TP-Link TL-WA854RE Manuale utente

www.tp-link.com

Features：

TL-WA854RE

300Mbps Universal WiFi

Range Extender

Greatly extend existing wireless coverage to

eliminate “dead zones”

Description

TP-LINK’s wall-mounted TL-WA854RE is designed to conveniently extend the coverage and improve the signal strength of an

existing wireless network to eliminate “dead zones”. Being incredibly user friendly, it is ideal for large homes or oces for

experienced or novice users.

Wireless N speed up to 300Mbps

Wall mount design, just plug in and play, very convenient

Prole function remembers previously connected wireless networks

Supports domain name-based login (http://tplinkextender.net)

for advanced management

Easily extend your wireless network at a push of the Range Extender

button

www.tp-link.com

Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are

trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make

any derivative such as translation, transformation, or adaptation without permission from TP-LINK Technologies Co., Ltd.

TL-WA854RE

300Mbps Universal WiFi Range Extender

Specifications：

IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

Range Extender Button, Reset Button

2*internal

About 3W

2.4~2.4835GHz

11n: Up to 300Mbps(dynamic)

11g: Up to 54Mbps(dynamic)

11b: Up to 11Mbps(dynamic)

< 20 dBm

270M: -68dBm@10% PER

130M: -68dBm@10% PER

108M: -68dBm@10% PER

54M: -68dBm@10% PER

11M: -85dBm@8% PER

6M: -88dBm@10% PER

1M: -90dBm@8% PER

Range Extender

WMM(Wi-Fi Multimedia); Wireless MAC Address Filtering;

Wireless Statistic; Domain Login Function

64/128/152-bit WEP WPA-PSK / WPA2-PSK

EIRP

Receive Sensitivity

Wireless Mode

Wireless Functions

Wireless Security

Wireless Standards

Button

Antenna

Power Consumption

Frequency

Signal Rate

Hardware Features

Wireless Features

Others

CE, FCC, RoHS

Microsoft® Windows® 8/7/Vista™/XP/2000/ NT/98SE,

Mac® OS, NetWare®, UNIX® or Linux.

0℃~40℃(32℉~104℉)

-40℃~70℃(-40℉~158℉)

10%~90% non-condensing

5%~90% non-condensing.

4.3 × 2.6 × 3.0in. (110.0 × 65.8 × 75.2mm)

EU, UK, US

Certication

System Requirements

Operating Temperature

Storage Temperature

Operating Humidity

Storage Humidity

Dimensions ( W x D x H )

Plug Type

www.tp-link.com

Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are

trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make

any derivative such as translation, transformation, or adaptation without permission from TP-LINK Technologies Co., Ltd.

Related Product:

- 300Mbps Wireless N USB ADSL2+ Modem Router

TD -W8968

- 300Mbps Wireless N PCI Adapter

TL-WN851ND

-300Mbps High Gain Wireless USB Adapter

TL-WN822N

Package:

- 300Mbps Universal WiFi Range Extender

TL-WA854RE

- Resource CD

- Quick Installation Guide

Diagram:

Working as a Range Extender

INTERNET

TD-W8968

300Mbps Wireless N USB

ADSL2+ Modem Router

TL-WN851ND

300Mbps

Wireless N PCI Adapter

TL-WN822N

300Mbps High Gain

Wireless USB Adapter

Tablet & Smart Phone

TL-WA854RE

300Mbps Universal WiFi Range Extender

TL-WA854RE

300Mbps Universal WiFi Range Extender
