Totally Wicked Resolve 2 Manuale utente
1
ELECTRONIC CIGARETTE KIT
USER MANUAL
TW Resolve2 Compliant Manual.indd 1 08/11/2016 13:20
2
Congratulations on purchasing your
Totally Wicked Resolve 2 Electronic Cigarette.
The Totally Wicked Resolve 2 is a stylish and compact e-cigarette design,
featuring direct output voltage, a micro USB charging port and adjustable airflow.
The Resolve 2 combines its features and 1300mAh Li-battery capacity in a sleek
and ergonomic, yet particularly simple to use package, suitable for all, from
beginners to advanced electronic cigarette users.
TW Resolve2 Compliant Manual.indd 2 08/11/2016 13:20
3
Using your Resolve 2
Assembly:
To assemble the device, firstly, screw
the atomizer head into the atomizer
base tightly to ensure an effective
seal. The atomizer base must then
be screwed into the atomizer tube
and the mouthpiece attached. Finally,
screw the liquid tank onto the Battery.
Filling the Tank:
To fill the tank with e-liquid, firstly,
invert the tank, unscrew the atomizer
base from the atomizer tube and
slowly fill the tube with e-liquid by
inserting the nozzle into one of the
two filling holes. Screw the atomizer
base back onto the atomizer tube.
Maximum refill nozzle diameter:
2.8mm.
Note: Do not overfill the tank, for
best results fill the tank to between
10%-90% capacity. When first using
an atomizer, to ensure the best
performance and longevity, drip a
few drops of e-liquid into the wicking
material of the atomizer to ensure
that it is saturated before vaping.
TW Resolve2 Compliant Manual.indd 3 08/11/2016 13:20
4
Using your Resolve 2
Power On and Off:
The Resolve 2 uses a 5-click on/
off function. To switch the device on
quickly press the power button 5
times. The white button light will flash
5 times, signifying that the device is
powered on. Once the Resolve 2 is
powered on press the button 5 times
to switch the device off.
Vaping:
Simply press the power button as
you inhale.
Airflow Adjustment:
To adjust the amount of airflow the
supplied airflow ring must be slid
around the bottom of the tank so
that the two slots are aligned. The
ring can now be rotated to give the
preferred amount of airflow.
TW Resolve2 Compliant Manual.indd 4 08/11/2016 13:20
5
Using your Resolve 2
Charging the Batteries:
To charge the integrated 1300mAh
Li-Battery, simply plug the device
into the charging lead provided
whilst using a suitable wall adaptor
or powered USB port. The button
light will turn red when the device is
charging, and will turn off when the
device is fully charged.
Battery Level Indication:
Battery
Level
Light
Condition
60%-100% Stays Lit
30%-59% FlashesSlowly
10%-29% Flashes
Moderately
0%-9% Flashes
Quickly
TW Resolve2 Compliant Manual.indd 5 08/11/2016 13:20
6
Using your Resolve 2
No Atomizer Protection:
When no atomizer is detected and
the power button is pressed, the
white button light will flash slowly.
Fifteen Second Protection:
When the power button is held in
excess of 15 seconds, the device
will automatically shut off and the
white button light will flash 10 times
consecutively.
Short Circuit Protection:
If a short circuit occurs when
the power button is pressed, the
white button light will flash 3 times
consecutively. Replace the atomizer
to continue.
Low Voltage Protection:
When the battery voltage of the
device is below 3.3V, the white
button light will flash 40 times and
automatically power off. Recharge
the device to power it on.
TW Resolve2 Compliant Manual.indd 6 08/11/2016 13:20
7
Kit Contents Specications
1 x Resolve Battery
1 x Resolve 2 Tank
2 x CS Pure cotton atomizer head
(0.75ohm)
1 x USB cable
1 x User manual
Overall Length: 141.5mm
Battery Dimensions: 16.5mm
Dia. x 88mm
Tank Dimensions: 16.5mm Dia.
x 53.5mm
(Inc. mouthpiece)
Tank Capacity: 2ml
Atomizers: 2 x CS 0.75ohm
Resistance Range: 0.4ohm – 3.5ohm
Tank Connector: 510 Connector
Battery: 1300mAh Li-Battery
Maximum refill nozzle diameter:
2.8mm
TW Resolve2 Compliant Manual.indd 7 08/11/2016 13:20
8
There are no reported medical side effects with this product. If you believe you
experience a side effect, please contact the manufacturer.
Additional product information
TW Resolve2 Compliant Manual.indd 8 08/11/2016 13:20
9
Additional product information
• Store the Resolve 2 and its accessories away from children when not in use.
• Ensure the Resolve 2 is powered off when not in use.
• Avoid accidentally pressing the Resolve power button when not in use.
• Please only use the charging cable provided.
• Please dispose of dead batteries in accordance with your country’s
appropriate legislation.
• Do not charge the batteries in a damp environment.
• Do not use the device when temperatures are outside the range -10 - 60°C.
• Do not charge the battery when temperatures are outside the range 0 - 45°C.
• Do not carry batteries in a pocket bag with other metallic objects.
• Do not attempt to repair a faulty Resolve 2 as these are sealed units with no
serviceable parts. Attempted repairs will void the warranty.
Product storage and battery precautions
TW Resolve2 Compliant Manual.indd 9 08/11/2016 13:20
10
The Resolve 2 components have a 28-day parts warranty. The USB cable
supplied has a 12-month warranty. If any parts are found to be faulty within this
time please contact our customer service team, whose details are on the back
page of this booklet and we will arrange for a replacement. We may require the
goods to be returned for further investigation.
Warranty
