TP-Link TL-PA4010P KIT EU Manuale utente

www.tp-link.com

TL-PA4010P

Features：

Description：

AV500 Powerline

Adapter with AC Pass Through

TP-LINK’s 500Mbps Powerline Adapter with AC Pass Through, TL-PA4010P turns your existing powerline into a high speed

network with no need for new wires or drilling. No conguration is required, simply plug your adapter into your power sockets

and you can establish networking infrastructure in a ash. What’s more, its integrated power socket allows an additional device

or power bar to be connected to the adapter as though it were a normal wall socket. With speeds up to 500Mbps, TL-PA4010P

is a great choice for an easy to build multimedia entertainment network.

Data transfer rate up to 500Mbps over electrical wires,

ideal for HD video streaming

Embedded power socket ideal for other devices using

the same outlet

No new wires or drilling required, just using existing

electrical wires

No setup required, simply plug and play

Up to 300 meters range over the household power circuit

for better performance through walls or across oors

Power-Saving Mode automatically reduces power

consumption by up to 85%*

128-bit AES encryption easily at a push of "Pair" Button

* Actual data will vary because of the network conditions

and environment factors.

www.tp-link.com

Specifications：

TL-PA4010P

Package:

AV500 Powerline Adapter with AC Pass Through

TL-PA4010P

2-meter RJ-45 Ethernet Cable

Quick Installation Guide

Resource CD

AV500 Powerline Adapter with AC Pass Through

Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are

trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any

derivative such as translation, transformation, or adaptation without permission from TP-LINK Technologies Co., Ltd.

Diagram:

NAS

* Powerline adapters should be deployed on the same circuit and in set of two or more. The rst, connected to the router and others

located elsewhere to enable connectivity in those locations

Hardware Features

Standards and Protocols

Interface

Plug Type

Button

LED Indicator

Dimensions ( W x D x H )

Power Consumption

Range

Software Features

Modulation Technology

Encryption

Others

Certications

System Requirements

Environment

HomePlug AV, IEEE802.3, IEEE802.3u

1* 10/100Mbps Ethernet Port,Power Socket

EU, UK., FR

Pair Button

Power, Powerline, Ethernet

3.7 x 2.3 x 1.7 in. (95 x 58 x 42 mm)

< 2.2 W

300 meters in house

OFDM

128-bit AES Encryption

CE, FCC, RoHS

Windows 8/7/Vista/XP/2000, Mac OS, Linux*

Operating Temperature: 0°C~40°C (32°F~104°F)

Storage Temperature: -40°C~70°C (-40°F~158°F)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing

* Utility supports Windows 7/Vista/XP/2000 operating system for the present.

Ethernet Cable

Electrical Wire

Power
