Toyota LAND CRUISER V8 Guida di riferimento

Land Cruiser V8

Brief Guide

Table of Contents

Accessing your vehicle 2

Rear door child protection lock 3

Child restraint system 3

Seat and seat belt adjustment 4

Steering wheel adjustment 5

Instrument panel overview 6

Functions overview 7

Dashboard instruments 8

Instrument Cluster 8 - 9

Lights 9

Wipers 10

Electric windows and windows lock 11

Starting your vehicle 11

eating, A/C and de-misting 12

Set up display to access clock setting 13

Gear change 14

Fuel tank opening 15

Bonnet opening 15

Eco-Driving 16

Introducing Land Cruiser V8

Thank you for buying a Land Cruiser V8. We trust this Brief Guide will enable you to become

familiar with your vehicle’s basic operations and assist you in enjoying your vehicle.

This brief guide does not replace or substitute the Owner’s Manual, which you will find in the

vehicle’s glove compartment. It is important that you review the full Owner’s Manual as well as

any further supplementary manuals as this will allow you to familiarise yourself with the

operating and safety instructions and to handle the vehicle within its limitations.

Please do read all documents in your pack as this will ensure you get maximum performance

from your car and learn about related services offered.

Your Centre and everyone at Toyota wish you many years of enjoyable driving in your

new Land Cruiser V8.

NB: All information contained in this brief guide is current at the time of printing.

Toyota reserves the right to make changes at any time without notice.

Smart entry & Start system

The following operations can be performed simply by carrying the electronic key on your person.

(The driver should always carry the electronic key.)

The Mechanical Key is stored within the

Electronic Key

Accessing your vehicle

1. Electronic keys

- Operate smart entry & start system.

- Operate the wireless remote control function.

2. Mechanical keys.

3. Key number plate.

4. Open/closes the back door (if equipped).

1. Locks and unlocks the doors.

2. Locks and unlocks the boot.

3. Starts and stops the engine.

Rear door child protection lock

The door cannot be opened from inside the vehicle

when the locks are set.

These locks can be set to prevent children from

opening the rear doors. Push down the rear door

switches to lock the rear doors.

Child restraint syste

Child restraint systems are classified into the following 5 groups according to the regulation ECE No. 44:

Group 0: Up to 10 kg (0-9 months)

Group 0+: Up to 13 kg (0-2 years)

Group I: 9-18 kg (9 months-4 years)

Group II: 15-25 kg (4 years -7 years)

Group III: 22-36 kg (6 years-12 years)

(A) Baby seat

equal to Group 0 and 0+ of “ECE

No. 44”

(B) Child seat

equal to Group 0+and I of “ECE

No. 44”

equal to Group II and III of “ECE

No. 44”

Seat and seat belt adjust ent

Manual seat

1. Seat position

adjustment .

2. Seat back angle

adjustment .

3. Vertical height

adjustment.*

4. Seat cushion angle

adjustment knob.*

5. Lumbar support

control*

*: Driver's side only

Power seat

1. Seat position

fore/aft control.

2. Seat back angle

control.

3. Seat cushion (front)

angle control.

4. Vertical height

control switch.

5. Lumbar support

control (driver's side

only).

Head restraint height adjustment

Pull to move

upwards.

Press and hold

lock release to

lower.

Angle adjustment .

The centre of the head

restraint should be level

with the top of the ears

For reasons of safety your vehicle is fitted

with active head restraints

Under no circumstances should any

accessories be attached to these

(e.g. portable DVD players, etc).

Seat belts

1. To fasten the seat belt push the

tab into the buckle until it clicks.

2. Press the release button to

unfasten the seat belt.

Adjust the height up (1) and down (2) as

required.

Lock release

Steering wheel adjust ent

To change the angle

Manual tilt & telescopic steering

Auto tilt away ( vehicles with power tilt &

telescopic steering wheel)

Steering wheel must not be adjusted while the

vehicle is in motion.

1. Tilt up

2. Tilt down

3. Move/extend towards driver

4. Move/retract away from the driver

Power tilt & telescopic steering wheel

1. old the steering wheel and pull the lock release

lever towards you.

2. Tilt the steering wheel to the desired angle and

release the lever.

When the "ENGINE START STOP" switch is turned OFF,

the steering wheel returns to its stowed position by

moving up and away to enable easier driver entry and

exit.

Switching to the ACCESSORY / IGNITION mode will

return the steering wheel to its original position.

To change the column length

1. old the steering wheel and push down the lock

release lever.

2. Set the steering wheel to the desired length and

return the lever to its original position.

Instru ent panel overview

A. Functions overview (page 7)

B. Dashboard instruments (page 8).

eadlight switch

Indicator lever

Fog light switch

Multi-information display

Windscreen wipers and

washer switch

Rear window wiper and

washer switch

Cup holders

SRS knee airbags

Fuel filler door opener

Gauges and meters

Bonnet opener

Audio remote controls

Functions overview

Area A indicated on instrument panel overview (page 6).

With navigation system

Without navigation system

* On some models

Clock* Outside temperature display

Airbag manual on-off

indicator

Security indicator light

Navigation system*

Air conditioning system*

Front passenger’s seat

belt reminder light

azard light switch

Rear window

defogger switch

Audio system*

Clock

Airbag manual

on-off indicator

Front passenger’s seat

belt reminder light

Security indicator light

Audio system*

Outside

temperature

display

Air conditioning system

azard light switch

Rear air conditioning

control switch

Windscreen wiper

de-icer switch

Rear window

defogger switch

Dashboard instru ents

Instru ent cluster

The following gauges, meters and displays illuminate when the ‘‘ENGINE START STOP’’ switch is in the IGNITION

ON mode.

Area B indicated on instrument panel overview (page 6).

* On some models

eadlight

leveling dial*

Outside rear view mirror control switches

Instrument cluster light control knob

Odometer/trip meter and trip meter reset button

Roll sensing of curtain shield airbags off switch

eated steering wheel switch*

eadlight

cleaner switch*

Card holder

Tilt and telescopic steering control switch*

Toyota parking assist-sensor switch*

VSC OFF switch

Centre differential lock/unlock switch

Tachometer

Displays the engine speed in

revolutions per minute.

Engine coolant

temperature gauge

Displays the engine coolant

temperature.

Multi-information display

Voltmeter

Displays the

charge state.

Speedometer

Displays the vehicle

speed.

Fuel gauge

Displays the quantity of fuel

remaining in the tank.

Engine oil

pressure

gauge

Instrument panel

light control dial Odometer/trip meter display change button
