Celica
Brief guide
1
Brief guide
Index
Introducing Celica.................................................. 2
Lock system............................................................ 3
Seats and seat belts ................................................ 4
Bonnet and fuel tank opening................................ 5
Dashboard.............................................................. 6
Lights and wipers ................................................... 9
Heating and A/C control ........................................ 10
Power windows...................................................... 11
Gear change........................................................... 11
Tyre change.............................................................12
Service.....................................................................12
CEL11-0502ENUK-03-00 CEL11-0502ENUK-03-00
2
Introducing Celica
Congratulations on selecting a new
Celica!
Now you can begin enjoying this outstanding vehicle
immediately with this brief guide to basic vehicle
operations.
This brief guide contains a summary description of
basic operations so that you can locate and use the
vehicle’s main equipment and features, quickly and
easily.
This brief guide does not replace or substitute the
Owner’s Manual which you will find in the vehicle’s
glove compartment. It is important that you review
the full Owner’s Manual as well as any further
supplementary manuals. This will allow you to
familiarise yourself with the operating and safety
instructions and to handle the vehicle within its
limitations.
Your dealership and the entire staff of Toyota wish
you many years of enjoyable driving in your new
Celica.
PS: All information contained in this Brief Guide is current at the time of
printing. Toyota reserves the right to make changes at any time without notice.
CEL11-0502ENUK-03-00 CEL11-0502ENUK-03-00
Fit child seat
in the back
Stow loose objects
safely in the boot
Adjust seat and
head restraint
Fasten front and
rear seatbelts
at all times
10 seconds... that can save your life
Think before you drive !
European Road Safety Campaign
with the support of the European Commission
CEL11-0502ENUK-03-00 CEL11-0502ENUK-03-00
3
Lock system
Key number plate
Your key number is shown on
the plate. If you should lose
your keys or if you need
additional keys, duplicates can
be made using the key number.
Engine immobiliser system
The engine immobiliser system
is a theft prevention system. The
engine will start, only when the
electronic code in the chip
inside the key corresponds to
the registered ID code for the
vehicle.
Wireless remote control Locking operation. Your vehicle
has a wireless remote control
system that can lock or unlock
all the side doors and back door
from a distance within
approximately 1m (3ft) of the
vehicle.
Double locking. All new Celica
models have high security
double locks. To double lock the
doors, push the lock button on
the key twice.
Unlocking operation. To lock
and unlock all the side doors
and back door, push the
switches of the key slowly and
securely.
Locking wheel nuts. New
Celica vehicles fitted with alloy
wheels are also specified with
locking wheel nuts.
TVSS Alarm*. The Celica is
fitted with a Toyota Vehicle
Security System for the long
term benefit of your car.
(selected models)
International Security Register.
Your new Celica has a unique
number etched into all window
glass. The ISR operates a 24
hour service which can provide
peace of mind for your
purchase.
*Category 1 approved
Locking operation
Unlocking operation
4
Seats and seat belts
CEL11-0502ENUK-03-00 CEL11-0502ENUK-03-00
Seats
Adjusting front seats:
1. Seat position adjusting lever
Pull the lever up. Then slide the
seat to the desired position with
slight body pressure and release
the lever.
2. Seat back angle adjusting lever
Lean forward and pull the lever
up. Then lean back to the
desired angle and release the
lever.
3. Seat cushion angle adjusting
knob
Turn the knob either way.
Moving passenger’s seat for rear
seat entry
For easy access to the rear seat,
after seat.
1. Lift the seatback angle adjusting
lever or press the pedal behind
the seatback.
The seat will slide forward.
2. Move the seat to the front-most
position.
After passengers are in, lift up
the seatback and return the seat
until it locks.
Fold-down rear seat
Pull the lock release button and fold
down the seatback.
Each seatback may be folded
separately (50 : 50 split).
This will enlarge the luggage
compartment as far as the front
seatbacks.
Seat belts
Adjust the seat as needed (front
seats only) and sit up straight and
well back in the seat. To fasten your
belt, pull it out of the retractor and
insert the tab into the buckle.
CEL11-0502ENUK-03-00 CEL11-0502ENUK-03-00
5
Bonnet and fuel
tank opening
Bonnet
To open the bonnet:
1. Pull the bonnet lock
release lever. The bonnet
will spring up slightly.
2. In front of the vehicle,
pull up the auxiliary catch
lever and lift the bonnet.
3. Hold the bonnet open by
inserting the support rod
into the slot.
Fuel tank cap
To open the fuel tank door,
pull the lever up.
To remove the fuel tank cap,
turn the cap slowly counter-
clockwise, then pause
slightly before removing it.
After removing the cap,
hang the tether as shown in
the illustration.
Fuel type & tank capacity
Fuel type: unleaded petrol
with a RON of 95 or higher.
Tank capacity: 55 litres.
CEL11-0502ENUK-03-00 CEL11-0502ENUK-03-00
6
Dashboard
1. Clock
2. Emergency flasher switch
3. Headlight and turn signal
switch, and rear fog
and/or front fog light
switch
4. Wiper and washer
switches
5. Instrument panel light
control knob
6. Window lock switch
7. Headlight beam level
control switch
8. Traction control system
off switch*
9. Engine immobiliser
system indicator light
10. Ignition switch
11. Tilt steering wheel lock
release lever
12. Ashtray
13. Cigarette lighter
14. Rear window and outside
rear view mirror defogger
switch
15. Air conditioning controls
16. Car audio
17. Auxiliary box
* on Celica T Sport only
Instrument panel overview
CEL11-0502ENUK-03-00 CEL11-0502ENUK-03-00
7
To change the steering wheel
angle, hold the steering wheel,
push the lock release lever, tilt
the steering wheel to the desired
angle and return the lever to its
original position.
Tilt steering wheel
CEL11-0502ENUK-03-00 CEL11-0502ENUK-03-00
8
1. Tachometer
2. Service reminder indicators
and Indicator lights
3. Speedometer
4. Engine coolant temperature
gauge
5. Odometer and two trip
meters
6. Fuel gauge
7. Trip meter reset knob
Indicator symbols on the instrument panel
Instrument cluster overview
Brake system
warning light
Discharge
warning light
Low engine oil
pressure warning
light
Malfunction
indicator lamp
Low fuel level
warning light
Driver’s seat belt
reminder light
Front passenger
seat belt
reminder light
Anti-lock brake
system warning
light
SRS warning light
Open door
warning light
Turn signal
indicator lights
Tail light indicator
light
Headlight high
beam indicator
light
Rear fog light
indicator light
Front fog light
indicator light
Automatic
headlight leveling
system warning
light*
Vehicle stability
control system and
traction control
system warning
light*
Slip indicator light*
Traction control
system off
indicator light*
* on Celica T Sport only
CEL11-0502ENUK-03-00 CEL11-0502ENUK-03-00
9
Lights and wipers
Headlights
Windscreen wipers and
washer
To turn on the following lights:
twist the headlight/turn signal lever
knob.
Position 1: Parking, tail, license plate
and instrument panel lights
Position 2: Headlights and all of the
above.
High-low beams.
For high beams, turn the headlights on
and push the lever away from you
(position 1). Pull the lever toward you
(position 2) for low beams.
Flashing the high beam headlights
(position 3). Pull the lever all the way
back. The high beam headlights turn off
when you release the lever.
Rear window wiper and
washer
To turn on the windscreen wipers,
move the lever to the desired setting.
Position 0: off
Position 1: mist
Position 2: intermittent
Position 3: slow
Position 4: fast
To spray washer fluid, pull the lever
towards you.
To turn on the rear window wiper,
twist the lever knob upwards.
Position 1: Intermittent
Position 2: Normal
Position 3,4: Washer fluid
