Toshiba IK-TF9C Manuale utente

IK-TF9C

3-MEGA PIXEL 3 CCD COLOR CAMERA

›3 Progressive Scan CCD Sensors

›Output Resolution of 2048 x 1536

›Video Output – Camera Link

›20 frames/sec (full frame)

›Partial Scan 30 frames/sec and 40 frames/sec

›Ultra Compact Size

›On-screen and RS-232 Setup

›Asynchronous Reset

›Pulse Width Trigger

›C-Mount Lens Mount

3-MMEGA PPIXEL

3CCCD

PROGRESSIVE SSCAN

COLOR CCAMERA

13 1

26 14

44±0.2

22±0.1

8.2

19.2 2-M2

26±0.1

5±0.1 4.8

2-M3 Depth 3

78 -0.3

+0.2 6.3

26±0.1

5±0.1 56±0.2

25±0.2 25±0.1

4-M3 Depth 3

4-M2 Depth 3

Scanning System Progressive Scan

Image Sensor 3 x 1/3” CCD

Effective Pixels 1034 x 779

Output Pixels 2048 x 1536 (by way of 1/2 pixel offset)

Frame Rate 20 frames per second (full frame)

Partial Scan 30 fps (972 lines); 40 fps (644 lines)

Pixel Size 4.65 µm (H) x 4.65 µm (V)

Clock 80.87 MHz

Output Interface Camera Link

Output Signal 8-bit RGB

Sync Signal Output FVAL/LVAL/DVAL

Gamma Correction Yes

White Balance AWB/Manual

Gain Manual, OFF (odB)

Input Power 12VDC +/- 10%

Minimum Illumination 10 Lux at F2.2

Lens Mount C-mount

Ambient Temp. 0ºC - 40ºC

Ambient Humidity Less than 90%

Weight 165g

Dimensions 44 mm x 44 mm x 78.3 mm

IK-TF9C

3 MEGA PIXEL 3CCD COLOR CAMERA

products and names mentioned are the property of their respective owners.

While Toshiba has made every effort at the time of publication to ensure the

accuracy of the information provided herein, product specifications, configu-

rations, prices, system/component/options availability are all subject to

change without notice.

Toshiba America Information Systems, Inc.

Imaging Systems Division

9740 Irvine Boulevard, Irvine, California 92618

1-602-7967130 • www.cameras.toshiba.com

SPECIFICATIONS

DIMENSIONS

CONNECTOR PIN ASSIGNMENTS

DC IN 12V Terminal

DISP Button

MENU UP Button

DATA UP (AWB) Button

DATA DOWN Button

MENU DOWN Button

PAGE Button

DIGITAL Terminal

Prism Faceplate

1 GND

2 X0-

3 X1-

4 X2-

5 Xcllk-

6 X3-

7 SerTC+

8 SerTFG-

9 CC1-

10 CC2+

11 CC3-

12 CC4+

13 GND

14 GND

15 X0+

16 X1+

17 X2+

18 Xcllk+

19 X3+

20 SerTC-

21 SerTFG+

22 CC1+

23 CC2-

24 CC3+

25 CC4-

26 GND

1 +12V

2 +12V

3 GND

4 GND

Serial communication control (RXD)

Serial communication control (TXD)

Trigger pulse input

Partial scanning control

Connector used:

HR10A-7P-4PB

(HIROSE electronics

Co. Ltd.) or equivalent

Connector used:

12226-51000-00 (3M)

or equivalent

Measurements in Millimeters

3 4

DC IN 12V DIGITAL Function I/O
