Toshiba IK-WB16A Manuale utente
NETWORK CAMERA
Model: IK-WB16A / IK-WB16A-W
Quick Start Guide and Important Safeguards
This guide describes the hardware installation.
Refer to the user's manual (PDF le) contained in the CD-ROM for settings, operations
and other information.
The application Adobe Reader is needed to view PDF les. If you do not have this
application, download it from the Adobe Systems Incorporated website.
For information on our latest products and peripheral devices, refer to the following
Website:
nhttp://www.toshibasecurity.com
If the URL changes, refer to the Toshiba website (http://www.toshiba.com).
IK-WB16A IK-WB16A-W
2
Introduction
FCC (USA)-INFORMATION
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
lReorient or relocate the receiving antenna.
lIncrease the separation between the equipment and receiver.
lConnect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
lConsult the dealer or an experienced radio/TV technician for help.
Shielded interface cables must be used in order to comply with emission limits.
USER-INSTALLER CAUTION: Your authority to operate this FCC veried
equipment could be voided if you make changes or modications not expressly
approved by the party.
3
Thank you for purchasing the IK-WB16A/IK-WB16A-W Network Camera. Before
you start using the camera, read this quick start guide carefully to ensure
correct usage. Once you have nished reading this quick start guide, keep it in a
convenient place for future reference.
The design, specications, software, and quick start guide contents are subject to
change without prior notice.
Terms and Trademarks
lThe term "OS" is used in this manual to indicate operating systems compatible
with this product.
-- Windows®XP: Microsoft®Windows® XP operating system
-- Windows Vista®: Microsoft®Windows Vista® Business operating system
-- Windows 7®: Microsoft® Windows 7® Professional operating system
lThe formal name of Windows®is Microsoft®Windows® Operating System.
lMicrosoft®, Windows®and Windows Vista®are trademarks or registered
trademarks of Microsoft®Corporation in the United States and other countries.
lAdobe is a registered trademark and Adobe Reader is a trademark of Adobe
Systems Incorporated.
lOther product names appearing in this quick start guide may be trademarks or
registered trademarks of their respective holders.
NOTE
lThe performance of the network camera may vary depending on the network
environment.
4
Table of Contents
Introduction
Introduction....................................................................................................... 2
Terms and Trademarks ..............................................................................................3
Table of Contents.............................................................................................. 4
IMPORTANT SAFEGUARDS ........................................................................... 5
NOTES ON USE AND INSTALLATION.......................................................... 10
Setting the Network Camera Environment ..................................................... 12
Items needed for network camera monitoring.........................................................12
Contents ......................................................................................................... 13
Physical Description ....................................................................................... 14
Hardware Installation...................................................................................... 15
Network Deployment ...................................................................................... 18
General Connection (without PoE)...........................................................................18
Power over Ethernet (PoE) (IK-WB16A only)...........................................................19
Assigning IP Address...................................................................................... 20
Retrieving Images........................................................................................... 21
Congure the Wireless Connection (IK-WB16A-W only)................................ 22
Quick Start Guide
5
IMPORTANT SAFEGUARDS
1. Read Instructions
Read all the safety and operating instructions before operating the product.
2. Retain Instructions
Retain the safety instructions and user's manual for future reference.
3. Warnings
Comply with all warnings on the product and in the user's manual.
4. Follow Instructions
Follow all operating and use instructions.
5. Cleaning
Disconnect this video product from the power supply before cleaning.
6. Attachments
Do not use attachments not recommended by the video product manufacturer
as they may pose safety risks.
7. Water and Moisture
Do not use this video product near water. Some examples are: near a bath tub,
wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming
pool.
8. Accessories
Do not place this video product on an unstable cart, stand, tripod, bracket
or table. The video product may fall, causing serious injury to a person, or
serious damage to the product. Use only with stand, tripod,bracket,or table
recommended by the manufacturer, or sold with the video product. Any
mounting of the product should follow the manufacturer's instructions, and
should use a mounting accessory recommended by the manufacturer.
9. Ventilation
This video product should never be placed near or over a radiator or heat
register. If this product is placed in a built in installation verify that there is proper
ventilation so that the camera temperature operates within the recommended
temperature range.
6
IMPORTANT SAFEGUARDS (Cont.)
10. Power Sources
This video product should be operated only from the type of power source
indicated on the information label. If you are not sure of the type of power
supply at your location, consult your product dealer.
11. Power-Cord Protection
Power cords should be routed so that they are not likely to be walked on or
pinched by items placed upon or against them. Pay particular attention to cords
at plugs, screws and the point where they exit the product.
12. Installation
Install this video product on a secure part of the ceiling or wall. If installed on an
unsecured location, the camera could fall causing injury and damage.
13. Lightning
For additional protection on this video product during a lightning storm, or when
it is left unattended and unused for long periods of time, unplug it from the wall
outlet and disconnect the power supply and cable system. This will prevent
damage to the video product due to lightning and power-line surges. If lightning
occurs, do not touch the unit or any connected cables in order to avoid electric
shock.
14. Overloading
Do not overload the power supply or extension cords as this can result in a risk
of re or electric shock.
15. Object and Liquid Entry
Never push objects of any kind into this video product through openings as they
may touch dangerous electrical points or short-out parts that could result in a
re or electrical shock. Never spill liquid of any kind on the video product.
16. Servicing
Do not attempt to service this video product yourself as opening or removing
covers may expose you to dangerous electrical or other hazards. Refer all
servicing to quali ed service personnel.
7
17. Damage Requiring Service
Disconnect this video product from the power supply and refer servicing to
qualied service personnel under the following conditions.
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the video product.
c. If the video product has been submerged in water.
d. If the video product does not operate normally by following the operating
instructions in the user's manual. Adjust only those controls that are covered
by the user's manual as an improper adjustment of other controls may result
in damage and will often require extensive work by a quali ed technician to
restore the video product to its normal operation.
e. If the video product has been dropped or the cabinet has been damaged.
f. When the video product exhibiting a distinct change in performance which
indicates a need for service.
18. Replacement Parts
When replacing parts be sure the service technician uses parts specied
by the manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in re, electric shock or other hazards.
19. Safety Check
Upon completion of any service or repairs to this video product, ask the service
technician to perform safety checks to determine that the video product is in
proper operating condition.
20. When using a wireless LAN function (IK-WB16A-W):
• Do not use near people with heart pacemakers.
• Do not use near electronic medical equipment, or in hospitals or other
medical institutions.
• Do not use inside aircraft or in places where the wireless LAN function
could interfere with electromagnetic signals.
The electromagnetic interference could cause a malfunction, resulting in an
accident.
8
21. If the use of a wireless LAN function interferes with another device’s
electromagnetic signals, cease use immediately. (IK-WB16A-W)
The electromagnetic interference could cause a malfunction, resulting in an
accident.
9
IMPORTANT SAFEGUARDS (Cont.)
CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning ash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be of
sufcient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
WARNING:
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
FIELD INSTALLATION MARKING:
WORDED: “THIS INSTALLATION SHOULD BE MADE BY A QUALIFIED SERVICE
PERSON AND SHOULD CONFORM TO ALL LOCAL CODES.”
10
NOTES ON USE AND INSTALLATION
lDo not aim the camera at the sun
Never aim the camera at the sun even with the camera power off.
lDo not shoot intense light
Intense light such as a spotlight may cause a bloom or smear. A vertical stripe
may appear on the screen. However, this is not a malfunction.
lTreat the camera with care
Dropping or subjecting the camera to intense vibration may cause it to
malfunction.
lAvoid Volatile Liquid
Do not use volatile liquids, such as an insect spray, near the unit. Do not leave
rubber or plastic products touching the unit for a long time. They will leave
marks on the nish. Do not use a chemically saturated cloth.
lNever touch internal parts
Do not touch the internal parts of the camera other than the parts specied.
lKeep the camera installation away from video noise
If cables are wired near electric lighting wires or a TV set, noise may appear in
images. In this event relocate cables or reinstall equipment.
lCheck the ambient temperature and humidity
Avoid using the camera where the temperature is hotter or colder than the
specied operating range. Doing so could affect the internal parts or cause the
image quality to deteriorate. Special care is required to use the camera at high
temperature and humidity.
lShould you notice any trouble
If any trouble occurs while you are using the camera, turn off the power and
contact your dealer. If you continue to use the camera when there is something
wrong with it, the trouble may get worse and an unpredictable problem may
occur.
Altri manuali per IK-WB16A
1
Questo manuale è adatto per i seguenti modelli
1
Indice
Altri manuali Toshiba Telecamera di sicurezza
Toshiba
Toshiba IK-DF03A Manuale utente
Toshiba
Toshiba IK-644A Manuale utente
Toshiba
Toshiba IK-WR12A Manuale utente
Toshiba
Toshiba IK-WP41A Manuale utente
Toshiba
Toshiba CCD Monochrome Camera IK-539A Manuale utente
Toshiba
Toshiba DF03A - IK CCTV Camera Manuale utente
Toshiba
Toshiba IK-WB80A Manuale utente
Toshiba
Toshiba IK-DF02ADAY Manuale utente
Toshiba
Toshiba IK-WB70A - IP/Network Camera, PoE Manuale utente
Toshiba
Toshiba IK-DP20A Manuale utente
Toshiba
Toshiba IK-WB21A - IP Network PTZ Camera Istruzioni per il montaggio
Toshiba
Toshiba IK-7100A Manuale utente
Toshiba
Toshiba IK-WD14A Manuale utente
Toshiba
Toshiba IK-DP20A Manuale utente
Toshiba
Toshiba IK-WB15A - IP Network Camera Manuale utente
Toshiba
Toshiba IK-64DNA Manuale utente
Toshiba
Toshiba IK-527A Manuale utente
Toshiba
Toshiba IK-WB70A - IP/Network Camera, PoE Manuale utente
Toshiba
Toshiba IK - TF7H Manuale utente
Toshiba
Toshiba IK-WB01A Manuale utente
