radio station stipulated in the Radio Law and the Telecommunications

Business Law of Japan.

The name of the radio equipment: refer to the equipment label provided on

the computer

Approved by both the JAPAN APPROVALS INSTITUTE FOR

TELECOMMUNICATIONS EQUIPMENT and the TELECOM

ENGINEERING CENTER

The following restrictions apply:

❖Do not disassemble or modify the device.

❖Do not install the embedded wireless module into other device.

❖5.17 GHz to 5.23 GHz for indoor use only.

2.4FH1

(1) (2) (3)

(4)

5.375 x 8.375 ver 3.1

Radio Approvals for Wireless Devices

The following information is dependent on what type of wireless device is in

your computer. Not all devices are available on all models.

Approved Countries/Regions for the Intel®Wireless Wi-Fi®

Link 5100/5300 Series

This equipment is approved to the radio standard by the countries/regions in the

following table.

Do not use this equipment except in the countries/regions in the following

table.

Andorra Argentina CNC:

533AN_HMW: “CNC C-6367”

533AN_MMW: “CNC C-6366”

512AN_HMW: “CNC C-6373”

512AN_MMW: “CNC C-6374”

Australia

Austria Azerbaijan Bahrain

Belgium Bermuda Bosnia

Brazil Bulgaria Caicos Islands

Cambodia Canada Cayman Islands

Chile China Colombia

Costa Rica Croatia Curacao, Netherlands

Antilles

Cyprus Czech Republic Denmark

Dominican Republic Ecuador El Salvador

Egypt Estonia Falkland Islands

Finland France French Guinea

French Polynesia Germany Ghana

Gibraltar Greece Guadeloupe

Guam Guatemala Herzegovina

Honduras Hong Kong Hungary

Iceland India Indonesia

Ireland Israel Italy

Japan Jordan Kenya

Kuwait Latvia Lebanon

Liechtenstein Lithuania Luxemburg

Malawi Malaysia Malta

Martinique Mayotte Mexico

Monaco Montenegro Montserrat

Morocco Netherlands New Caledonia

5.375 x 8.375 ver 3.1

Approved Countries/Regions for the Atheros®Wireless Wi-Fi®

Link AR5B95 Series

This equipment is approved to the radio standard by the countries/regions in the

following table.

Do not use this equipment except in the countries/regions in the following

table.

New Zealand Nicaragua Norway

Oman Pakistan Panama

Paraguay Peru Philippines

Poland Portugal Puerto Rico

Qatar Réunion Romania

Russia Saint Martin Saipan

San Marino Saudi Arabia Serbia

Singapore Slovakia Slovenia

South Africa South Korea Spain

Sri Lanka Sweden Switzerland

Tahiti Taiwan Turkey

Turk Islands Ukraine UAE

(United Arab Emirates)

United Kingdom Uruguay USA

Vatican Venezuela Vietnam

Virgin Islands Zimbabwe

Albania Argentina CNC:

693 GI/2007

3655 GI/2007

Australia

Austria Azerbaijan Bahrain

Bangladesh Belgium Bolivia

Bosnia Brazil Brunei

Bulgaria Cambodia Canada

Chile China Colombia

Croatia Cyprus Czech Republic

Denmark Dominican Republic Ecuador

Egypt El Salvador Estonia

Finland France Germany

Ghana Greece Guatemala

Herzegovina Honduras Hong Kong

Hungary Iceland India

Indonesia Iraq Ireland

Italy Jamaica Japan

Jordan Kazakhstan Kenya

Kuwait Kyrgyzstan Latvia

5.375 x 8.375 ver 3.1

Europe - Restrictions for use of 2.4 GHz Frequencies in

European Community Countries

Lebanon Lesotho Liechtenstein

Lithuania Luxembourg Macedonia

Malaysia Malta Mexico

Monaco Montenegro Mozambique

Nambia Nepal Netherlands

New Zealand Nicaragua Nigeria

Norway Oman Pakistan

Panama Papua New Guinea Paraguay

Peru Philippines Poland

Portugal Puerto Rico Qatar

Romania Russia Saudi Arabia

Senegal Serbia Singapore

Slovak Republic Slovenia South Africa

South Korea Spain Sri Lanka

Sweden Switzerland Taiwan

Thailand Turkey UAE (United Arab

Emirates)

Ukraine United Kingdom Uruguay

USA Venezuela Vietnam

Yemen Zimbabwe

België/

Belgique: For private usage outside buildings across public grounds over less than

300m no special registration with IBPT/BIPT is required. Registration to

IBPT/BIPT is required for private usage outside buildings across public

grounds over more than 300m. For registration and license please

contact IBPT/BIPT.

Voor privé-gebruik buiten gebouw over publieke groud over afstand

kleiner dan 300m geen registratie bij BIPT/IBPT nodig; voor gebruik

over afstand groter dan 300m is wel registratie bij BIPT/IBPT nodig.

Voor registratie of licentie kunt u contact opnemen met BIPT.

Dans le cas d’une utilisation privée, à l’extérieur d’un bâtiment, au-

dessus d’un espace public, aucun enregistrement n’est nécessaire pour

une distance de moins de 300m. Pour une distance supérieure à 300m un

enregistrement auprès de l’IBPT est requise. Pour les enregistrements et

licences, veuillez contacter l’IBPT.

Deutschland: License required for outdoor installations. Check with reseller for

procedure to follow.

Anmeldung im Outdoor-Bereich notwendig, aber nicht

genehmigungspflichtig. Bitte mit Händler die Vorgehensweise

abstimmen.

France: Restricted frequency band: only channels 1 to 7 (2400 MHz and 2454

MHz respectively) may be used outdoors in France. Please contact

A.R.T. (http://www.art-telecom.fr) for applicable procedures to follow.

Altri manuali per A505-S6992

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Toshiba Computer portatile

Toshiba

Toshiba P505D-S8000 Manuale utente

Toshiba

Toshiba M400 - Portege - Core 2 Duo 1.83 GHz Manuale utente

Toshiba

Toshiba Portege M700 Series Manuale utente

Toshiba

Toshiba A6 (PTA60U) Manuale utente

Toshiba

Toshiba Tecra S3 Manuale utente

Toshiba

Toshiba U305-S5097 Istruzioni per l'installazione

Toshiba

Toshiba Satellite M200 Manuale utente

Toshiba

Toshiba L305-S5931 Manuale utente

Toshiba

Toshiba Satellite 1800 SERIES Manuale elenco delle parti

Toshiba

Toshiba Satellite 2615DVD Manuale utente

Toshiba

Toshiba P100-ST1072 Manuale utente

Toshiba

Toshiba Satellite Pro L500-SP6016L Manuale utente

Toshiba

Toshiba Portege 3015CT Manuale utente

Toshiba

Toshiba M45-S2653 Manuale utente

Toshiba

Toshiba Portege A600 Manuale utente

Toshiba

Toshiba Satellite L755-S5239 Manuale utente

Toshiba

Toshiba U500-ST5307 Manuale utente

Toshiba

Toshiba Satellite P205 Manuale utente

Toshiba

Toshiba M3-S636 Manuale utente

Toshiba

Toshiba Portege Z30-C Series Manuale utente

Toshiba

Toshiba L515 S4925 - Satellite - Pentium 2.1 GHz Manuale utente

Toshiba

Toshiba Satellite Pro C650 Manuale utente

Toshiba

Toshiba L450-EZ1522 Manuale utente

Toshiba

Toshiba 1955-S801 Manuale utente

Manuali Computer portatile popolari di altre marche

HP ze2401xt - Pavilion Notebook PC Manuale utente

Velocity

Velocity NoteMagix M10 Manuale utente

Dell

Dell Alienware 17 R2 Manuale utente

HP ENVY 17 Manuale

Winbook

Winbook LM Manuale utente

Dell

Dell Inspiron 1464 Manuale utente

Dell

Dell Inspiron 15R 5537 Manuale utente

HP PROBOOK 4520S Manuale

Dell

Dell Latitude ATG D620 Manuale utente

Sony

Sony VAIO PCG-FX270 Manuale utente

Dell

Dell Latitude 7310 Manuale utente

Dell

Dell Precision GU806 Manuale utente

Sony

Sony VAIO PCG-R505JLK Manuale utente

Lenovo

Lenovo THINKPAD X32 Manuale utente

HP Compaq tc4200 Guida rapida

Lenovo

Lenovo ThinkPad X201 Tablet Manuale

Lenovo

Lenovo THINKPAD X31 Manuale

Sony

Sony VGN-T240P VAIO Manuale utente
